2.Printing Specification

1.Trim Size (Format)

2.Printing Colors

* Cover :

* Inside :

3.Stock (Paper)

* Cover :

* Stock :

4.Printing Method :

5.Bindery :

6.Laguage :

7.Number of pages :

"This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,

Details should be followed Eco-SCM management standard[LG(56)-A-2524].

Especially, Part should be followed and controlled the following specification.

Note

(1)Eco-hazardous substances test report should be submitted

when Part certification test and First Mass Production.

(2) Especially, Don't use or contain lead(Pb) and cadmium(Cd) in ink.

3. Special information

4. Change

14/8/2006

Rev.No.

DD/MM/YY

BRAND

21FB3RB-LH

Product Name

Size A5 (210 mm. X 297 mm.)

Black

Wood free pager 60 GSM

Off-Set

Stiching

ENG

32 Pages

212903

Signature

Change No.

MO. T, add circuit diagram,some model sentence

PIC

COS

Chatchai A.

Somphop P.

Part No.

38289VA0521T

06/08 REV01

Change Content

Table of Contents

Need help?

Do you have a question about the RP-21CC25 and is the answer not in the manual?

Questions and answers

Summary of Contents for LG RP-21CC25

Page 1 6.Laguage : 32 Pages 7.Number of pages : “This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level, Details should be followed Eco-SCM management standard[LG(56)-A-2524]. Especially, Part should be followed and controlled the following specification.
Page 2 Color Television OWNER'S MANUAL MODELS : RP-21CC25 21FX4AL RP-21FB75 21FX4AL-LD RP-21FC45 21FB3RB-LH RP-21FD15 RP-21FD16 RP-21FD35 Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service.
Page 3: Safety Precautions
Safety Precautions WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK). NO USER-SERVICEABLE PARTS IN SIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Page 4: Table Of Contents
CONTENTS Description of controls ....................4 ~ 6 Basic TV operation ......................7 Turning on/off the TV .....................7 Selecting the on screen language .................7 Memorizing Channels ....................8 Memorizing the Channels by AUTO PROGRAM ............8 Memorizing the Channels by MANUAL PROGRAM .............9 Selecting the Channel ....................9 Adjusting the Volume .....................9 Various function .......................10 Setting the Clock ......................10...
Page 5: Description Of Controls
Description of controls 1. POWER BUTTON (or ON/OFF, Refer to "Turning on/off the TV". NOTE: Power line lives even when the power is off. 2. NUMBER BUTTONS To select the desired channel directly. 3. APC (Auto Picture Control) BUTTON To adjust the factory preset pictures corresponding to the lighting around.
Page 6 MUTE POWER POWER MUTE TV/VIDEO APC CAPTION MENU FCR SLEEP MEMORY EYE/ AUTOPRG. /ERASE REVIEW PICTURE TV/VIDEO ENTER MEMORY EYE/ AUTOPRG. ENTER /ERASE REVIEW SOUND PICTURE TURBO MEMORY EYE/ AUTOPRG. /ERASE MEMORY EYE/ AUTOPRG. /ERASE REVIEW WIDE/ZOOM PICTURE REVIEW MTS PICTURE 14.
Page 7 ON/OFF MENU OK VIDEO L/MONO AUDIO 1 19 20 4 22 23 22.AUDIO (or AUDIO-L/R)/VIDEO IN SOCKETS (AV or AV2) (some models) Connect the audio/video out sockets of external equipment to these sockets. 23.HEADPHONE SOCKET (some model) Connect the headphone plug to this socket.
Page 8: Basic Tv Operation
Basic TV operation Before operating your TV, make sure the following instructions have been completed. • Your TV has been connected to an antenna or a cable system. • Your TV has been plugged in a power outlet. • In this manual, the OSD (On Screen Display) may be different from your TV’s because it is just an example to help you with the TV operation.
Page 9: Memorizing Channels
Basic TV operation Memorizing Channels This is the function to memorize all the active channels in your area before you can use the TV. There are two ways of memorizing channels. You can use either. One is called AUTO PROGRAM and the other is called MANUAL PROGRAM. In AUTO PROGRAM the TV will memorize the channels in ascending order.
Page 10: Memorizing The Channels By Manual Program
Memorizing the Channels by MANUAL PROGRAM Using the MEMORY/ERASE button You can conveniently perform MANUAL PROGRAM using the MEMORY / ERASE button on the remote control. ++CATV+95+Memory 1. Press the or NUMBER buttons to select the channel number you want to memorize or erase. 2.
Page 11: Various Function
Various function Setting the Clock Before setting the on/off timer, first you should set the current time. Clock __:__+AM Clock 1. Press the MENU button and then button the until the menu is Off_timer displayed as shown right. _timer 2. Press the and then button to select Clock...
