NAVTELECOM SMART S-2435 Operation Manual page 8

№
1 Device unit
2 14-pin connector of Microfit-14 with two power wires
3 Cable set of 5 installation wires
4 Fuse 1A
5 Fuse holder
6 Interface cable with MiniUSB connector
7 Passport
8 Package
1.6 Standard equipment set
Name
Figure 4. 14-pin connector of Microfit-14
Figure 5. Interface cable with MiniUSB connector
Figure 6. Fuse and fuse holder
Version of complete set
Number of pieces
1
1
1
1
1
1
1
1
Tab. 2
A B
+ +
+ +
+ +
+ +
+ +
+
+ +
+
