UltraTEV Plus²
Operating Manual
Model No: UTP2
Document Version: V13.04.00
Date: 24 April 2025

Advertisement

loading
Need help?

Need help?

Do you have a question about the UltraTEV Plus2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EA Technology UltraTEV Plus2

Summary of Contents for EA Technology UltraTEV Plus2

  • Page 1 UltraTEV Plus² Operating Manual Model No: UTP2 Document Version: V13.04.00 Date: 24 April 2025...
  • Page 2 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Version History Date Version Author(s) Notes Gareth Devine April 2016 2388L011 Gareth Devine April 2016 2388L012 May 2016 2388L013 Gareth Devine August 2016 2388L014 Gareth Devine, Sion Hughes October 2016 2388L015 Gareth Devine November 2016 2388L016 Gareth Devine July 2017 2388L017...
  • Page 3 © EA Technology Ltd Apr 2025 EA Technology Limited, Capenhurst Technology Park, Capenhurst, Chester, CH1 6ES; Tel: 0151 339 4181 Fax: 0151 347 2404 http://www.eatechnology.com...
  • Page 4 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Safety Precautions and procedures FCC Warning Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 Do not operate the instrument or its accessories in an explosive atmosphere. Mains supply voltages are present within the battery charger. • The UTP2 contains no user serviceable parts, always return to EA Technology or your local distributor • for service and repair.
  • Page 6 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Contents General Description ..............................1 Non-Intrusive Detection of Partial Discharge Activity ..................1 Operating Instructions ............................... 3 UltraTEV Plus² Overview ........................... 3 ® Charging ................................. 4 Turning the UltraTEV ® Plus² On/Off ......................4 Self-Test ................................. 5 Notification Bar .............................
  • Page 7 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual UTP2 Technical Specification ..........................84 UHFR1 Technical Specification ..........................88 Wireless Phase Reference Specification ......................90 Sales and Service..............................92 Privacy Notice ................................92 Declaration of Conformity ............................93 Page iv...
  • Page 8 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual General Description The UltraTEV ® Plus² (UTP2) is a versatile hand-held tool used to easily detect and classify Partial Discharge (PD) in a wide range of electrical equipment. The UTP2 uses inbuilt TEV and Ultrasonic sensors and external accessories to detect the presence of potentially damaging PD in switchgear, cables and overhead line equipment.
  • Page 9 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual The most sensitive method of detection is using an airborne ultrasonic Microphone centred at 40 kHz. This method is very successful at detecting partial discharge activity provided there is an air passage between the source and the Microphone. Electromagnetic Discharge Activity When partial discharge activity occurs within high voltage switchgear, it generates electromagnetic waves in the radio frequency range which can only escape from the inside of the switchgear through openings in the...
  • Page 10 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Operating Instructions UltraTEV ® Plus² Overview TEV sensor Ultrasonic microphone Photo sensor Smart Ultrasonic accessory accessory port port Left button Right button Middle button Home button Figure 1 MicroSD card slot Audio out / headphone socket LED charging Micro USB indicator...
  • Page 11 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Charging Use the supplied USB cable to charge the UTP2 with the mains charger, in-car charger or from a standard USB. Micro USB charging port Charging UTP2 is charging UTP2 is fully charged For the quickest charging time, turn off the UTP2 during charging. Charging time is extended when connected to a USB port compared to the mains charger.
  • Page 12 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Self-Test During power up, the UTP2 performs a self-test on TEV, ultrasonic and Cable PD using the built-in test sources. The self-test is not a calibration check. During self-test, the ultrasonic sensor should be pointed away from sources of noise.
  • Page 13 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Temperature & Humidity The temperature and relative humidity reading is displayed on the notification bar only after connection of the Environmental Sensor. The Environmental Sensor is connected to the Smart Accessory Port on the left-hand side of the instrument. The connection of the accessory automatically starts the data collection with the latest reading being displayed in the notification bar at the top left of the screen.
  • Page 14 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Main Menu After powering up, the UTP2 will load up to the Main Menu as shown below. The Home Button can be used to navigate back to the Main Menu at any time. The TEV icon on the main screen will change to a Cable PD icon when a HFCT accessory is plugged in and a UHF icon when a UHF accessory is plugged in.
