ENGLISH - USER MANUAL
Sophia LED light with sensor – BXTILED60B
1. Characteristics
1.1 Technical specifications
Power: 3.2 W
Input: 220-240 V / 50-60 Hz
Battery: Lithium battery
Battery capacity: 2,200 mAh
Battery life: 9 hours
Luminous flux: 230 lumens
Colour temperature: 4,000 K
LED colour: Neutral white
CRI index: 80
Number of LEDs: 157 units
Sensor type: Motion sensor
Sensor range: 120°
Range distance: 10 m
Operating temperature: -20ºC to +45ºC
Lifetime: 20,000 h
Protection rating: IP20
Charging port: USB-A to USB-C
Charging time: 4-5 h
Material: White painted aluminum + ABS
Dimensions: 60 x 4 x 0.9 cm
Weight: 231 g
1.2 In the box
x 1 LED light with sensor
x 1 USB-A to USB-C charging cable (50 cm)
x 2 Magnetic holder with adhesive
x 1 User manual
1.3 Diagram

Advertisement

loading
Need help?

Need help?

Do you have a question about the BXTILED60B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KSIX BXTILED60B

  • Page 1 ENGLISH - USER MANUAL Sophia LED light with sensor – BXTILED60B 1. Characteristics 1.1 Technical specifications Power: 3.2 W Input: 220-240 V / 50-60 Hz Battery: Lithium battery Battery capacity: 2,200 mAh Battery life: 9 hours Luminous flux: 230 lumens...
  • Page 2 1. Montion sensor and 4. Magnetic holder with indicator adhesive 2. LED light 5. Power button 3. Aluminium housing 6. USB-C Charging port 1.4 Instructions for using the Sophia LED light Press the side button for 3 seconds to turn on the LED light. 1.5 How to install the Sophia LED lighting Attach the two metal parts to the back of the LED light using adhesive.
  • Page 3 ESPAÑOL - USER MANUAL Luz LED Sophia con sensor – BXTILED60B 1. Características 1.1 Especificaciones técnicas Potencia: 3,2 W Entrada: 220-240 V / 50-60 Hz Batería: Batería de litio Capacidad de la batería: 2.200 mAh Duración de la batería: 9 horas...
  • Page 4 1.2 En la caja 1 x Luz LED con sensor 1 x Cable de carga USB-A a USB-C (50 cm) 2 x Soportes magnéticos con adhesivo 1 x Manual de usuario 1.3 Diagrama 1. Sensor de 4. Soportes magnéticos movimiento e con adhesivo indicador 5.
  • Page 5 puertos y conectores del producto limpios de polvo, suciedades, etc., para asegurar una correcta conexión. Evita roturas en el producto. No apliques una presión excesiva en ninguna de las partes del producto. Evita impactos y caídas que puedan dañar el producto. Si el producto tiene un cable, no lo dobles y no lo estires con exceso de fuerza para no dañarlo.
  • Page 6 FRANÇAIS - MANUEL D'UTILISATEUR Lumière LED Sophia avec détecteur – BXTILED60B 1. Caractéristiques 1.1 Spécifications techniques Puissance : 3,2 W Entrée : 220-240 V / 50-60 Hz Batterie : Batterie au lithium Capacité de la batterie : 2.200 mAh Autonomie : 9 hours Flux lumineux : 230 lumens Température de couleur : 4.000 K...
  • Page 7 1. Détecteur de 4. Supports magnétiques mouvement et avec adhésif indicateur 5. Bouton d'allumage 2. Lumière LED 6. Port de charge USB-C 3. Corps en aluminium 1.4 Instructions d'utilisation de l'éclairage LED Sophia Appuyez sur le bouton latéral pendant 3 secondes pour allumer la lumière LED.
  • Page 8 Pour plus d'informations, contactez le vendeur ou les autorités locales chargées de la gestion des déchets. Deutsch - BENUTZERHANDBUCH Sophia LED-Licht mit Sensor – BXTILED60B 1. Eigenschaften 1.1 Technische Daten Leistung: 3,2 W Eingang: 220-240 V / 50-60 Hz Batterie: Lithium-Batterie Batteriekapazität: 2.200 mAh...
  • Page 9 Sensortyp: Bewegungssensor Sensorreichweite: 120° Erfassungsdistanz: 10 m Betriebstemperatur: -20ºC bis +45ºC Lebensdauer: 20.000 Stunden Schutzklasse: IP20 Ladeanschluss: USB-A zu USB-C Ladezeit: 4-5 Stunden Material: Weiß lackiertes Aluminium + ABS Abmessungen: 60 x 4 x 0,9 cm Gewicht: 231 g 1.2 Verpackungsinhalt 1 x LED-Licht mit Sensor 1 x USB-A-zu-USB-C-Ladekabel (50 cm) 2 x Magnetische Halterung mit Klebefläche...
  • Page 10 -Ladevorgang: Eine durchgehende rote Lampe leuchtet. -Ladung vollständig: Die durchgehende rote Lampe wechselt zu Blau. -Zu geringe Stromversorgung: Die roten und blauen Lampen blinken 6 Mal und das Licht schaltet sich aus. 2. Empfehlungen zu Sicherheit, Wartung und Verwendung Lesen Sie vor der Verwendung des Produkts alle mitgelieferten Unterlagen und Anweisungen.
  • Page 11 Behandlung der anfallenden Abfälle. Für weitere Informationen wenden Sie sich bitte an den Verkäufer oder die örtlichen Entsorgungsbehörden. ITALIANO - MANUALE D’USO Luce LED Sophia con sensore – BXTILED60B 1. Caratteristiche 1.1 Specifiche tecniche Potenza: 3,2 W Ingresso: 220-240 V / 50-60 Hz Batteria: Batteria al litio Capacità...
  • Page 12 1. Sensore di 4. Supporti magnetici con movimento e adesivo indicatore 5. Pulsante di accensione 2. Luce LED 6. Porta di ricarica USB-C 3. Struttura in alluminio 1.4 Come usare la luce LED Sophia Tieni premuto il pulsante laterale per 3 secondi per accendere la luce LED.
  • Page 13 con le mani bagnate. Conservare sempre il prodotto in un luogo asciutto e lontano dall'umidità. Tenere sempre il prodotto lontano da materiali infiammabili e non esporlo al fuoco, a fonti di calore o a temperature estreme. Quando il prodotto non è in uso, scollegarlo e conservarlo in un luogo pulito e asciutto, lontano da umidità...
  • Page 14 PORTUGUÊS - MANUAL DO USUÁRIO Luz LED Sophia com sensor – BXTILED60B 1. Características 1.1 Especificações técnicas Potência: 3,2 W Entrada: 220-240 V / 50-60 Hz Bateria: Bateria de lítio Capacidade da bateria: 2.200 mAh Autonomia: 9 horas Fluxo luminoso: 230 lúmens Temperatura da cor: 4.000 K...
  • Page 15 1. Sensor de 4. Suportes magnéticos movimento e indicador com adesivo 2. Luz LED 5. Botão de ligar 3. Estrutura de 6. Porta de carregamento alumínio USB-C 1.4 Como usar a luz LED Sophia Pressione o botão lateral por 3 segundos para ligar a luz LED. 1.5 Instalação da luz LED Sophia 1.
  • Page 16 3. Nota Legal Atlantis Internacional, S.L. declara que este produto cumpre com os requisitos essenciais e quaisquer outras disposições aplicáveis ou exigíveis pela Diretiva 2014/53/UE. funções características descritas neste manual baseiam-se em testes realizados pela Atlantis Internacional S.L. O utilizador é...
