8. UTP2 Technical Specification
Key features
Partial discharge detection
Advanced partial discharge
analysis
Audio output
Survey mode
Language support
Built-in self-test
Accessories
Physical
Size
Weight
Enclosure
Screen
Indicators
Controls
Connectors
Connector safety class
Headphones
TEV
Sensor
Measurement Range
Pass band
Resolution
Accuracy
Min. Level for Pulse Count
Interpretation
Allows measurement of partial discharge by electromagnetic and
acoustic methods in accordance with PD IEC/TS 62478:2016
Phase-resolved partial discharge (PRPD) display
Waveform display
Partial discharge signals transformed into audible range
Self-contained survey mode with workplan feature
Zip file output with self-contained analysis tools
English, Chinese, Spanish, Arabic, French, Russian, Portuguese,
Indonesian, German, Turkish, Korean, Vietnamese, Italian, Thai,
Polish, Malaysian, Czech, Swedish, Norwegian, Welsh
Tests hardware functionality on power-on or on request
Wide range of supported accessories
201 x 76 x 34 mm
0.44 kg
Self-coloured injection moulded plastic case
3.5" TFT resistive touchscreen
LED backlight
640 x 480 resolution
Charging indicator LED
LCD resistive touchscreen
Membrane Keypad (4x push-buttons)
External Ultrasonic Sensor
External Smart Sensor
3.5 mm stereo headphone socket
Micro USB port
All connectors are Extra-Low Voltage
Min. 16 ohms
Capacitive
0 – 60 dBmV
3 – 80 MHz
1 dB
±1 dB
10 dBmV
Integrated algorithm determines likely type of partial discharge or if
noise is present.