  • Page 15 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Measure Screen The Measure mode is common to both TEV and Cable PD. This mode displays TEV readings in dBmV (dB) or (if the HFCT accessory is connected) Cable PD readings in picoCoulombs (pC). To enter this mode, click the Measure icon P/Cycle –...
  • Page 16 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual This option is useful for distinguishing between whether a measured PD activity is a genuine discharge source or just noise. For example, genuine PD activity may manifest itself as a stable phase resolved plot which will occur at the same position with respect to phase angle cycle by cycle;...
  • Page 17 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.9.3 Histogram This Histogram mode displays the number of events registered (y-axis) for a given amplitude (x-axis). This measurement option is useful for determining if more than one discharge source is present; two distinct groups of bars on this chart could mean there are two sources of discharge at the respective dB (or pC) levels. The screen is also useful in positively identifying a genuine source of PD and assessing its pulse rate when there is a high pulse rate noise floor affecting the standard pulse per cycle calculation.
  • Page 18 This display is an easy to use software implementation of the TEV measurement interpretation guide produced by EA Technology using decades of experience. The original summary document giving an overview of the original guidelines for the interpretation of TEV measurements is included on the next page.
  • Page 19 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.10.1 TEV Interpretation Guide Page 12 of 94...
  • Page 20 The algorithm processes the data from the ultrasonic Microphone along with the phase reference signal, and looks for patterns within the data stream which experts at EA Technology have identified as typical indicators of partial discharge.
  • Page 21 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.11 Context Menu Pressing the Left Button whilst in TEV, Cable PD or Ultrasonic modes brings up the Context Menu as shown below. The Context Menu consists of a number of items with only those relevant to the current mode of operation visible at any time.
  • Page 22 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.11.2 Filters Select the filter icon to change the filter properties; this option is only enabled when in Cable PD Measurement Mode and enables noise to be filtered from the cable PD measurement. Select the desired filter properties, a tick should appear when a selection has been made (shown above). No Filter –...
  • Page 23 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual E field – This option selects the built-in E-field sensor as the source of Phase reference. The sensor detects the phase reference from the stray electric field within the substation. Wireless – This option selects the Wireless Phase Reference as the source for the Phase reference. The Wireless Phase Reference is wireless accessory for UTP2 which allow detection of Phase reference with Photo- sensor, E-Field, Rogowski coil and Mains.
  • Page 24 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual During a data capture the UTP2 monitors the phase lock to ensure a continuous sync is achieved. If the phase lock is lost at any time during a capture the unit displays a warning message on completion of the recording. Every attempt should be made to ensure a phase lock is present as the lack of this may affect the analysis of the data captured.
  • Page 25 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.12.1 System Settings Key Beep – allows the turning ON/OFF of the audible beeps when any of the buttons are pressed and • when an NFC tag is detected. The button toggles to a green colour when Key Beep is activated. Display Brightness –...
  • Page 26 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual • Auto Shutdown – this option can be used to Enable/Disable the Auto shutdown feature of the UTP2. After a defined period of push button inactivity, the UTP2 will display a warning message and then proceed to shut itself down to conserve power. The inactivity period can also be changed here as shown below.
  • Page 27 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual The Ultrasonic only contains a Red Level threshold setting. The Guided Mode Settings, allow you to select the default measurement screen to be taken to when needing to do a TEV UHF or Cable PD measurement. Each Measurement type will bring up a list of possible measurement screens, for example, TEV: Interpretation (Default) •...
  • Page 28 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual The About Wireless Phase Reference allows you to check Wireless Phase Reference Model Number, Hardware Version and Firmware Version of Wireless Phase Reference when connected to UTP2. Note: When Wireless Phase Reference is not connected to UTP2, the device information will be unavailable. Page 21 of 94...
  • Page 29 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.12.3 Wireless Settings This section allows the setting of the Substation 360 Base URL, Wi-Fi & NFC features of the UTP2. The S360 URL button will bring up the text editor to allow the user to update the URL to which the UTP2 will try to connect to.
  • Page 30 3.12.4 About The about screen displays a summary of the UTP2 components including both hardware and software version numbers. The display also provides details of EA Technology’s dedicated Product Support team should any further information be required. Page 23 of 94...
