Installation guide Polyethylene Ecoflo compact biofilter EC7-500, EC7-600, EC7-750, EC7-1050, and EC7-1350 model series This guide contains the information required to install the polyethylene Ecoflo compact biofilter EC7-500, EC7-600, EC7-750, EC7-1050, and EC7-1350 model series. The installation must be performed by a duly trained installer. A list of installers can be provided by contacting Premier Tech at 1 800 632-6356.
Page 2: Technical Data Sheets
TECHNICAL DATA SHEETS COMPONENT MATERIALS • Tank and top slab: reinforced concrete • Lid, central support, tipping bucket, and distribution plates: polyethylene • Filtering medium: coconut husk fragment-based compound Model EC7-500-P-G/P-PACK EC7-600-P-G/P-PACK EC7-750-P-G/P-PACK Hydraulic capacity 500 US gal/d 600 US gal/d 750 US gal/d Primary tank volume 750 US gal...
Page 3 Model EC7-500-P-G/P EC7-600-P-G/P EC7-750-P-G/PDV Hydraulic capacity 500 US gal/d 600 US gal/d 750 US gal/d Length 10’ 2-3/4” 11’ 7-3/4” 13’ 3-1/2” Width 4’ 2-1/2” Height 5’ 9-3/4” Includes 12” of risers Inlet invert height from 4’ 1/2” bottom of the tank Inlet invert height 1’...
Page 4 Model EC7-1050-P-G/PDV EC7-1350-P-G/PDV Hydraulic capacity 1,050 US gal/d 1,350 US gal/d Length 11’ 3/4” 13’ 5-1/2” Width 6’ 6-3/4” 6’ 8-3/4” Height 6’ 3/4” Inlet invert height from 4’ 1-1/2” bottom of the tank Inlet invert height 1’ 11-1/4” from surface grade Gravity water outlet height 1-1/2”...
Page 5: Description Of System Components
Premier Tech does not recommend using a garbage disposal unit. If you are using a garbage disposal unit, you must follow the state and local code for tank and absorption field sizing.
Page 6: Product Nomenclature
Premier Tech Water and Environment offers different pumping station models, such as PSA-240 the PSA-240 and the PSA-240H. Find more information about them or about Premier Tech Water pumping station and Environment’s recommended pump station dosing PT-WaterEnvironment.com/ProSpace.
Page 7: Location Of The Components And Specific Instructions
Premier Tech Water and Environment offers several pressurized flow dividers. Learn more at PT-WaterEnvironment.com/ProSpace. FINAL DISPERSAL The final dispersal system must be designed in accordance with Premier Tech Water and Environment guidelines and/or state or local regulations. LOCATION OF COMPONENTS AND SPECIFIC INSTRUCTIONS...
Page 8: Reference Point
• that is accessible at all times for maintenance, inspection, and emptying The treatment system’s location must also comply with the distances in the following table: Minimum distances to be maintained in accordance with Premier Tech Water and Environment specifications Reference point...
Page 9: Installation Conditions
Base of excess backfill, slope, or embankment Parking area Object or structure weighing Retaining wall more than 500 lb (225 kg) Minimum distances may be higher, depending on local regulations ecommended 12” Seasonal High Groundwater (SHGT) levels to respect pumped discharge for an Ecoflo compact biofilter installation Installation conditions 2.4.1 Primary/septic tank...
Page 10 (when present). The following extensions must be provided by Premier Tech: a STR-060 6’’ (150 mm) extension for the main access and a PSR-060 6’’ (150 mm) extension for the each access to the pretreatment chamber, or an STR-060P kit with both extensions for Pack models.
Page 11 The vertical separation between the infiltration area to the seasonal high groundwater table, impermeable layer, or bedrock must comply with applicable local requirements. Premier Tech Water and Environment recommends that the minimal vertical distance between the clean crushed stone (treated effluent distribution zone) and the limiting layer (groundwater, bedrock, or impervious layer) be at least 12”...
