  6. Installation and user instructions manual

Legendfires Spirit Installation And User Instructions Manual

Coal, pebble, deluxe pebble, log, modular coal, inset live fuel effect gas fires
Hide thumbs Also See for Spirit:
Table of Contents

Advertisement

Quick Links

Spirit Remote Control
- Coal, Pebble, Deluxe Pebble, Log, Modular Coal
- Inset Live Fuel Effect Gas Fires
Installation and
Users Instructions
This product is not suitable for primary
heating purposes
These instructions should be read by the
installer before installation and then should be
handed to the end user when the installation
is complete.
This is an official requirement and is the
responsibility of the fitter of this
appliance.
Having installed the appliance, the installer
should take the necessary steps to ensure
that the user fully understands how to operate
the appliance and is also made aware of the
fire's basic cleaning and maintenance
requirements.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spirit and is the answer not in the manual?

Questions and answers

Related Manuals for Legendfires Spirit

Summary of Contents for Legendfires Spirit

  • Page 1 Spirit Remote Control - Coal, Pebble, Deluxe Pebble, Log, Modular Coal - Inset Live Fuel Effect Gas Fires Installation and Users Instructions This product is not suitable for primary heating purposes These instructions should be read by the installer before installation and then should be handed to the end user when the installation is complete.

  • Page 3: Table Of Contents

    CONTENTS SECTION PAGE Notes for the Installer and End User Installation Requirements Installation Procedure Commissioning Technical Data Replacement Parts Remote Control Component Layout Trouble Shooting (GAS SAFE Engineer Only) 10 User Instructions Cleaning and Maintenance Fire Front Specifications Coal Layout Instructions Pebble Layout Instructions Deluxe Pebble Layout Instructions Log Layout Instructions...

  • Page 4: Notes For The Installer And End User

    NOTES FOR THE INSTALLER AND END USER THIS APPLIANCE IS INTENDED FOR DECORATIVE PURPOSES This appliance has been designed, tested and manufactured to the European Standard EN509 relating to Decorative Gas Appliances and must be installed by a qualified GAS SAFE Registered Installer in accordance with the Gas Safety (Installation and use) regulations 1994 and all other relevant standards.

  • Page 5: Installation Requirements

    INSTALLATION REQUIREMENTS This appliance must only be installed in Great Britain or Ireland. 1. This appliance is a natural gas appliance only and has been designed for use with the following applications: a) Class I - Conventional brick or stone chimney as used for a solid fuel fire with a cross sectional dimension of 225mm x 225mm (9”...

  • Page 6: Installation Procedure

    INSTALLATION PROCEDURE 1. Carefully lift the appliance out of the packaging taking care not to damage the ceramic components in the separate carton. 2. Remove the magnetic trim and store to one side to prevent any damage. 3. Cut the foam sealing strip (in plastic bag supplied) to length and stick a continuous strip down the two sides and across the top of the radiant box.

  • Page 7: Commissioning

    INSTALLATION PROCEDURE CONTINUED ALTERNATIVE FIXING METHOD Where the drilling of the back panel is not practical, an alternative 112mm 112mm fixing method may be employed using the cable fixing kit provided. Drill four holes in the rear of the fireplace opening (Fig. 5). Securely fix the four eye bolts provided using suitable rawl plugs.

  • Page 8: Technical Data

    TECHNICAL DATA Gas Type Natural Gas (G20) Cat 2H Gas Connection Number of Injectors Injector size Stereomatic 072 Control Max Operating Temperature Inlet Pressure Cold 20 mbar Heat Input (Gross) 6.2 kW Weight 12.5 kg REPLACEMENT PARTS 1. Loose coals - The ceramic coals supplied with this appliance can be replaced at service intervals depending on their condition.

  • Page 9: Remote Control Component Layout

    REMOTE CONTROL COMPONENT LAYOUT Upper fixing point Pressure test point Heat shield Pilot assembly Lower fixing point Controls Battery cover panel Fig. 8 In order to access: a. Pilot Assembly (including thermocouple) b. Controls It will be necessary to dismantle the burner tray. Please use the following procedure. 1.

  • Page 10: Trouble Shooting (Gas Safe Engineer Only)

    TROUBLE SHOOTING (GAS SAFE ENGINEER ONLY) SERVICING MUST ONLY BE CARRIED OUT BY A GAS SAFE ENGINEER. NOTE: Before undertaking any actions on the servicing, replace the batteries in the control and handset (if applicable) with new batteries. Faulty batteries will cause errors. ALWAYS CHANGE ALL OF THE BATTERIES TOGETHER. USE THE SAME MAKE AND TYPE (I.E MANUFACTURER AND MODEL TYPE).