  • Page 31 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.12.5 In-field Firmware Upgrade Through the ‘About’ screen, the firmware of the UTP2 can be updated. To access the firmware update screen, press the update icon . The UTP2 can be updated in the field using either the web or a microSD card. To perfrom an update using the web, make sure you are connected to a wifi network and press the “Check Web for Update”...
  • Page 32 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual To update your UTP2 via the MicroSD card the image will initially need to be copied from the distribution media to the ‘updates’ folder on the MicroSD card. An SD to MicroSD adapter is supplied for use with laptops or PCs which have an built-in SD card reader.
  • Page 33 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.12.6 Reset Settings Reset All Users: This option removes all Substation 360 Users from the UTP2. This will include the Users information, Work Orders downloaded, the current state of the completed Surveys to be uploaded (this will not remove the surveys from the SD Card, just the ability to upload them to S360).
  • Page 34 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Line Frequency • 3.13 File Browser The File Browser screen can be used to manage files and folders stored on the UTP2’s microSD card. To access the file browser, click File icon on the Home screen. Upon opening the File Browser, the contents at the root of the memory card will be displayed.
  • Page 35 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.13.1 Screenshot The UTP2 allows the user to capture an image of the screen at any time. To initiate a capture, press both the left and right hand buttons simultaneously for two seconds. Once capture completes, a pop window will appear giving a preview of the screen capture. This preview can either be rejected by pressing cancel which discards the image and returns to normal operations or accepted which will move onto the file naming screen.
  • Page 36 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual The file name screen provides the opportunity to rename the file from the default as shown below. Selecting the tick in the bottom left hand corner of the image stores the file to the removable microSD Card. The files are stored at \data and can be verified through the file browser.
  • Page 37 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.14 Function Check The UTP2 function checker is designed to allow users to verify the functionality of their instrument using build- in test sources. The Function Check display option can be used to toggle these built-in test sources. To launch the Function Check display, press the Function Check icon on the Home screen.
  • Page 38 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15 Survey The UTP2 Survey mode is a powerful yet easy way to collect and store data from a range of assets. Data from TEV, Cable PD, Ultrasonic or UHF measurement modes can be recorded and stored with corresponding metadata linking the data and its associated context.
  • Page 39 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Save Language selection Open Undo/redo workflow workflow New workflow Advanced mode Metadata field selection Add new metadata group Asset entry Measurement selection Page 32 of 94...
  • Page 40 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.2 Creating a Workflow for an Existing Survey When not in Survey Mode, a Workflow can be created for an existing survey by connecting to the UTP2 via Hotspot or USB (see section 3.17). Click on Generate Workflow for each survey file that is saved on the UTP2. 3.15.3 Starting a Survey There are two ways to start a survey;...
  • Page 41 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.4 Select Workflow Recall workflow from substation tag Read substation tag Go to workflow list Select workflow Note: When using an NFC Tag to filter the Workflows, if an error occurs, all available workflows on the UTP2 will be shown.
  • Page 42 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Enter your unique job number, the substation and switchgear information will be filled in using the information from the Workflow. Capture background readings, if ‘yes’ was not selected when the workflow was created, this data will not be captured.
  • Page 43 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.6 Ad-hoc Measurement If a survey is not in progress when the record button is pressed in any of the TEV, Cable PD, Ultrasonic or UHF measurement screens the data is still captured. On completion of the record, the default survey information fields are displayed to capture the measurement context data.
  • Page 44 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Cable Type of cable being surveyed Pressing the input field will show a populated list Naming of cable types Form Name Switchgear Field Description Behaviour Manufacturer Manufacturer name Pressing the input field will show a populated list switchgear being surveyed of switchgear manufacturers, with the option to enter a custom value using the virtual keyboard...
  • Page 45 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Humidity Humidity read Pressing the input field will cause it to be Environmental Sensor populated with the current Humidity. The Temperature & Humidity sensor must be connected to do this. Condition These are Questions generated by the Potential Input Fields: Questions Workflow creator.
  • Page 46 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.9 Using the virtual keyboard The virtual keyboard allows custom text to be input. Characters can be input using the buttons on the layout, with additional characters and numbers available through the “123” button. Uppercase letters can be entered by pressing the arrow (between A and Z).
