DMP 1142HD Installation Manual

Wireless two-button transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION GUIDE
1142HD
Wireless Two-Button Transmitter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1142HD and is the answer not in the manual?

Questions and answers

Related Manuals for DMP 1142HD

Summary of Contents for DMP 1142HD

  • Page 1 INSTALLATION GUIDE 1142HD Wireless Two-Button Transmitter...

  • Page 2: Get Started

    GET STARTED The 1142HD is a wireless two-button holdup transmitter in a heavy duty enclosure that can be mounted under a counter or on a wall. It has a tamper switch to identify if the unit has been removed from its mounted location. The 1142HD features built-in optional 128-bit AES encryption.

  • Page 3: Installation

    Install the Battery Insert a 3.0V lithium battery or a DMP Model CR123A battery. It is recommended for UL installations to use either an Energizer 123 battery or a CR123A battery manufactured by Panasonic or Tekcell. Keep in mind, when setting up a wireless system, program zones and connect the receiver (if needed) before installing the battery.

  • Page 4: Select A Location

    Select a Location The 1142HD provides a Survey LED capability to allow one person to confirm Antenna Tamper Switch communication with the wireless receiver or panel while the cover is removed. Hold the transmitter in the exact desired location. Press the tamper switch to send data to the panel and determine if communication is confirmed or faulty.

  • Page 5: Additional Information

    ADDITIONAL INFORMATION Replace the Battery Remove the screws from the 1142HD housing and remove the old battery. Observe polarity and place the new battery in the holder and press into place. Align the top housing and LED cut-out with the base housing and reassemble. See Figure 3.

  • Page 6: Specifications

    Version 300 is required for Wireless Receivers. CERTIFICATIONS ▶ FCC Part 15 Registration ID: CCKPC0248 ▶ Industry Canada Registration ID: 5251A-PC0248 Underwriters Laboratory (UL) Listed ANSI/UL 2610 Commercial Premises Security Alarm Units Patents U.S. Patent No. 7,239,236 1142HD Installation Guide | Digital Monitoring Products...

  • Page 7: Fcc Information

    I N T R U S I O N • F I R E • A C C E S S • N E T W O R K S manufactured in Springfield, MO 2500 North Partnership Boulevard using U.S. and global components. Springfield, Missouri 65803-8877 LT-2982 1.01 25152 800.641.4282 | DMP.com © 2025...
