STICKLAMP
Reading lamp for screens
USER MANUAL
BXLAMP02
Technical specifications:
Light Source: 27PCS warm white + 27PCS Day White Chips
Beam Angle: 120°
Working Voltage: DC5V USB Power Supply
Housing Material: ABS Housing+Transparent PC Cover
Control Type: 4-keys Dimming and CCT Controller
PCB Board: 255*6.2mm Double FR4 Board
Color temperature: Warm White:2800-3200K White:6000-6500K
Power: 5W Max
Installation: ABD Mounting Clip(0-90 degree adjustable)
Product size: 260 x 22 x 16.5mm
Package: Protection bag + Color box
Product weight: 82g
Illustration
3
4
5
6
Clip the top section
of monitor
1
2
7
LED
Lamp
Holding this to
put on or take o
the lamp
ABS Mounting Clip
Highlight Strips
Controller
Adjustment of color temperature
Brightness +
Brightness -
O /On
USB input
8
Note:
The material of the mounting clip is
black ABS material. Its unique
structure design is suitable for
di erent sizes, like 13.3/14/15.6 inches
and laptops of di erent thickness.
The recommended monitor thickness
would be no higher than 10mm.
Besides, the lamp body can rotate
90 degrees to adjust lighting area.

Advertisement

loading
Need help?

Need help?

Do you have a question about the STICKLAMP BXLAMP02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KSIX STICKLAMP BXLAMP02