  • Page 47 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.11 Recording Data Once a survey has been started, data can be recorded from any TEV, Cable PD, Ultrasonic or UHF displays. The same data is recorded for TEV or Cable PD independent of which TEV/Cable PD screen is currently displayed. To record data, simply press the record icon visible on the menu bar, which will then start a 10 second period of data capture.
  • Page 48 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.12 Guided Mode Upon starting a Workflow or a Work Order, a prompt will pop up asking, start this survey in ‘Guided Mode’. Guided Mode is designed to help the user work through the workflow measurement by measurement, in the hopes to not miss anything and to move from measurement to measurement in an efficient manner.
  • Page 49 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual If a Survey is resumed/continued (Section 3.15.18), Guided Mode can used again to help complete anything missing, edit comments, or overwrite previous measurements. 3.15.13 Viewing Survey Progress The progress of a survey can be viewed at by navigating to the Survey menu then pressing ‘View Progress’. The view progress displays the list of measurements to be taken in the loaded Workflow.
  • Page 50 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Measurement Type • Ultrasonic VPIS Panel Names • This is generated from the Workflow While on the view progress screen, the left, centre and right button all have actions. Left Button • Return to the Survey Screen Middle Button •...
  • Page 51 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.15.15 Edit Survey Meta Data A surveys meta data can be edited at time while in ‘Survey Mode’. This action will mimic the same screens as when starting the Workflow. 3.15.16 Resume Guided Mode Any Survey can be resumed in Guided Mode by going back to the view progress screen and clicking the play button.
  • Page 52 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.16 NFC Functionality The UTP2 has a built-in NFC tag reader/writer that can program NFC tags when they are used for the first time and recall the information during a survey. Blank NFC tags are identical and can be programmed with substation asset information.
  • Page 53 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual NFC Antenna 3.16.2 Substation Tag Use one NFC tag per substation to hold all the information relative to the substation being surveyed. This tag can be installed anywhere in the substation. The following information is stored: Substation Name (up to 127 characters) Substation type...
  • Page 54 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Enter unique survey Enter substation name & Enter switchgear reference type information Take background readings Align the UTP2 centre The UTP2 will beep once to button with the NFC tag indicate a tag has been detected, followed by two beeps indicate successful tag write...
  • Page 55 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Successful scan Substation information added to survey Page 48 of 94...
  • Page 56 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.16.5 Asset Tag We suggest two NFC tags per panel, one on the front and one on the rear. The asset tag will store the following information required in the Metadata screen of Survey mode: Asset Name (up to 127 characters) Panel Number (up to 127 characters)
  • Page 57 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.16.7 Reading an Asset Tag Whenever the record option is used in Survey mode and the measurement ‘Metadata’ screen is displayed, a tag read is possible. Press the centre button or NFC The UTP2 will beep once to Data will populate asset icon to trigger a scan indicate a tag has been...
  • Page 58 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.17 Reviewing Results Data collected during Survey mode or though ad-hoc recording is stored on the UTP2 MicroSD card. To facilitate viewing of the data, the UTP2 provides four methods of connection. Hotspot – Allows direct connection via the UTP2 personal hotspot to a Wi-Fi enabled device. •...
  • Page 59 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.17.2 Wi-Fi Connection 1. Go to Main Menu, Settings, Wireless Settings and enable Wi-Fi. 2. Select Network Connect, choose your network from the list and connect. 3. Once connected, go to Network Status and make a note of the IP address. 4.
  • Page 60 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual The MicroSD card will contain a separate .zip file (compressed folder) for each survey and ad-hoc measurement undertaken. Inside each folder there is an html page named ‘index.html’. Extracting the zip file and then opening the ‘index.html’ file inside this folder will direct you to the analysis pages. 3.17.5 Data Analysis Screens The UTP2 has a web interface for analysing data captured by the instrument.
  • Page 61 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.17.6 TEV & Cable PD Analysis Screen Both TEV and Cable PD recorded data share the same suite of analysis screens. Once a TEV or Cable PD measurement has been selected from the index page a new tab will open in the browser displaying the analysis page corresponding to the measurement selected.
  • Page 62 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 3.17.7 Ultrasonic Analysis Once an ‘Ultrasonic’ measurement has been selected on the index page, a new tab will open in the browser with the analysis page corresponding to the measurement selected. The metadata section will be displayed to the left side of the page, and the ‘Play’...
