Spirit Slide Control
- Coal, Pebble, Deluxe Pebble, Log, Modular Coal
- Inset Live Fuel Effect Gas Fires
Installation and
Users Instructions
This product is not suitable for primary
heating purposes
These instructions should be read by the
installer before installation and then should
be handed to the end user when the
installation is complete.
This is an official requirement and is the
responsibility of the fitter of this
appliance.
Having installed the appliance, the installer
should take the necessary steps to ensure
that the user fully understands how to operate
the appliance and is also made aware of the
fire's basic cleaning and maintenance
requirements.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spirit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Legendfires Spirit

  • Page 1 Spirit Slide Control - Coal, Pebble, Deluxe Pebble, Log, Modular Coal - Inset Live Fuel Effect Gas Fires Installation and Users Instructions This product is not suitable for primary heating purposes These instructions should be read by the installer before installation and then should be handed to the end user when the installation is complete.
  • Page 2: Table Of Contents

    CONTENTS SECTION PAGE Notes for the Installer and End User Installation Requirements Installation Procedure Commissioning Technical Data Replacement Parts Trouble Shooting (GAS SAFE Engineer Only) 8 User Instructions Cleaning and Maintenance Ignition System Wiring Diagram Fire Front Specifications Coal Layout Instructions Pebble Layout Instructions Deluxe Pebble Layout Instructions Log Layout Instructions...
  • Page 3: Notes For The Installer And End User

    NOTES FOR THE INSTALLER AND END USER THIS APPLIANCE IS INTENDED FOR DECORATIVE PURPOSES This appliance has been designed, tested and manufactured to the European Standard EN509 relating to Decorative Gas Appliances and must be installed by a qualified GAS SAFE Registered Installer in accordance with the Gas Safety (Installation and use) regulations 1994 and all other relevant standards.
  • Page 4: Installation Requirements

    INSTALLATION REQUIREMENTS This appliance must only be installed in Great Britain. 1. This appliance is a natural gas appliance only and has been designed for use with the following applications: a) Class I - Conventional brick or stone chimney as used for a solid fuel fire with a cross-sectional dimension of 225mm x 225mm (9”...
  • Page 5: Installation Procedure

    INSTALLATION PROCEDURE 1. Carefully lift the appliance out of the packaging taking care not to damage the ceramic components in the separate carton. 2. Remove the magnetic trim and store on one side to prevent any damage. 3. Cut the foam sealing strip (in plastic bag supplied) to length and stick a continuous strip down the two sides and across the top of the radiant box.
  • Page 6: Commissioning

    INSTALLATION PROCEDURE CONTINUED ALTERNATIVE FIXING METHOD 112mm 112mm Where the drilling of the back panel is not practical, an alternative fixing method may be employed using the optional cable fixing kit provided. Drill four holes in the rear of the fireplace opening (Fig. 5). Securely fix the four eye bolts provided using suitable Rawl plugs.
  • Page 7: Technical Data

    TECHNICAL DATA Gas Type Natural Gas (G20) Cat I 2H Gas Connection Number of Injectors Injector size Stereomatic 070 Control Max Operating Temperature Inlet Pressure Cold 20 mbar Heat Input (Gross) 6.2 kW Weight 12 kg REPLACEMENT PARTS 1. Loose coals - The ceramic coals supplied with this appliance can be replaced at service intervals depending on their condition.
  • Page 8: Trouble Shooting (Gas Safe Engineer Only)

    TROUBLE SHOOTING (GAS SAFE ENGINEER ONLY) 1. The Piezo will not spark. Check: The battery If the electrode is cracked or broken - Replace pilot assembly. If the HT lead is shorting out on the burner body - Locate where the short is occurring, isolate and/or re-route the lead.
  • Page 9: User Instructions

    USER INSTRUCTIONS THIS APPLIANCE IS INTENDED FOR DECORATIVE PURPOSES. Please also familiarise yourself with the Notes for the Installer and End User on page 3. OPERATION AND CONTROLS It is most important that the operator of this gas appliance has fully read and understood all the operating, cleaning and maintenance procedures as laid out in these instructions.
  • Page 10: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Legend Gas Fires recommend that this appliance is serviced at regular 12 monthly intervals. The chimney or flue should also be checked regularly to ensure that all products of combustion are entering the flue and there is no excessive buildup of soot. It is the user’s responsibility to ensure that the appliance is kept in a clean serviceable condition.
  • Page 11: Ignition System Wiring Diagram