Page 12: Setting The Sleep Time
Setting the Sleep Time You don't have to remember to switch the TV to standby mode before you go to sleep. The sleep timer automatically turns the TV off after the preset time elapses. Press the SLEEP button to select the desired sleep time. Each time you press this button, the sleep time is displayed one by one as shown below.
Page 13: Key Lock
Various function Key Lock Language The TV can be set so that the remote control is needed to control it. Input This feature can be used to prevent unauthorized viewing. Key+lock Key+lock Caption+ Auto+demo 1. Press the MENU button and then button the until the menu is displayed as shown right.
Page 14: Favorite Channel Memory
Favorite channel memory Favorite channel memory is a convenient feature that lets you quickly scan up to five channels of your choice without having to wait for the TV to scan through all the in-between channels. Auto+prog. 1. Press the MENU button and then button the until the menu is Manual CATV++95...
Page 15: Picture Control
Picture control Enjoying the Eye Function (some models) The set will automatically adjust the picture according to the Magig+eye surrounding conditions with the display Magic eye Contrast Brightness Color 1. Press the EYE button on the remote control. Sharpness Stop:EYE The display Magic eye appears and the picture is adjusted.
Page 16: Sound Control
Sound control Enjoying the Stereo/SAP Broadcast (some models) This TV set can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program, as the system to be transmitted one additional sound signal as well as the original one.
Page 17: Avl (Auto Volume Leveler)(Some Model)
Sound control AVL (Auto Volume Leveler)(Some models) AVL automatically keeps on an equal volume level even if you change channels. DASP Balance Using the MENU Button Treble 1. Press the MENU button and then button the until the menu is Bass displayed as shown right.
Page 18: Closed Caption Function (Some Models)
Closed caption function (some models) Closed captioning is a process which converts the audio portion of a television program into written words, which then appear on the television screen in a form similar to subtitles. Closed captions allow viewers to read the dialogue and narration of television programs. Using Closed Captions Captions are the subtitles of the dialogue and narration of television programs.
Page 19: Closed Caption Function
Closed caption function Using the Text Function Text services give a wide variety of information on all kind of subjects (ex. captioned program lists, weather forecasts, stock exchange topics, news for hearing-impaired---) through the full TV screen. But not all stations offer text services, even though they might offer captioning.
Page 20: Antenna Connections
Antenna Connections Combination VHF/UHF Antennas 300 ohm Flat Wire TV rear 300 ohm Flat Wire 75 ohm 75 ohm Antenna Coaxial Jack Cable 300 to 75 300 to 75 75 ohm ohm Adapter ohm Adapter CATV Cable Connecting an Outdoor Antenna For the best reception, we recommend you use an outdoor antenna.
Page 21: Connection Of External Equipment (Some Models)
Connection of external equipment (some models) You can connect additional equipment, such as VCRs, camcorders etc. to your set. Here shown may be somewhat different from your set. These are an example drawing of typical jack layout. COMPONENT DVD INPUT (480i) AV VIDEO (L/MONO) AUDIO(R) AUDIO...
Page 22: Vcr Recording
Note: In some mono models, when the input jacks on the front panel and back panel are connected to external equipments at the same time, the input jacks on the front panel have priority over the input jacks on the back panel of the TV. Connecting the S-VHS VCR (some models) 1.
Page 24: Connecting Dvd Player (Some Models)
Connecting DVD player (some models) • Connect component DVD inputs to Y, P (480i) and audio IN to audio(L/R) ports. • Note: This TV is programmed to remember which mode it was last set to, even if you turn the TV off. 1.How to connect <...
Page 33: Troubleshooting Check List
Troubleshooting check list SYMPTOMS No power No picture or sound Poor picture but good sound Poor reception Lines in picture Ghosts (multiple images) Remote control does not work. Cannot tune desired channel. CHECK THESE THINGS Is power cord plugged in? Is television turned on? Check batteries in remote control.