  • Page 63 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Detecting Partial Discharge using the UltraTEV ® Plus² Due to the tri-sensor capability, the UTP2 is able to detect Partial Discharge activity on the surface of insulation using Ultrasonic detection, internal to insulation by measuring TEV signals and in cables and cable accessories using the HFCT accessory.
  • Page 64 Settings icon in any of the Cable PD measurement screens, until the Cable PD icon is displayed and select the correct Cable PD accessory. EA Technology HFCTs are designed to be installed by suitably competent operators on cable earth/ground straps which are suitably and efficiently connected to earth/ground to maintain safety.
  • Page 65 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Switch gear Insulation plug housing Earth cable Earth cable RFCT/HFCT RFCT/HFCT Bottom view Side view 4.2.2 Measuring PD in cables Switch on the UTP2 and wait until home menu is displayed. If the conditions set out above are met, install the HFCT around the earth strap of the cable under test.
  • Page 66 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Ultrasonic Measurement The UTP2 is equipped with a built-in ultrasonic sensor which can be used to detect the acoustic emissions of surface partial discharge activity. External ultrasonic sensors are also available to use with the UTP2 allowing use in outdoor compounds, on sealed assets or in hard to reach places.
  • Page 67 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.3.3 Measuring Ultrasonic with the UltraDish The UltraDish provides a means of detecting discharge sources at a distance. It comprises a transparent parabolic reflector that focuses the ultrasonic sound on to a sensor mounted at the focus point of the reflector. The UltraDish gives an effective increase in gain compared to the built-in sensor allowing discharges to be detected at much greater distances such as insulator strings on overhead assets.
  • Page 68 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.3.4 Measuring Ultrasonic using the Flexible Sensor The Flexible Sensor provides a means of reaching inaccessible parts on the switchgear. The sensor is mounted at the end of a flexible goose-neck which allows the angle of the sensor to the handle to be adjusted. This allows the user to make measurements where it would be difficult to use the built-in sensor and still be able to read the display.
  • Page 69 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.3.5 Measuring Ultrasonic using the Ultrasonic Contact Probe The Ultrasonic Contact Probe (UCP1) is designed to detect Partial Discharge (PD) in sealed chambers. It should be used if there is no direct path between the PD source and instrument sensor. However, it must not be used if the tank containing the expected PD source is separated with another layer.
  • Page 70 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Ultrasonic Contact Probe The Ultrasonic Contact Probe (UCP1) is clamped on to the area of interest using the magnets surrounding the sensor plate. Any air gap between the sensor head and measurement point will effectively attenuate signals to a level where even strong discharges will not be detected.
  • Page 71 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual A rough or uneven surface will drastically decrease the amount of signal being transferred to the sensor head. UCP1 Dust ingress between the UCP1 sensor head and the asset surface. The following images present some examples of how unwanted signals may be introduced during the PD detection process when using the Ultrasonic Contact Probe.
  • Page 72 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual UHF Measurement The UHF Receiver (UHFR1) is an accessory for the UltraTEV ® Plus (UTP2) which allows Radio Frequency Interference (RFI) from partial discharge (PD) sources to be detected in the Ultra High Frequency (UHF) region. Partial discharge detection using UHF is particularly relevant in outdoor switchyards, when used with a suitable antenna, such as the UHF Directional Antenna (UHFDA1).
  • Page 73 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual The UHFR1 includes narrowband and wideband modes which can be selected by software. In narrowband mode, the signal is amplified by an adjustable gain and filtered to an adjustable frequency. In wideband mode, the full bandwidth of the signal is received by the UTP2 at all times. NARROWBAND Adjustable tuning...
  • Page 74 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.4.2 Assembly Connect an appropriate antenna or sensor to the Signal connector of the UHFR1. Antennas can be connected either directly or using a coaxial cable. • • The Signal Connector is a BNC connector. Push the sensor or cable onto the Signal Connector then twist clockwise one quarter turn.
  • Page 75 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.4.3 Operation Once the UHFR1 is connected, access the UHF functionality by pressing the UHF icon from the UTP2 home screen. The normal TEV measurement screens are available for use in UHF mode. • In addition, there is also a 3D Phase Plot screen and a Spectrum screen •...
