Summary of Contents for ML Accessories OP6N
- Page 1 INSTALLATION & MAINTENANCE MANUAL OP6N / OP63N...
-
Page 2: General Instructions
These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following product: OP6N / OP63N SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. -
Page 3: Installation
These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following product: OP63 / OP63N SAFETY INSTALLATION • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. - Page 4 • The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is advised if the unit • advised if the unit is installed in a location subject to temperature fluctuations where a is installed in a location subject to temperature fluctuations where a build-up of condensation may occur.
- Page 5 a suitable IP rated gland or adaptor (not supplied). For rear entry, cut or drill a 20/25mm hole where marked and install a suitable IP rated grommet (not supplied). Unused cable entries must have the blank plugs fitted Feed the mains cable into the unit and secure the base plate to the surface. The fixing holes are slotted •...
- Page 6 taking care not to compress, damage or trap any cables, and secure with the screws provided - do not overtighten • Replace front assembly to back box and secure by returning the screws to the LOCKED position Switch on and check for correct operation •...
- Page 7 WARNING To ensure continued safe and proper weatherproof operation, the unit must not be left with the cover raised open or the catch left unlocked. This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing.
-
Page 8: Warranty
ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML... - Page 9 SUPPLIED BY: (UK) MANUFACTURER ML ACCESSORIES LTD, UNIT E CHILTERN PARK, BOSCOMBE ROAD, DUNSTABLE LU5 4LT, WWW.MLACCESSORIES.CO.UK (EU) AUTHORISED REPRESENTATIVE SLV LIGHTING GROUP, DAIMLERSTRASSE 21-23, 52531 ÜBACH-PALENBERG, GERMANY EMAIL: EPREL@GROUP.SLV.COM MADE IN CHINA 230V 50Hz JBOCT24_V1...
