La Cara del Futuro Televisor a color MANUAL DEL USUARIO Por favor, lea detenidamente este manual antes de poner en funcionamiento su televisor. Conserve el manual para futuras consultas. Anote el número de modelo y serie del aparato. Anote la información de la etiqueta ubicada en el panel posterior, su distribuidor se la pedirá...
Page 2
PRECAUCIONES DE SEGURIDAD ADVERTENCIA : PARA REDUCIR EL RIESGO DE CHOQUE ELECTRICO, NO EXPONGA ESTE PRODUCTO A LA LLUVIA O LA HUMEDAD. PRECAUCION : PARA REDUCIR EL RIESGO DE CHOQUE ELECTRICO, NO RETIRE LA CUBIERTA POSTERIOR. NO REEMPLACE PARTES DENTRO DEL TV. REFIERASE AL PERSONAL DE SERVICIO CAPACITADO.
TABLA DE CONTENIDO DESCRIPCION DE LOS CONTROLES .................4 ~ 6 FUNCIONAMIENTO BASICO DEL TELEVISOR ...............7 Encendido / Apagado del TV ..................7 Selección del Idioma en la pantalla ................7 Memorización de Canales .....................8 Memorizando los canales por medio de la PROGRAMACION AUTOMATICA ....8 Memorización de los Canales por medio de la PROGRAMACION MANUAL .....9 Selección de Canales ......................9 Ajuste del volumen ......................9...
7. BOTONES DE LA VIDEO GRABADORA (VCR) SIZE SWAP SELECT Controlan un magnetoscopio LG. STILL POSITION CH.SEARCH 8. BOTON SLEEP Para fijar el tiempo de apagado, si desea dormir. A.PROG MEMORY/ERASE 9. BOTON EYE (Algunos modelos) Para activar o desactivar la función de Ojo Mágico.
Page 5
13. BOTON TV/VIDEO Para seleccionar el modo TV, VIDEO o COMPONENTE. Enciende el televisor desde el modo en POWER espera. MUTE 14. BOTON MENU Despliega en la pantalla los menus uno a uno. 15. BOTON ENTER ( • Para memorizar el Menú ajustado. •...
Page 6
DESCRIPCION DE LOS CONTROLES sta es una presentación simplificada del panel frontal. TV/VIDEO MENU POWER STAND BY STAND BY TV/VIDEO MENU ON/OFF 2 20 21 13 14 20 21 13 14 TV/VIDEO MENU STAND BY ON/OFF ON/OFF TV/VIDEO MENU 20 21 22 20 13 14 TV/VIDEO MENU...
FUNCIONAMIENTO BASICO DEL TELEVISOR Antes de poner a funcionar su televisor, asegúrese que las siguientes instrucciones se han cumplido. • Su TV ha sido conectado a un sistema de antena o cable. • Su TV ha sido conectado a un tomacorriente. •...
FUNCIONAMIENTO BASICO DEL TELEVISOR Memorización de Canales Esta es la función para memorizar todos los canales activos en su área antes de utilizar el TV. Hay dos maneras de memorizar los canales. Usted puede utilizar cualquiera. Una es la PROGRAMA AUTO y la otra es la PROGRAMA MANUAL.En la PROGRAMA AUTO, el televisor memorizará...
Memorización de los Canales por medio de la PROGRAMACION MANUAL Utilización del botón MEMORY/ERASE Usted puede realizar convenientemente la PROGRAMACION MANUAL utilizando el botón de MEMORY/ERASE en el control remoto. ++CATV+++95+++Memoria 1. Presione el botón o botones NUMERADOS para seleccionar el canal deseado.
FUNCIONES VARIAS Fijación de la Hora Antes de fijar el encendido y apagado del temporizador, primero tiene Temporizador que fijar la hora actual. __:__+AM Reloj Reloj 1. Presione el botón MENU y luego presione el botón para Timer +off Timer +on seleccionar el menú...
Fijación del temporizador para dormir Con estas funciones usted no tendrá que preocuparse por activar el modo de espera (standby) en su televisor antes de quedarse dormido. La función Sleep Timer automáticamente apagará el televisor, después de que haya transcurrido el intervalo de tiempo prefijado. Presione el botón de SLEEP para seleccionar la hora de dormir.
