Bascom BSM-PA4X-ODR User Manual page 12

Outdoor camera adapter

Advertisement

Available languages

Available languages

Specifications
Model
Connect with
Interface
Speed
Encryption
Reach
PoE port
PoE standard
Max. power on PoE port
Max. PoE cable length
Weight
Dimension (L × W × H)
Operating temperature
Storage temperature
Operating and storage humidity
Power consumption
Power supply
BSM-PA4X-ODR
Camera
1 x PoE RJ45 10/100/1000 Mbps / 1 x Power
Terminal G / N / L.
1200Mbps
128-AES
500 meter
Yes
IEEE 802.3at/af
30W
100 meter with UTP category 5e cable
480g
200 x 110 x 50 mm
- 35 °C to 60 °C
- 35 °C to 70 °C
10-90% relative humidity, non-condensing
4W
Input: 100-240V AC, 50/60Hz
11
