- Page 1 INSTALLATION & MAINTENANCE MANUAL OP7N / OP9N...
- Page 2 These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following products: OP7N / OP9N SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations.
- Page 3 Check the total load on the circuit (including when this product is fitted) does not exceed the rating he circuit cable, fuse or circuit breaker Please note the IP (Ingress Protection) rating of this product when deciding the location for installat Do not overload this accessory or subject it to conditions outside its rating his product is Class I and must be earthed INSTALLATION...
- Page 4 Fig. 2 (OP7N shown) Fig. 2 Remove one or more of the pre-fitted blank plugs as required by pushing out from the inside an a suitable IP rated gland or adaptor (not supplied).
- Page 5 20/25mm hole where marked and install a suitable IP rated grommet (not supplied). Fig. 2 (OP7N shown) Unused cable entries must have the blank plugs fitted Remove one or more of the pre-fitted blank plugs as required by pushing out from the inside and install •...
- Page 6 • An earth connection must be made to the earth terminal of the socket. Use green/yellow sleeving on earth conductors that are not insulated. The earth terminal in the backbox is provided for convenience and does not need to be connected •...
- Page 7 Note: The Power Indicator is lit when there is power to the unit and the switch is on, irrespective of whether a load is plugged in or not WARNING To ensure continued safe and proper weatherproof operation, the unit must not be left with the cover raised open or the catch left unlocked.
- Page 8 ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the right to alter product specification without prior notice.