FUNCIONES VARIAS Bloqueo de teclado El televisor puede ser programado para que solo pueda ser operado por el control remoto. Esta caraterística puede ser utilizada para evitar Especial que personal no autorizado lo utilice. Idioma Entrada 1. Presione el botón MENU y luego presione el botón para PIP+Entrada Bloqueado...
Memorización de los canales favoritos La memorización de los canales favoritos es una característica conveniente que le permite explorar rápidamente más de 5 canales Canal de su elección sin que tenga que esperar que el TV explore los que están en medio. Programa +auto Programa +manual { 1.
CONTROL DE LA IMAGEN Turbo Imagen (Algunos modelos) Cuando se activa esta función, la imagen se verá más clara y brillante que la imagen normal. Por consiguiente, puede disfrutar de una Turboimagen mucho mejor que la imagen normal. Pulsando repetidamente el botón TURBO PICTURE se activa o desactiva esta función.
(Algunos modelos) VM (Modulación de Velocidad) 1. Presione el botón MENU y luego presione el botón para Imagen seleccionar el menú Imagen. Bajo 2. Presione el botón y luego para seleccionar Medio 3. Presione el botón para accesar a Alto Contraste Brillo 4.
CONTROL DE SONIDO Disfrute de la transmisión ESTEREO / SAP Su TV puede recibir programas MTS Estéreo y SAP que acompañen la programación, como sistemas que transmitirán una señal de audio adicional de igual calidad que la original. La función MTS no opera en el modo de Video.
Turbo Sonido (Algunos modelos) Cuando se activa esta función, el sonido resultará más acentuado y amplificado que el normal. Ajustando el ecualizador (Modo Usuario del menú Sonido) Sonido DASP 1. Presione el botón MENU y después para seleccionar el Plana Música Balance menú...
CONTROL DE SONIDO AVL (Nivelador Automático de Volumen) El AVL automaticámente mantiene un nivel de volumen aunque usted Sonido DASP cambie de canal. Balance Utilizando el botón de MENU Woofer 1. Presione el botón MENU y después para seleccionar el menú Sonido.
FUNCION DE SUBTITULAJE El subtitulaje es un proceso que convierte la porción de audio de un programa de televisión en palabras escritas, las cuales aparecen en la pantalla del televisor en una forma similar a los subtítulos. El subtitulaje permite al televidente leer el diálogo y narración de los programas de televisión. Uso de Subtitulaje Las leyendas son los subtítulos del diálogo y narración de los programas de televisión.
FUNCION DE SUBTITULAJE Uso de Función de Texto Los servicios de Texto proporcionan una extensa variedad de información sobre toda clase de temas (por ejemplo, listas de programas subtitulados, pronóstico de tiempo, tópicos del mercado de valores, noticias para personas con incapacidad auditiva ... ) a través de la pantalla de Televisión.
FUNCIONES PIP (Algunos modelos) Esta es un función opcional. Canal de la lmagen Principal Observación del PIP (Imagen sobre Imagen) TVO11 Video1 Esta función despliega una peque ña imagen sobre la imagen principal. Usted podrá observar dos programas diferentes al mismo Modo de la tiempo.
FUNCIONES PIP (Algunos modelos) Video1 TVO11 TVO11 Cambio de Pantallas Video1 Presione el botón SWAP. Cada vez que presione este botón la imagen principal y la sub imagen intercambian lugar. Imagen Congelada Presione el botón de STILL. La imagen fija se muestra en la sub imagen. Para cancelar la imagen fija, presione el botón de STILL nuevamente.
CONEXIONES DE LA ANTENA Combinación de Antenas VHF/UHF Cable de antena de 300 ohm(plano) Parte pos- Cable de terior del TV antena de 300 ohm (plano) Cable 75 ohm Coaxial Antenna Jack 75 ohm Adaptador de Adaptador de antena Cable de CATV de 300 a 75 ohm antena 75 ohm...