  • Page 76 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.4.6 Spectrum Screen The Spectrum Screen shows the peak power received by the UHFR1 over its full tuning range. The tuning frequency is quickly swept from 50 MHz to 1000 MHz. • • The peak power received is plotted. In Single Trace mode, each time a new sweep is started, the previous sweep is shown in grey and the •...
  • Page 77 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.4.7 Adjusting the Mode, Gain and Tuning Frequency To adjust the UHF Mode, Gain or Tuning Frequency, press the Context Settings button. This will display the Context Settings menu showing the most appropriate settings for the current operating mode. To switch between Narrowband and Wideband modes, press the •...
  • Page 78 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.4.9 Persistence Level On the Phase Plot and Histogram screens, it is possible to control the persistence of the display. To access this setting, press the Context Settings button. It may be necessary to press the button more than once to scroll through different settings pages until the Persistence control is shown.
  • Page 79 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 4.4.12 Taking Measurements With the sensor of choice and the screen of choice, move the sensor around the asset, tilting it through 90 degrees looking for the highest levels. When you find the highest levels, adjust the gain so the signal is clear and neither red arrow is indicated.
  • Page 80 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Substation 360 What is Substation 360 Substation360 (S360) is an intelligent, centralized asset condition knowledge platform, for hosting a range of data types. It is a gateway for instruments to submit that data, and a website for configuration and analysis of the data.
  • Page 81 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 5.2.3 This is a 4-digit Personal Identification Number (PIN). The first time entering this PIN the user will have to enter it twice and both times the PIN must match. The PIN set cannot be changed at a later date. After a successful login, any subsequent login attempt by this user can be done using this PIN.
  • Page 82 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 5.3.2 Substations This screen lets a user search for a substation and download an appropriate workflow. Enter the first few letters of the substation name, then press the tick button. Substation 360 will return a list of matching substations. The list is scrollable.
  • Page 83 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 5.3.3 Upload This screen will display a list of completed Surveys to be uploaded from UTP2 to Substation 360. The middle button while on this screen is to ‘Auto Upload’, clicking this will start to upload all the Surveys. Each Survey shown in the list can be uploaded individually by selecting the survey and clicking the right button.
  • Page 84 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 5.4.1 Work Orders The Work Orders screen while in offline mode will only display the Work Order already downloaded and syncing Work Orders is disabled. It is still possible to view and complete previously downloaded Work Orders. 5.4.2 Upload Surveys The Upload button will not be displayed while in offline mode.
  • Page 85 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Starting a Work Order 5.5.1 Work Order Detail Screen This screen shows the user the details of the selected Work Order. This screen is scrollable, when there is too much information to be shown on the screen it will continue below. The details shown: Label Type...
  • Page 86 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual All data stored in the user’s directory can be downloaded again from S360. In-case anything is deleted from settings or the ‘File’ view screen no data is lost. All completed Work Orders or Surveys are still stored in the same location and are not deleted when removing S360 Users.
  • Page 87 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 6.1.3 Phase-reference source LEDs Photo: This option selects the photo-sensor located on the front upper section of the Wireless Phase Reference (see label) as the source of the Phase reference. The photo-sensor requires line of sight to a mains frequency light source such as fluorescent fitting.
  • Page 88 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 6.1.5 Auto Power-Off Feature To preserve battery, the UTP2-WPR will auto power-off after 15 minutes when it is not connected to a Wi-Fi network and the charger is not plugged in. 6.1.6 Buzzer The UTP2-WPR features a built-in buzzer that is activated 1 minute after connection to the UTP2 is lost. This is to remind the user to retrieve the UTP2-WPR after testing and ensure it is not left behind.
  • Page 89 3 months to at least a 50% state of charge and ensure that it is stored in a cool and dry environment. The UTP2-WPR contains no user serviceable parts, always return to EA Technology or your local distributor for service and repair.
  • Page 90 Waste electrical and electronic equipment directive (WEEE) EA Technology is a member of an approved compliance scheme as defined by the WEEE directive. When an EA Technology product reaches the end of its operational life, it must be recycled by a licensed waste management operator or returned to EA Technology for recycling.
