60cm Induction Hob
INT600 -
4 Zones - Front Touch Control

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INT600 and is the answer not in the manual?

Questions and answers

Summary of Contents for montpellier INT600

  • Page 1 60cm Induction Hob INT600 - 4 Zones - Front Touch Control...
  • Page 2 Welcome Thank you for choosing this Montpellier Induction Hob. Our Induction Hobs have been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your Hob to ensure you get the most from your purchase.
  • Page 3 Thank you for choosing this Montpellier product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
  • Page 4: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ......................6 1.3 During Use ........................7 1.4 During Cleaning and Maintenance .................7 2.INSTALLATION AND PREPARATION FOR USE ..............9 2.1 Instructions for the Installer ....................9 2.2 Installation of the Hob .....................9 2.3 Electrical Connection and Safety..................
  • Page 5: Safety Instructions

    1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within.
  • Page 6 • For induction hobs, metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface because they can get hot. • For induction hobs, after use switch off the hob element using the control knob. Do not rely on the pan detector.
  • Page 7: Installation Warnings

    household use only. It should not be used for any other purpose or in any other application, such as for non-domestic use, in a commercial environment or for heating a room. • All possible measures have been taken to ensure your safety.
  • Page 8: During Use

    Styrofoam, etc.) may be harmful to children and they should be collected and removed immediately. • Protect your appliance against atmospheric effects. Do not expose it to effects such as sun, rain, snow, dust or excessive humidity. • Materials around the appliance (i.e. cabinets) must be able to withstand a minimum temperature of 100°C.
  • Page 9 • Do not remove the control knobs to clean the control panel. • To maintain the efficiency and safety of your appliance, we recommend you always use original spare parts and to call our authorised service agents in case of need. CE Declaration of conformity We declare that our products meet the applicable European Directives, Decisions...
  • Page 10: Installation And Preparation For Use

    2. INSTALLATION AND PREPARATION FOR USE WARNING: This appliance must be installed by an authorised service person or qualified technician, according to the instructions in this Minimum Minimum 42 cm 42 cm guide and in compliance with the current local regulations. Incorrect installation may cause harm •...
  • Page 11 Separator Separator Apply the supplied one-sided self- • Worktop mounting adhesive sealing tape all the way bracket around the lower edge of the cooktop. Do not stretch it. Self-adhesive sealing tape Screw the 4 worktop mounting brackets • in to the side walls of product. EN - 10...
  • Page 12: Electrical Connection And Safety

    Insert the appliance into the aperture. • 2.3 Electrical Connection and Safety WARNING: The electrical connection of this appliance should be carried out by an authorised service person or qualified electrician, according to the instructions in this guide and in compliance with the current local regulations.
  • Page 13: Product Features

    3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Induction zone 2. Control Panel EN - 12...
  • Page 14: Use Of Product

    4. USE OF PRODUCT 4.1 Hob Controls Induction Zone The information given in the following table is for guidance only. Settings Use for Circular Saucepan Base Element off Delicate warming Gentle simmering, slow warming Reheating and rapid simmering Boiling, saute and searing Small Saucepan Saucepan base that Maximum heat...
  • Page 15 (If a cooking-zone is not selected within 20 power for the activated heater(s) will reduce seconds, the hob will automatically switch to level 1 and “II” will appear at all displays. off). Press again to deactivate Smart Switching the Appliance Off Pause.
  • Page 16: Cleaning And Maintenance

    Buzzer Calibration error. Call authorised service While the hob is in operation, the following agent. activities will be signalled by the buzzer. Normal button activation will be • 5. CLEANING AND MAINTENANCE accompanied with a short sound signal. Continuous button operation over a •...
  • Page 17 durability of the ceramic and is not due to a change in the material. Colour changes to the ceramic glass may be for a number of reasons: 1. Spilt food has not been cleaned off the surface. 2. Using incorrect dishes on the hob will erode the surface.
  • Page 18: Troubleshooting&Transport

    6. TROUBLESHOOTING & TRANSPORT 6.1 Troubleshooting If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check the household fuse for the Hob control card’s display is appliance.
  • Page 19: Technical Specifications

    7. TECHNICAL SPECIFICATIONS 7.1 Energy Fiche Brand Model INT600 Type of Hob Electric Number of Cooking Zones Heating Technology-1 Induction Size-1 Ø16,0 Energy Consumption-1 Wh/kg 182,0 Heating Technology-2 Induction Size-2 Ø16,0 Energy Consumption-2 Wh/kg 182,0 Heating Technology-3 Induction Size-3 Ø21,0...
  • Page 20: After-Sales Assistance

    Your 2 year Manufacturer’s guarantee THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the first 24 months from date of purchase provided that: Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date of claim.