CONEXION DE EQUIPOS EXTERNOS (Algunos modelos) Usted puede conectar equipos adicionales, como una VHS, Cámara de Video,etc. a su TV. Aquí se muestra algunas formas de cómo puede conectarse. Estos son ejemplos de la disposición de los conectores. S-VIDEO JACK ( A l g u n o s modelos) S-VIDEO...
Page 25
Nota: En algunos modelos mono, cuando en los conectores de entrada en el panel delantero y el panel trasero se conectan equipos externos al mismo tiempo, los conectores de entrada en el panel delantero tienen prioridad sobre aquellos del panel trasero del televisor. Conectando la video grabadora S-VHS (Algunos modelos)
CONEXIONES al DVD (Algunos modelos) • Conecte las entradas compuestas de Video Y, Pb, Pr (480i) y las entradas de audio R y L. • Nota: El televisor está programado para recordar cuál fue la última modalidad que se fijó, aún cuando lo haya apagado.
PROBLEMAS CON LA TV SINTOMA No enciende No hay imagen o no hay sonido Sonido bien, imagen pobre Recepción pobre Líneas en la imagen Fantasmas (Imagenes múltiples) No funciona el Control Remoto. No puede sintonizar el canal deseado VERIFIQUE ESTOS PASOS Y TRATE DE HACER EL AJUSTE Asegúrese que el cable de alimentación está...
Page 28
Color Television OWNER'S MANUAL Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. Internet Home Page : http://www.lge.com...
Page 29
Safety Precautions WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK). NO USER-SERVICEABLE PARTS IN SIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Page 30
CONTENTS Description of controls ....................4 ~ 6 Basic TV operation ......................7 Turning on/off the TV .....................7 Selecting the on screen language .................7 Memorizing Channels ....................8 Memorizing the Channels by AUTO PROGRAM ............8 Memorizing the Channels by MANUAL PROGRAM .............9 Setting the Channel .......................9 Adjusting the Volume .....................9 Various function .......................10 Setting the Clock ......................10...
DASP • To enter or adjust the selected menu when menu is displayed on the screen. 7. VCR BUTTONS SIZE To control LG video cassette recorder. SWAP SELECT STILL POSITION CH.SEARCH 8. SLEEP BUTTON To set the desired sleep time.
Page 32
13. TV/VIDEO BUTTON To select TV, VIDEO or COMPONENT mode. Switches the set on from standby. POWER MUTE 14. MENU BUTTON To display on-screen. 15. ENTER ( ) BUTTON • To memorize the adjusted menu. • To recall the current TV mode (by remote control only). 16.
Page 33
Description of controls This is a simplified representation of front panel. TV/VIDEO MENU POWER STAND BY STAND BY TV/VIDEO MENU ON/OFF 2 20 21 13 14 20 21 13 14 TV/VIDEO MENU STAND BY ON/OFF ON/OFF TV/VIDEO MENU 20 21 22 20 13 14 TV/VIDEO MENU...
Basic TV operation Before operating your TV, make sure the following instructions have been completed. • Your TV has been connected to an antenna or a cable system. • Your TV has been plugged in a power outlet. • In this manual, the OSD (On Screen Display) may be different from your TV’s because it is just an example to help you with the TV operation.
Basic TV operation Memorizing Channels This is the function to memorize all the active channels in your area before you can use the TV. There are two ways of memorizing channels. You can use either. One is called AUTO PROGRAM and the other is called MANUAL PROGRAM. In AUTO PROGRAM the TV will memorize the channels in ascending order.
Memorizing the Channels by MANUAL PROGRAM Using the MEMORY/ERASE button You can conveniently perform MANUAL PROGRAM using the MEMORY / ERASE button on the remote control. 1. Press the or NUMBER buttons to select the channel number ++CATV+++95+++Memory you want to memorize or erase. 2.
Various function Setting the Clock Timer Before setting the on/off timer, first you should set the current time. Clock __:__+AM Clock 1. Press the MENU button and then use button to select the Off_timer Timer menu. _timer 2. Press the and then button to select Clock...
Setting the Sleep Time You don't have to remember to switch the TV to standby mode before you go to sleep. The sleep timer automatically turns the TV off after the preset time elapses. Press the SLEEP button to select the desired sleep time. Each time you press this button, the sleep time is displayed one by one as shown below.