  • Page 1 STICKLAMP Reading lamp for screens USER MANUAL BXLAMP02 Technical specifications: Light Source: 27PCS warm white + 27PCS Day White Chips Beam Angle: 120° Working Voltage: DC5V USB Power Supply Housing Material: ABS Housing+Transparent PC Cover Control Type: 4-keys Dimming and CCT Controller PCB Board: 255*6.2mm Double FR4 Board Color temperature: Warm White:2800-3200K White:6000-6500K Power: 5W Max...
  • Page 2 Product features: 1. Intelligent eye protection lamp for those who work or study on laptops. 2. High quality LED chips are in a dense row, which makes light be uniform and brighter. 3. Black ABS housing, light and convenient. Good texture. Gentle to your hands. 4.
  • Page 3 to unplug the product. • Do not wet the product. Keep it always in a dry place, away from humidity. • When not using the product, store it in a place free from dust, dirt, lint, liquids, etc. z• If water or other liquids enter the product interior, unplug it immediately from any attached power source or device it is connected to.
  • Page 4 KSIX SMART YOUR TECH BXLAMP02...
  • Page 5 STICKLAMP Lámpara de lectura para pantallas MANUAL DE USUARIO BXLAMP02 Especificaciones técnicas: Fuente de luz: 27PCS blanco cálido + 27PCS blanco luminoso Ángulo de apertura: 120° Potencia Alimentación: DC5V USB Material de la carcasa: Carcasa ABS +Funda transparente PC Tipo de mando: Mando 4 opciones para control de temperatura de color y brillo PCB: 255*6.2mm doble placa FR4 Temperatura de color: Blanco cálido:2800-3200K Blanco:6000-6500K Voltaje: 5W Max...
  • Page 6 Características: Instalación: 1. Saque la lámpara de la caja, abre la bolsa de protección y comprueba que el paquete esté completo. 2. Lea el manual de usuario. Desenrolle el cable, abra la pinza de sujeción y colóque con cuidado en el centro de la zona superior de la pantalla 3.
  • Page 7 Nota Legal Por medio de la presente Atlantis Internacional, S.L, declara que este producto cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/CE. Las funciones y características descritas en este manual se basan en pruebas realizadas por Atlantis Internacional S.L.
  • Page 8 KSIX SMART YOUR TECH BXLAMP02...
  • Page 9 STICKLAMP Lampe de lecture pour écrans GUIDE DE L'UTILISATEUR BXLAMP02 Spécifications techniques : Light Source : 27 LED blanc chaud + 27 LED blanc du jour Source lumineuse : 27 LED blanc chaud + 27 LED blanc du jour Angle du faisceau : 120° Tension : USB DC 5 V Matériau boîtier : Boîtier ABS + Couvercle PC transparent Type de commande : Commande à...
  • Page 10 Caractéristiques du produit : 1. Lampe de protection oculaire intelligente pour ceux qui travaillent ou étudient sur des ordinateurs portables. 2. Les LED de haute qualité sont réparties dans une rangée dense, ce qui rend la lumière uniforme et plus lumineuse. 3.
  • Page 11 Recommandations d’entretien • Nettoyez régulièrement le produit à l’aide d’un chi on sec. Veillez à ce que le produit soit éteint et/ou ne soit pas connecté lorsque vous le nettoyez. • Veillez à garder les connecteurs et/ou les ports du produit propres, sans poussières ni saleté, pour un fonctionnement correct.
  • Page 12 • Le coût final de ce produit comprend le coût de la gestion environnementale nécessaire au traitement approprié des déchets générés. • Pour en savoir plus, vous pouvez contacter le vendeur ou les autorités locales responsables de la gestion des déchets. KSIX SMART YOUR TECH BXLAMP02...
  • Page 13 STICKLAMP Leselampe für Bildschirme BEDIENUNGSANLEITUNG BXLAMP02 Technische Daten: Lichtquelle : 27 Stk. Warmweiße + 27 Stk. Tagweiße Chips Strahlwinkel: 120° Betriebsspannung : DC5V USB-Netzteil Material des Gehäuses : ABS-Gehäuse + transparente PC-Abdeckung Steuerungstyp : 4-Tasten-Dimmer und CCT-Controller PCB-Platte : 255 * 6,2 mm Doppelte FR4-Platte Farbtemperatur : Warmweiß: 2.800-3.200K Weiß: 6.000-6.500K Stromversorgung : 5W Max.
  • Page 14 Produktmerkmale: 1. Intelligente Augenschutzlampe für alle, die an Laptops arbeiten oder lernen. 2. Hochwertige LED-Chips sind in einer dichten Reihe angeordnet, wodurch das Licht gleichmäßiger und heller wird. 3. Schwarzes ABS-Gehäuse, leicht und praktisch. Gute Textur. Sanft zu Ihren Händen. 4.
  • Page 15 Wartungsempfehlungen • Reinigen Sie das Produkt regelmäßig mit einem trockenen Tuch. Das Produkt muss beim Reinigen vom Strom getrennt oder ausgeschaltet werden. • Halten Sie die Stecker und/oder Anschlüsse frei von Staub, Flusen usw., um unsachgemäße Anschlüsse zu vermeiden. • Vermeiden Sie es, das Gerät zu beschädigen. Legen Sie keine Gegenstände darauf und biegen Sie sie nicht zu stark.
  • Page 16 • Der Endpreis dieses Produkts beinhaltet die Kosten, die für die korrekte umweltgerechte Entsorgung der erzeugten Abfälle erforderlich sind. • Für weitere Informationen wenden Sie sich bitte an den Einzelhändler oder die für die Abfallwirtschaft zuständigen lokalen Behörden. KSIX SMART YOUR TECH BXLAMP02...
  • Page 17 STICKLAMP Lampada da lettura per schermo MANUALE UTENTE BXLAMP02 Informazioni tecniche Fonte di luce: 27PCS bianco caldo + 27PCS bianco giorno Angolo del fascio: 120° Alimentazione: USB DC5V Materiale alloggiamento: Alloggiamento in ABS + coperchio trasparente per PC Tipo di controllo: Interruttore CCT a 4 tasti per regolare la luminosità e gestire la lampada Scheda PCB: Doppia scheda FR4 255*6,2mm Temperatura colore: Bianco caldo: 2800-3200K Bianco: 6000-6500K Potenza : 5W Max.
  • Page 18 Caratteristiche prodotto: 1. Lampada intelligente per la protezione degli occhi per chi lavora o studia usando il PC. 2. I chip LED di alta qualità sono disposti in una fila densa, il che rende la luce uniforme e più intensa. 3.
  • Page 19 4. Per disinstallare la lampada, spegnere l'alimentazione, staccare il filo USB e togliere la clip. Consigli di manutenzione • Pulire regolarmente il prodotto con un panno asciutto. Il prodotto deve essere scollegato e spento quando viene pulito. • Tenere i connettori e/o le porte pulite da polvere, lanugine, ecc, per evitare connessioni improprie. •...
  • Page 20 KSIX SMART YOUR TECH BXLAMP02...
  • Page 21 STICKLAMP Lâmpada de leitura para monitores MANUAL DO UTILIZADOR BXLAMP02 Especificações Técnicas Fonte de Luz: 27PCS branco quente + 27PCS Chips de Dia Brancas Ângulo de Feixe: 120° Tensão de Trabalho: DC5V USB Fonte de alimentação Material Estrutura : ABS Alojamento + Tampa Transparente para PC Tipo di controllo: 4-chaves de Escurecimento e Controlador CCT Placa PCB: Quadro Duplo FR4 de 255*6,2mm Temperatura de cor: Branco quente:2800-3200K Branco:6000-6500K...
  • Page 22 Características do produto: 1. Lâmpada de proteção ocular inteligente para quem trabalha ou estuda em computadores portáteis. 2. Os chips LED de alta qualidade estão numa fila compacta, o que faz com que a luz seja uniforme e mais brilhante. 3.
  • Page 23 • Mantenha o produto sempre num lugar seco e longe da humidade. • Quando não use o produto, guarde-o num lugar limpo e seco, longe da humidade e da sujidade • Se entra agua no produto, desligue-o imediatamente de qualquer fonte de energía ou dispositivo ao qual esteja ligado.
  • Page 24 KSIX SMART YOUR TECH BXLAMP02 tlantis Internacional SL Crom 53, 08907 L'Hospitalet de Llobregat, Spain care@atlantistelecom.com...
