Bitstream ERIS-100 Quick Manual

10/100m ethernet fiber optic converter
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

ERIS-100 Quick Guide
https://bitstream.pl
ERIS-100
10/100M Ethernet Fiber Optic Converter
The software and complete instructions necessary to properly
configure BitStream's hardware can be downloaded using the
QR code or website link.
Websites:
https://bitstream.pl/oprogramowanie-instrukcje/
Password:
Bitstream2021@
1. About version meaning
ERIS-100-T-(PoE)-(NP)
Legend
1 - option available in PoE version
REV.
1.08
ERIS MANUAL -100
2025.02.28
1/6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERIS-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Bitstream ERIS-100

Summary of Contents for Bitstream ERIS-100

  • Page 1 ERIS-100 Quick Guide https://bitstream.pl ERIS-100 10/100M Ethernet Fiber Optic Converter The software and complete instructions necessary to properly configure BitStream's hardware can be downloaded using the QR code or website link. Websites: https://bitstream.pl/oprogramowanie-instrukcje/ Password: Bitstream2021@ 1. About version meaning ERIS-100-T-(PoE)-(NP)

  • Page 2: Front Panel Of The Device

    ERIS-100 Quick Guide https://bitstream.pl 2. Front panel of the device Figure 1: Device front panel and marking. Symbol Designation: 1. PE - Ethernet port connector; 2. LNK/ACT, SD, FEF - indicator lights; 3. FO - SFP optical port connector 4. N LNK, PWR - signal LEDs PWR - power connector;...
  • Page 3 ERIS-100 Quick Guide https://bitstream.pl Fig 3. Indicator lights Indicator LED designation: - N LNK - indicates that the electrical port of the remote device is properly connected; - Power connection indication; 2.2 Ethernet electrical interface status indication The Ethernet port is equipped with two indicator LEDs.

  • Page 4: Power Supply

    ERIS-100 Quick Guide https://bitstream.pl As an example SFP insert we recommend BTP-3103-L2CD model (155M, 20km, 1310 nm, duplex, DDMI). On the side of the unit, an eight-way ON/OFF two-position switch module is located to configure the converter. Fig 5. Side view of the device - configuration element Micro switches allow you to set the following parameters Fig.

  • Page 5: First Start-Up

    4. First start-up The ERIS-100 converter is ready for operation automatically after power supply is connected. When the power supply voltage is correctly connected, the LED indicating the power supply should light 5. User safety 5.1 E LECTROMAGNETIC COMPATIBILITY The devices have been designed on the basis of PN-EN 55022 class A, PN-EN-55024 standard.

  • Page 6: Data Transmission

    5.4 S ECURITY BITSTREAM devices have been designed in terms of safety and operation on the basis of PN-EN- 60950 standard. Configuration and installation of the device should be made by people with necessary authorizations after getting acquainted with the operation manual. The manufacturer is not responsible for any events resulting from not following the detailed operating and installation instructions.
