26TPA8
Performance™ Series 2-Stage Air Conditioner
with Puron Advance™ (R-454B) Refrigerant
and InteliSense™ Technology
2 to 5 Nominal Tons
NOTE: For use with R-454B indoor units only. Read the entire instruction manual before starting the installation.
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Check Equipment and Job Site . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Install on a Solid, Level Mounting Pad . . . . . . . . . . . . . . . . . . . . . 2
Clearance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operating Ambient. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Make Piping Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
MANDATORY PIPING REQUIREMENTS. . . . . . . . . . . . . . . . . . . 5
Make Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Compressor Crankcase Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Install Electrical Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Airflow Selections (ECM Furnaces) . . . . . . . . . . . . . . . . . . . . . . . 8
(Non-Communicating) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
(Non-Communicating) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SEQUENCE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Compressor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CHECK CHARGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
FINAL CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
REPAIRING REFRIGERANT CIRCUIT . . . . . . . . . . . . . . . . . . . . 11
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
MAJOR COMPONENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CARE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

SAFETY CONSIDERATIONS

The following considerations are critical to upholding safety during
installation:
IMPORTANT: This appliance shall only be installed by EPA qualified
personnel having appropriate certification. This appliance is not
intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Improper installation, adjustment, alteration, service, maintenance, or
use can cause explosion, fire, electrical shock, or other conditions which
may cause death, personal injury, or property damage. Consult a
qualified installer, service agency, or your distributor or branch for
information or assistance. The qualified installer or agency must use
factory-authorized kits or accessories when modifying this product.
Refer to the individual instructions packaged with the kits or accessories
when installing.
Follow all safety codes. Wear safety glasses, protective clothing, and
work gloves. Use quenching cloth for brazing operations. Have a dry
powder or CO
fire extinguisher available. Read these instructions
2
thoroughly and follow all warnings or cautions included in literature and
attached to the unit. Consult local building codes and current editions of
Installation Instructions
the National Electrical Code (NEC) NFPA 70. In Canada, refer to
current editions of the Canadian Electrical Code CSA 22.1.
Proper tools should be used that are designed for the refrigerant of the
unit being installed. For A2L refrigerants, non-sparking tools are
required. A refrigerant detector should be used prior to and during the
installation process to check for leaks. Open flames or other ignition
sources should not be present except during brazing. Brazing should
only take place on refrigerant tubes open to the atmosphere or have been
properly evacuated.
Recognize safety information. This is the safety-alert symbol
When you see this symbol on the unit and in instructions or manuals, be
alert to the potential for personal injury.
Understand these signal words; DANGER, WARNING, and CAUTION.
These words are used with the safety-alert symbol. DANGER identifies
the most serious hazards which will result in severe personal injury or
death. WARNING signifies hazards which could result in personal
injury or death. CAUTION is used to identify unsafe practices which
would result in minor personal injury or product and property damage.
NOTE is used to highlight suggestions which will result in enhanced
installation, reliability, or operation.
WARNING
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury or death.
Before installing, modifying, or servicing system, main electrical
disconnect switch must be in the OFF position. There may be more than
1 disconnect switch. Lock out and tag switch with a suitable warning
label.
WARNING
!
EXPLOSION HAZARD
Failure to follow this warning could result in
death, serious personal injury, death, and/or
property damage.
Never use air or any gas containing oxygen for
leak testing or operating refrigerant compressors.
Never allow compressor suction pressure to
operate in a vacuum with service valves closed.
See Service Manual for pump-down instructions.

GENERAL

The following are general installation recommendations/NOTES to be
observed throughout the installation process:
1. Locate unit away from windows, patios, decks, etc. where unit
operation sound may disturb customer.
2. Ensure that vapor and liquid tube diameters are appropriate for unit
capacity.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Performance 26TPA8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carrier Performance 26TPA8

  • Page 1: Table Of Contents

    26TPA8 Performance™ Series 2-Stage Air Conditioner with Puron Advance™ (R-454B) Refrigerant and InteliSense™ Technology 2 to 5 Nominal Tons Installation Instructions NOTE: For use with R-454B indoor units only. Read the entire instruction manual before starting the installation. SAFETY CONSIDERATIONS ......1 the National Electrical Code (NEC) NFPA 70.
  • Page 2: Installation