    IGNITION SYSTEM WIRING DIAGRAM Fig. 10A FIRE FRONT SPECIFICATIONS Fire fronts are now available in many different designs and finishes. The user can now choose their own particular style of fire front to suit their individual fireplace setting, providing the fire front complies with the following dimensions - Fire Front - (X) Max: 210mm...
  • Page 12: Coal Layout Instructions

    COAL LAYOUT INSTRUCTIONS It is very important that all the coals are used and arranged as shown in order to achieve the desired Burner Tray flame picture. It may be necessary to remove some or all of the coals to clean them at some time. Cleaning must only be done using a soft brush.
  • Page 13 COAL LAYOUT INSTRUCTIONS CONTINUED 5. Pick out the smallest two coals and lay to one side, lay the first row of four loose coals on top of the front coal. Ensure the back of the coals are resting on the coal bed and there are even gaps all round (Fig.
  • Page 14: Pebble Layout Instructions

    PEBBLE LAYOUT INSTRUCTIONS It is very important that all the pebbles are used and arranged as shown in order to achieve the Burner Tray desired flame picture. It may be necessary to remove some or all of the pebbles to clean them at some time. Cleaning must only be done using a soft brush.
  • Page 15 PEBBLE LAYOUT INSTRUCTIONS CONTINUED 4. Pick out the smallest two pebbles and lay to one side, lay the first row of four loose pebbles on top of the front coal. Ensure the back of the pebbles are resting on the fuel bed and there are even gaps all round (Fig.
  • Page 16: Deluxe Pebble Layout Instructions

    DELUXE PEBBLE LAYOUT INSTRUCTIONS It is very important that all the pebbles are used and arranged as shown in order to achieve the desired flame picture. Burner Tray It may be necessary to remove some or all of the pebbles to clean them at some time.
  • Page 17 DELUXE PEBBLE LAYOUT INSTRUCTIONS CONTINUED 4. Lay the first row of four loose pebbles on top of the front coal. Ensure the back of the pebbles are resting on the coal bed and there are even gaps all round (Fig. 30). 5.
  • Page 18: Log Layout Instructions

    LOG LAYOUT INSTRUCTIONS Main Fuel Bed It is very important that all the logs are used and arranged as shown in order to achieve the desired flame picture. It may be necessary to remove some or all of the logs to clean them at some time.
  • Page 19 LOG LAYOUT INSTRUCTIONS CONTINUED 4. Make any adjustments necessary to achieve even gaps as this will help in giving a well balanced flame picture and an even glow. After running the fire for 30 minutes, it may be necessary to adjust the logs with tongues.
  • Page 20: Modular Coal Layout Instructions

    MODULAR COAL LAYOUT INSTRUCTIONS Fuel Bed 1. Place the main fuel bed on to the middle section of the metal burner tray. It is important that the front edge of the fuel bed is located behind the burner strip (Fig. 43). Fig.
  • Page 21 MODULAR COAL LAYOUT INSTRUCTIONS CONTINUED 5. Finally check that all the coal pieces are ‘nested’ together correctly (Fig. 49). Fig. 49 It is very important that all the coals are used and arranged as shown in order to achieve the desired flame picture.
  • Page 22: Trouble Shooting (User)

    TROUBLE SHOOTING (USER) 1. The Fire will not light. Always check the battery first (page 10). Remove the brass fret and check the pilot area for soot. If soot is present remove all the loose coals and the front coal and thoroughly clean any debris in and around the pilot area.
  • Page 23: Product Warranty

    PRODUCT WARRANTY Thank you for purchasing our gas fire appliance. We are dedicated to providing high-quality products and excellent customer service. The following terms and conditions outline the details of our 5-year warranty: Warranty Coverage This warranty covers defects in materials and workmanship for a period of 5 years from the date of purchase, subject to the conditions outlined below.
  • Page 24: Important Warranty Information

    IMPORTANT WARRANTY INFORMATION Please retain these details for future reference Please complete this information Your Details Product Details Mr/Mrs/Miss/Ms. Model Name. Address: Serial Number: Town/City: County: Purchased from: Post Code: Telephone No: Installation Date: SERVICE RECORD Gas Safe No. Working Pressure Engineers Signature Date Service...
