3.15.6 Ad-hoc Measurement
If a survey is not in progress when the record button is pressed in any of the TEV, Cable PD, Ultrasonic or UHF
measurement screens the data is still captured. On completion of the record, the default survey information
fields are displayed to capture the measurement context data. This data is the same as entered when starting
a survey through the menu icon. Once this information has been entered, survey mode stays active ready for
further data to be recorded and added to the survey.
3.15.7 Survey Metadata Forms
As mentioned in the previous section, each survey requires the input of information about the substation the
survey is being conducted in. Some fields have populated lists of values to select from, with each having the
option to override by inputting a custom value, others allow only virtual keyboard input and a select few have
special behaviours.
Navigation through the forms is done using the left and right buttons on the menu bar or using the
corresponding physical buttons. The last form to be populated is indicated by the right hand button on the menu
bar changing to become a tick icon.
Pressing this will close the last form, save the entered information and a prompt will pop up to start the survey
in 'Guided Mode'. If 'Yes' is selected then you will be taken to details of the first measurement to be taken, in
preparation to take the measurement. If 'No' was selected, then the screen will return to the home menu ready
to start recording data. See section 3.15.12 for more detail on Guided Mode.
If a workflow is not being used, the default form fields used are set out below along with their behaviour:
Form 1
Name Job
Field Description
Job Number The job number of the survey, used by
many users to link a survey to a
contract or package of work
Engineer Name of engineer performing the
Name survey
Form 2
Name Substation
Field Description
Name Name
surveyed
Type Type of the substation being surveyed
of the substation
Behaviour
Pressing the input field will show the virtual
keyboard
Pressing the input field will show the virtual
keyboard
Behaviour
being Pressing the input field will show the virtual
keyboard
Pressing the input field will show a populated list
of substation types, with the option to enter a
custom value using the virtual keyboard