  • Page 11: User Instructions

    USER INSTRUCTIONS Warnings A suitable guard may be required to take account of special hazards that exist in nurseries and other places where there are young children, aged or infirm persons. Curtains are not to be placed directly above the appliance. It is recommended that combustible materials are not placed directly above this appliance.
  • Page 12 USER INSTRUCTIONS Activity Light – flashes red when starting and stopping burner only. Illuminates when key pad is unlocked Button not used for operation Not used Decrease burner power Increase burner power Power button – for On/Off of burner Fig. 11 Starting the fire using the remote handset By holding the handset, the green unlock light should illuminate.
  • Page 13 USER INSTRUCTIONS Pairing a new handset if pairing broken Breaking a pairing on handset To reset the handset to factory conditions (to enable the handset to be paired again with the same or another fire for example), hold handset to unlock, press and hold pressed for at least 10-20 seconds the SET button. The green and red lights will start to flash .

  • Page 14: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Legend Gas Fires recommend that this appliance is serviced at regular 12 monthly intervals. The chimney or flue should also be checked regularly to ensure that all products of combustion are entering the flue and there is no excessive build up of soot. It is the users responsibility to ensure that the appliance is kept in a clean serviceable condition.

  • Page 15: Fire Front Specifications

    FIRE FRONT SPECIFICATION Fire fronts are now available in many different designs and finishes. The user can now choose their own particular style of fire front to suit their individual fireplace setting, providing the fire front complies with the following dimensions - Fire Front - (X) Max: 210mm Min: 190mm...

  • Page 16: Coal Layout Instructions

    COAL LAYOUT INSTRUCTIONS It is very important that all the coals are used and arranged as shown in order to achieve the desired Burner Tray flame picture. It may be necessary to remove some or all of the coals to clean them at some time. Cleaning must only be done using a soft brush.
  • Page 17 COAL LAYOUT INSTRUCTIONS CONTINUED 5. Pick out the smallest two coals and lay to one side, lay the first row of four loose coals on top of the front coal. Ensure the back of the coals are resting on the coal bed and there are even gaps all round (Fig.

  • Page 18: Pebble Layout Instructions

    PEBBLE LAYOUT INSTRUCTIONS It is very important that all the pebbles are used and arranged as shown in order to achieve the Burner Tray desired flame picture. It may be necessary to remove some or all of the pebbles to clean them at some time. Cleaning must only be done using a soft brush.
  • Page 19 PEBBLE LAYOUT INSTRUCTIONS CONTINUED 4. Pick out the smallest two pebbles and lay to one side, lay the first row of four loose pebbles on top of the front coal. Ensure the back of the pebbles are resting on the fuel bed and there are even gaps all round (Fig.

  • Page 20: Deluxe Pebble Layout Instructions

    DELUXE PEBBLE LAYOUT INSTRUCTIONS It is very important that all the pebbles are used and arranged as shown in order to achieve the desired flame picture. Burner Tray It may be necessary to remove some or all of the pebbles to clean them at some time.
  • Page 21 DELUXE PEBBLE LAYOUT INSTRUCTIONS CONTINUED 4. Lay the first row of four loose pebbles on top of the front coal. Ensure the back of the pebbles are resting on the coal bed and there are even gaps all round (Fig. 33). 5.

  • Page 22: Log Layout Instructions

    LOG LAYOUT INSTRUCTIONS Main Fuel Bed It is very important that all the logs are used and arranged as shown in order to achieve the desired flame picture. It may be necessary to remove some or all of the logs to clean them at some time.
  • Page 23 LOG LAYOUT INSTRUCTIONS CONTINUED 4. Make any adjustments necessary to achieve even gaps as this will help in giving a well balanced flame picture and an even glow. After running the fire for 30 minutes, it may be necessary to adjust the logs with tongues.

  • Page 24: Modular Coal Layout Instructions

    MODULAR COAL LAYOUT INSTRUCTIONS Fuel Bed 1. Place the main fuel bed on to the middle section of the metal burner tray. It is important that the front edge of the fuel bed is located behind the burner strip (Fig. 47). Fig.
  • Page 25 MODULAR COAL LAYOUT INSTRUCTIONS CONTINUED 5. Finally check that all the coal pieces are ‘nested’ together correctly (Fig. 53). Fig. 53 It is very important that all the coals are used and arranged as shown in order to achieve the desired flame picture.

  • Page 26: Guarantee

    GUARANTEE Your appliance is guaranteed for one year from proof of purchase. Should the appliance prove defective within that period we agree to repair or replace (at our discretion) the component or appliance provided that: 1. The user can produce a receipt for proof of purchase/installation. 2.
  • Page 28 Issue 11 - 16/01/18 Unit 404 Glenfield Park Business Centre Blakewater Road Blackburn Lancashire BB1 5QH Tel: 01254 695244 Fax: 01254 695255 Web: www.legend-fires.com Email: info@legend-fires.com...