    26TPA8: Installation Instructions 3. Run refrigerant tubes as directly as possible by avoiding IMPORTANT: Always install the factory-supplied liquid-line filter unnecessary turns and bends. Tube bends shall be greater than 2.5 drier. If replacing the filter drier, refer to Product Data Digest for times the external pipe diameter.
  • Page 3: Clearance Requirements

    26TPA8: Installation Instructions Outdoor units may be connected to indoor section using accessory tubing package or field-supplied refrigerant grade tubing of correct size and condition. Rated tubing diameters shown in Table 1 recommended up to 80 ft. (24 m). See Product Data for acceptable alternate vapor diameters and associated capacity losses.
  • Page 4 26TPA8: Installation Instructions Table 2 – Accessory Usage Required for Low Ambient Required for Sea Coast Required for Long Line Accessory Cooling Applications Applications Applications (Below 55°F / 12.8°C) (within 2 miles/3.2 km) Compressor Start Assist Capacitor and Relay Crankcase Heater Evaporator Freeze Thermostat Hard Shutoff TXV See Residential Piping...
  • Page 5: Mandatory Piping Requirements

    26TPA8: Installation Instructions Install Liquid-Line Filter Drier Indoor Leak Check CAUTION WARNING UNIT DAMAGE HAZARD EXPLOSION HAZARD Failure to follow this warning could result in Failure to follow this caution may result in equipment damage or death, serious personal injury, death, and/or improper operation.
  • Page 6: Make Electrical Connections

    26TPA8: Installation Instructions Make Electrical Connections Connect Control Wiring NOTE: This unit has a transformer in the outdoor unit that powers the WARNING control board and compressor solenoid and does not require 24VAC "R" from the indoor unit. ELECTRICAL SHOCK HAZARD This unit installed...
  • Page 7 26TPA8: Installation Instructions A240453 A240419 Fig. 8 – 2-Stage Air Conditioner Tstat Wiring with Fan Coil Control, Fig. 7 – 2-Stage Air Conditioner Tstat Wiring with Furnace Coil Sensor Control Module, and Leak Dissipation Board Control, Sensor Control Module, and Leak Dissipation Board (See System Control Installation Instructions for specific unit (See System Control Installation Instructions for specific unit combinations)
  • Page 8: Compressor Crankcase Heater

    26TPA8: Installation Instructions InteliSense™ Technology Install Electrical Accessories This unit is InteliSense capable when used with an Ecobee for Carrier Refer to the individual instructions packaged with kits or accessories smart thermostat with InteliSense technology. when installing. InteliSense technology allows for the collection of performance data to WARNING be sent to the cloud.
  • Page 9: Start-Up

    26TPA8: Installation Instructions SEQUENCE OF OPERATION Start-Up Turn on power to indoor and outdoor units. Transformer is energized. WARNING On a call for cooling, thermostat makes circuits R-Y and R-G. Circuit R-Y energizes contactor, starting outdoor fan motor and compressor ENVIRONMENTAL HAZARD circuit.
  • Page 10: Check Charge

    26TPA8: Installation Instructions CHECK CHARGE Table 3 – Minimum Room Area Charging Table NOTE: CHARGE IN HIGH STAGE ONLY Total System Charge (lbs.) Minimum Floor Area (sq. ft.) Factory charge amount and desired subcooling are shown on unit rating plate. Care should be taken to ensure proper refrigerant is used for charging.
  • Page 11: Final Checks

    26TPA8: Installation Instructions FINAL CHECKS Table 4 – Required Liquid Line Temperature IMPORTANT: Before leaving job, be sure to do the following: Liquid (PSIG) R-454B Required Subcooling Temperature (°F) Pressure at 1. Ensure that all wiring is routed away from tubing and sheet metal Service Valve edges to prevent rub-through or wire pinching.
  • Page 12: Major Components

    Access My Learning Center with your HVAC Partners credentials at www.mlctraining.com. Please contact us a mylearning@carrier.com with questions. © 2024 Carrier. All rights reserved. Edition Date: 11/24 Catalog No: 26TPA8-01SI Replaces:New Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
