SIRIUS 3RV Motor Starter
Protectors
Equipment Manual
09/2024
A5E03656507320A/RS-AL/012
Introduction
Standards
Safety instructions
Product description
Product combinations
Functions
Configuration
Mounting
Connection
Operation
Accessories
Technical data
Circuit diagrams
Types of coordination
References
Dimension drawings
(dimensions in mm)
1
2
3
4
5
6
7
8
9
10
11
12
13
A
B
C
