NAVTELECOM SMART S-2435 Operation Manual page 6

Total number of universal (analog, discrete, pulse-frequency) inputs
Built-in pull-up resistor for discrete or pulse-frequency inputs
Measuring range by inputs, set up as analog, V
Working range with frequency fuel level sensors, Hz
USB interface for settings, control, data transfer and diagnostics
RS-485 digital interface
RS-232 digital interface
CAN digital interface
1-Wire interface
Number of outputs of the "open collector" type for the external devices
control
Maximum switching current by the control outputs, mA
Maximum switching voltage by the control outputs, V
Built-in 3-axis accelerometer
Maximum impact loading measured by the device, g
Enclosure protection level
Maximum allowable overload during impacts, g
Storage temperature with the battery
Storage temperature without the battery,
Operating temperature with the battery,
Operating temperature without the battery,
Temperature at which the battery is possible to charge,
Maximum allowable humidity level at 35
Device dimensions with connectors, mm
Device weight, kg
1. Optional
2. If maximum operating voltage is exceeded the power protection is activated. The device continues to work, but
is powered by the battery.
3. If GPRS operates in poor communications, peak consumption (10 ms), consumption of the device can accede 500
mA.
4. Attention! Lithium polymer battery (Li-Po) is used in the device. The following rules must be observed during its
operation: not to heat, keep away from sources of heat, not to throw the battery into the fire, not to expose to
direct sunlight. The device, for power of which Li-Po battery is used, cannot be used in high humidity, high and
low ambient temperatures. Operation is permitted under the conditions specified by the manufacturer. Not to hit,
not to deform, not to disassemble, not to close contacts.
Protection against battery charge while it is overcooled or overheated.
5.
The mode in which information received through RS-232 and RS-485 interfaces is not processed by the device,
6.
and is buffered and transmitted to the server as it is.
When the device is stored and used outside the specified temperatures, it is recommended to turn it off and
7.
remove the battery from the device to avoid damage to the battery and to the device.
Performance specifications
, C
6 o
o C
o C
o C
o C
o C, %
3
yes
0...31
1 - 3000
yes
yes
yes
yes
yes
2
500
48
yes
8
IP54
24
0 ... +40
-40 ... +85
-20 ... +60
-40 ... +85
0 ... +50
95
102х57х22
0,097