Page 12: Description Of The Polyethylene Ecoflo Compact Biofilter Components
DESCRIPTION OF THE POLYETHYLENE ECOFLO COMPACT BIOFILTER COMPONENTS EXPLODED VIEW OF MODELS EC7-500, EC7-600, AND EC7-750 Component Material Description • houses the system’s components Casing Polyethylene • allows for the connection of the water and air supply lines • collects the treated effluent Lid(s)/riser(s) Polyethylene •...
Page 13 EXPLODED VIEWS OF MODELS EC7-1050 AND EC7-1350 Component Material Description • houses the system’s components Casing Polyethylene • allows for the connection of water and air supply lines • collects the treated effluent Lid(s)/riser(s) Polyethylene • protects inner components and provides access into the system Vent caps Polyethylene •...
Page 14: Installation Sequence
INSTALLATION SEQUENCE IMPORTANT: THE INSTALLER IS RESPONSIBLE FOR TAKING THE NECESSARY SAFETY MEASURES AT ALL STEPS OF THE INSTALLATION. THIS INCLUDES THE USE OF HARDHATS, GLOVES, BOOTS, SAFETY GLASSES, MASKS, ETC. During a typical installation, the components are installed in the following sequence: 1- primary/septic tank 2- Ecoflo compact biofilter 3- water inlet and discharge pipe connections...
Page 15 5.1.2 Modifying a pumped unit into a gravity unit For all models To modify an Ecoflo compact biofilter with an integrated pump into a gravity discharge biofilter, remove the protective red cap, remove the punch-out baffle in the outlet fitting, and use a watertight and flexible outlet adaptor to connect the effluent discharge pipe.
Page 16 INITIAL BACKFILL OF THE UNIT Backfill around the unit up to 8” (200 mm) below the invert of the inlet pipe. Begin with the two longest sides and end with the extremities. Note that the backfill material must be laid down rather than pushed. Do not compact the backfill material using a power shovel.
Page 17 Note for pumped models: If the installation includes a pressurized dispersal area, higher dosing volumes may need to be attained. Be sure to check elevation changes and distances to the dispersal area to determine if dose adjustments are needed. Float tree Stem Clips 1.
Page 18 These documents contain the owner’s manual and maintenance agreement to be signed by the homeowner and submitted to Premier Tech Water and Environment. • Connect the pipe arriving from the primary reactor/septic tank to the water inlet of the Ecoflo compact biofilter while making sure to maintain a constant downslope along the entire length of the pipe to the inlet of the Ecoflo compact biofilter.
Page 19 • The pumping station must be watertight from the outside (infiltration) and the inside (exfiltration). • The water inlet pipe (Ø 1-1/2” [38 mm] flexible pipe) is connected to a connection adaptor (provided with Premier Tech Water and Environment’s PSA-240 pumping station). This pipe shall also be connected to the inlet of the Ecoflo compact biofilter (nominal diameter of 4”...
Page 20 Ecoflo compact biofilter unit by hand. Ensure there are no air gaps Max. water between the pipe and the backfill material. Premier Tech Water and Gravity table level effluent pipe Environment recommends wetting backfill sand to improve compaction.
Page 21 (from the residence to the system), two double-stranded electrical wires are needed. Premier Tech recommends using a pipe/conduit to protect the buried wires. The professional electrician will choose the appropriate wire size. One of these wires will provide the power supply, whereas the other one will send current from the alarm float to the alarm box (Item A) or the control panel (when required).
Page 22 EC7-1050 and EC7-1350 The ON/OFF float’s white wire is connected to the pump’s black wire (“hot” wire). Premier Tech strongly recommends wrapping the white wire with black electrical tape. Close the electrical junction box. Pass the electrical wires arriving from the pumping unit through the groove of the insulation board.
Page 23: Shipping And Handling
Check the Ecoflo compact biofilter model installed and the type of discharge on the provided sticker. Install the insulation board and seal it in place using the two Premier Tech fasteners. Once in place, these fasteners secure the Ecoflo compact biofilter’s collar to the handle of the...
Page 24: Load Configuration
Ecoflo compact biofilter to prevent any motor vehicle traffic on the unit and to take note of the final level of the system. • The residence must be equipped with a functional air vent that meets the applicable standards. Premier Tech Water and Environment strongly recommends using a pipe measuring 4” (100 mm) in diameter.
