Bitstream ERIS-100 Quick Start Manual

Quick start manual, a detailed manual is on the enclosed CD or can be downloaded
from company's website www.bitstream.com.pl/en/
Fiber opical converter - Ethernet 10/100/Mbps
.1
Symbols designation:
1. PE – Ethernet port connector;
2. LNK/ACT, SD, FEF – Signalling LEDs;
3. FO – SFP optical port connector;
4. LP LNK, PWR – Signalling LEDs;
5. PWR – power connector;
.1.1
Designation of signaling diodes:
1 - LNK – indicator of correct connection on the optical port;
2 - SD – signal reception indicator on the optical port;
3 - FEF – Far End Fault – error signal reception indicator;
REV. 1.01
ERIS-100
T
OP VIEW OF THE DEVICE
1 2
Top panel of the device
Fig 1.

Signalling LEDs

1 2
Fig 2. Signalling LEDs
User Manual ERIS-100
3 4
3
5
2019.11.20 1/5