  • Page 91 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual UTP2 Technical Specification Key features Partial discharge detection Allows measurement of partial discharge by electromagnetic and acoustic methods in accordance with PD IEC/TS 62478:2016 Advanced partial discharge Phase-resolved partial discharge (PRPD) display analysis Waveform display Audio output Partial discharge signals transformed into audible range Survey mode Self-contained survey mode with workplan feature...
  • Page 92 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Ultrasonic Sensor Ultrasonic microphone Measurement Range -7 – +71 dBµV Resolution 1 dB Accuracy ±1 dB Transducer Sensitivity -65 dB (0 dB = 1 volt/µbar rms SPL) Transducer Centre Frequency 40 kHz Transducer Diameter 16 mm Classification Integrated algorithm discriminates between partial discharge and noise.
  • Page 93 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Phase reference Sources Lighting (Photo sensor) Electric field (High-Z sensor) Manual Frequency range 50 Hz ± 1%, 60 Hz ± 1% Power supplies Internal Batteries 3.7V, rechargeable Lithium-Ion Typical Operating Time Approx. 8 hours Battery Conservation Automatic shutdown after 5 minutes of inactivity (configurable) Charging Time Approx.
  • Page 94 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Radio ETSI EN 300 328 V2.2.2 (July 2019) (Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques; Harmonised Standard covering the essential requirements of article 3.2 of Directive 2014/53/EU) ETSI EN 300 330 V2.1.1 (Feb 2017) (Short Range Devices (SRD);...
  • Page 95 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual UHFR1 Technical Specification Physical Size 81 x 40 x 35 mm Weight 0.1 kg Enclosure Aluminium Indicators None Controls None Connectors 1x BNC antenna port 1x LEMO (UltraTEV ® Plus connection) Environmental Operating Temperature 0 – 55 degrees C Humidity 0 –...
  • Page 96 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual UHF Measurement - Wideband Measurement range -61 – -1 dBm Bandwidth 5 – 3300 MHz Accuracy ±2 dB Compliance Electromagnetic EN 61326-1:2013 (Electrical equipment for measurement, control compatibility (EMC) and laboratory use – EMC requirements. General requirements.) EN 61000-6-2:2019 (Electromagnetic compatibility.
  • Page 97 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 10. Wireless Phase Reference Specification Physical Size 115*118*50mm Weight 200g Enclosure Injection moulded plastic case Connectors 1x GCS1 Current Sensor (for a cable of 1.5m in length) 1x Power Barrel connector Mounting Mechanisms Freestanding Magnets in feet to attach to any magnetic surface. Velcro Strap to wrap around cables (up to 100mm diameter) Environmental Operating Temperature...
  • Page 98 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Output Voltage 9VAC Power Rated Environment -10 To 40 degrees C, 0-90%RH Cable Length Input: 2.0m / Output: 1.8m Connectivity Wireless Wi-Fi (IEEE 802.11) – Connecting to the UTP2 Frequency: 2.4 GHz Maximum Power: +19.97 dBm Model Number: ESP32-C3-WROOM-02 Antenna: PCB Antenna, 3.42dBi Certificate Number: E1177-210909...
  • Page 99 If any errors or omissions are noticed, please notify: product-support@eatechnology.com 12. Privacy Notice EA Technology collects usage information from the UltraTEV Plus² to better understand how devices are used in the field. This helps us with our mission to continuously improve our products.
  • Page 100 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual 13. Declaration of Conformity Hereby, EA Technology declares that the equipment described in this document is in compliance with EU Directive 2014/53/EU, UK Statutory Instrument 2017 No. 1206, and all other applicable EU Directives and UK Statutory Instruments.
  • Page 101 2388-MANUL-V13.04.00-UltraTEV Plus² Operating Manual Accessories and Options Part Kit 1 Kit 2 Kit 3 Kit 2 Upgrade Kit 3 Upgrade UltraTEV Plus ® Mains Charger Car Charger USB Lead 8GB MicroSD & SD adapter Environmental Sensor Stylus x 2 NFC Starter Pack Neckband Headphones Ultrasonic Contact...
  • Page 102 Safer, Stronger, Smarter Networks EA Technology Limited t +44 (0) 151 339 4181 Capenhurst Technology Park e sales@eatechnology.com Capenhurst, Chester CH1 6ES www.eatechnology.com...