Various function Key Lock The TV can be set so that the remote control is needed to control it. Special This feature can be used to prevent unauthorized viewing. Language Main +input 1. Press the menu button and then use button to select the PIP+input Key+lock...
Favorite channel memory Favorite channel memory is a convenient feature that lets you quickly scan up to five channels of your choice without having to wait for the Channel TV to scan through all the in-between channels. Auto+program 1. Press the MENU button and then use button to select the Manual program { CATV++95...
Picture control Turbo Picture (some models) With this function picture will be more brilliant and distinct picture than normal picture. You can enjoy the Turbo picture so much better than normal picture. Repeatedly press the TURBO PICTURE button to switch on or off the turbo picture function.
VM (Velocity Modulation) (some models) Picture 1. Press the MENU button and then use button to select the Picture menu. 2. Press the and then button to select Medium High Cotrast 3. Press the button to enter the Brightness 4. Press the button to select Low , Medium , Hight Color...
Sound control Enjoying the Stereo/SAP Broadcast This TV set can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program, as the system to be transmitted one additional sound signal as well as the original one. MTS function doesn't operate in the video mode. Using the MTS Button 1.
Turbo Sound (some models) With this function sound will be more emphasized and amplified than normal sound. You can enjoy the Turbo sound so much better than normal sound. Adjusting the equalizer (User mode in Auto Sound Control) Sound 1. Press the MENU button and then use button to select the DASP Sound menu.
Sound control AVL (Auto Volume Leveler) AVL automatically keeps on an equal volume level even if you change Sound DASP channels. Balance Using the MENU Button Woofer 1. Press the MENU button and then use button to select the Sound menu. 2.
Closed caption function Closed captioning is a process which converts the audio portion of a television program into written words, which then appear on the television screen in a form similar to subtitles. Closed captions allow viewers to read the dialogue and narration of television programs. Using Closed Captions Captions are the subtitles of the dialogue and narration of television programs.
Closed caption function Using the Text Function Text services give a wide variety of information on all kind of subjects (ex. captioned program lists, weather forecasts, stock exchange topics, news for hearing-impaired---) through the full TV screen. But not all stations offer text services, even though they might offer captioning.
PIP function (Some models) This is optional function . Channel of Main Picture Watching the PIP (Picture in Picture) TVO11 This is the function to call up a little picture (PIP : picture in picture) Video1 within the main picture. Thus at the same time you can watch two Sub picture different programs.
PIP function (Some models) Swapping Screens Video1 TVO11 TVO11 Video1 Press the SWAP button. Each time you press this button, the main picture and sub picture exchange places Still Picture Press the STILL button. The still picture is displayed in the sub picture. To cancel the still picture, press the STILL button again.
Antenna Connections Combination VHF/UHF Antennas 300 ohm Flat Wire TV rear 300 ohm Flat Wire 75 ohm 75 ohm Antenna Coaxial Jack Cable 300 to 75 300 to 75 75 ohm ohm Adapter ohm Adapter CATV Cable Connecting an Outdoor Antenna For the best reception, we recommend you use an outdoor antenna.
Connection of external equipment (some models) You can connect additional equipment, such as VCRs, camcorders etc. to your set. Here shown may be somewhat different from your set. These are an example drawing of typical jack layout. S-VIDEO JACK (some models) S-VIDEO COMPONENT...
Page 52
Note: In some mono models, when the input jacks on the front panel and back panel are connected to external equipments at the same time, the input jacks on the front panel have priority over the input jacks on the back panel of the TV. Connecting the S-VHS VCR (some models) 1.
Connecting DVD player (some models) • Connect component video inputs to Y, P (480i) and audio IN2 to audio(L/R) ports. • Note: This TV is programmed to remember which mode it was last set to, even if you turn the TV off. 1.How to connect COMPONENT DVD IN (480i)
Troubleshooting check list SYMPTOMS No power No picture or sound Poor picture but good sound Poor reception Lines in picture Ghosts (multiple images) Remote control does not work. Cannot tune desired channel. CHECK THESE THINGS Is power cord plugged in? Is television turned on? Check batteries in remote control.
