Intex PureSpa SC-WF10 Owner's Manual page 6

Before assembling your product, please take a few minutes to check the contents
REF.
NO.
1 CONTROL BASE
2 SPA FILTER MOTOR
3 CONTROL PANEL
4 SIDE COVER HINGE BASE
5 AIR PRESSURE RELEASE VALVE CORE
6 CONTROL PANEL BOLT WRENCH
7 SPA INFLATION HOSE
8 SPA CONTROL INLET/OUTLET O-RING
9 SIDE COVER HINGE FIXER
10 SPA DRAIN PLUG
11 SUCTION FITTING
12 FILTER CARTRIDGE HOUSING
13 FILTER CARTRIDGE
14 FILTER CARTRIDGE HOUSING LID
15 INLET PLUG
16 SPA TUB
17 SPA COVER
18 SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
19 GROUND CLOTH
20 ELECTROLYTIC CELL NUT WRENCH
21 TEST STRIPS
22 WRENCH
23 OUTLET PLUG
24 HOSE ADAPTOR (PRE -INSTALLED WITH #7)
25 MALE BUCKLE
26 FEMALE BUCKLE
27 SPA CONTROL AIR INLET O-RING
28 ELECTROLYTIC CELL COVER SCREW
29 ELECTROLYTIC CELL COVER
30 ELECTROLYTIC CELL COVER O-RING
31 ELECTROLYTIC CELL NUT
32 ELECTROLYTIC CELL
33 ELECTROLYTIC CELL O-RING
34 DEFLATION OUTLET CAP
35 DEFLATION HOSE ADAPTOR
36 CONTROL BASE SIDE COVER
When ordering parts, be sure to quote the model number and part numbers.
Self-contained spa fi ttings. – For multiple outlet use only. – Wall mounting only.
Replace suction fi ttings within 3 installed year. – Tool required: screwdriver.
Spa suction fi tting maximum fl ow rate: 84 gpm (5040 gph)
• Check suction strainer fi tting and fasteners for damage or tampering before each use of the spa.
• For service and winterization instructions refer to "Maintenance" and "Storage" sections.
• Read and follow all instructions, save these instructions for future reference.
S AVE THESE INSTRUCTIONS
(351PO) SPA (JET + BUBBLE) ENGLISH 7.5" X 10.3" PANTONE 295U 11/30/2021
PARTS (continued)
and become familiar with all the parts.
DESCRIPTION
SPA SUCTION FITTING
English
SPARE PART NO.
QTY.
4 ADULTS 6 ADULTS
1 13027 13027
1 12777 12777
1 13023 13023
2 12771 12771
1 12589D 12589D
1 11053 11053
1 11830 11830
2 11788 11788
2 12772 12772
1 13076 13076
2 11785 11785
2 11798 11798
2 11692 11692
2 11797 11797
1 11739 11739
1 12723 12745
1 11951 12117
1 11884 12114
1 11933 12110
1 11854 11854
1 11855 11855
1 11742 11742
2 11782 11782
1 12773 12773
8 11994 11994
8 11993 11993
1 11687 11687
4 11712 11712
1 11890 11890
1 11897 11897
1 11852 11852
1 11851 11851
1 11853 11853
1 12775 12775
1 12774 12774
2 12770 12770
