JS7000K
7 INCH MONITOR & CAMERA KIT
SPECIFICATIONS
JS7000 MONITOR
- TFT Panel:
New Grade A LCD
- LCD Size:
178mm (7-Inch) Diagonal
- Display Format:
16:9
- Resolution:
800 x 480
- Brightness:
< 500 CD/M2
- Viewing Angles:
70° Left/Right/Up/Down
- Video System:
Auto PAL/NTSC Select
- Video Connect:
2 x 4-Pin (Female)
- Reverse Trigger:
Camera 2 Only
- Monitor View:
Normal/Mirror Image Select
- Buttons:
Illuminated
- Guidelines:
Selectable On/Off (Camera 2 Only)
- Audio:
On Board Speaker
- Menu:
OSD
- Main Menu:
Brightness/Contrast/Colour/Volume/
Guidelines (On/Off)/Reset/Language
- Operating Temp:
-20°C to +70°C
- Power Input:
10-32V DC (Negative Ground)
- Dimensions:
180W x 122H x 28D mm (excluding bracket)
- Finish:
Matt Black Rubber, Matt Metal
- Included:
U-Shape Mount, Remote Control,
Power Cable Assembly, Sunshade
INSTRUCTION MANUAL
CAMERA
- Image Sensor:
- Auto Lens:
- Electronic Shutter:
- Diagonal Viewing Angle:
- Horizontal Viewing Angle:
- Signal System:
- Resolution:
- Sync System:
- Orientation:
- Night Vision:
- Illumination:
- Ingress Protection:
- Operating Temperature:
- Dimensions:
- Connection:
- Power Supply:
- Included:
Optional: Glass Mount Bracket (BKT101)
1
1/3" Sony CCD
f2.9mm
Auto
120°
90°
PAL
700 TV Lines
Internal
Mirror Image
Yes, 18 LED
0 Lux with IR on
IP67
-20°C ~ +70°C
70W x 45H x 60D mm
(Excl Bracket)
Terminated 4-Pin Male
12V DC
(From Monitor)
15m 4 Pin (Male) to 4 Pin
(Female) Extension Cable,
Mounting Bracket, Sunvisor
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Axis JS7000K
Summary of Contents for Axis JS7000K
- Page 1 JS7000K 7 INCH MONITOR & CAMERA KIT SPECIFICATIONS JS7000 MONITOR CAMERA - TFT Panel: New Grade A LCD - Image Sensor: 1/3” Sony CCD - LCD Size: 178mm (7-Inch) Diagonal - Auto Lens: f2.9mm - Display Format: 16:9 - Electronic Shutter:...
-
Page 2: Keys & Menu
CONTENTS CONTENTS - 7” TFT LCD Monitor - 7” TFT LCD Monitor - Removable Sun Hood - Removable Sun Hood - U Type Monitor Bracket - U Type Monitor Bracket - Power/AV Loom - Power/AV Loom - IR Remote Control - IR Remote Control - IR 1/3 SONY CCD Camera with Sun Hood and Bracket - IR 1/3 SONY CCD Camera with Sun Hood and Bracket... -
Page 3: Remote Control
REMOTE CONTROL Power Menu V1/V2 Change Nega�ve Decrease Positive Increase Mode selec�on SPECIFICATIONS MONITOR Camera - Display: Colour TFT-LCD - Sensor: 1/3 SONY CCD - Size: 7” (Diagonal) - Sensi�vity: 0 Lux with IR - Aspect Ra�o: 16:9 / 4:3 - Electronic Shu�er: Auto - Resolu�on: 800 x 480 x RGB - Lens: f 2.9mm... - Page 4 CONTENTS AV Cable Connector POWER +12V-24V GND wire Reversing wire Connect to CAM2 (CH 2 normal image) AV Cable Connector Connect to CAM1 (CH 1 normal image) 4 Pin Configuration 4-Pin Locking Socket (Female) Connection 4-Pin Locking Pl Definition: Monitor Connector Front View VIDEO AUDIO POWER...
- Page 5 MONITOR & CAMERA SET UP MONITOR & CAMERA SET UP 1. Place the U bracket in the position desired with the monitor installed and 1. Place the U bracket in the position desired with the monitor installed and check for obstructions. Do not obscure driver's view. check for obstructions.
-
Page 6: Optional Accessories
OPTIONAL ACCESSORIES Matching Second Camera Centre License Plate Camera Side Cameras, ideal for blind spots Front Facing camera Trailer Connection AV/Power Cables DVR Recording Systems... - Page 7 INCLUDING ACCESSORIES INCLUDING ACCESSORIES 1. Remote control 1x 1. Remote control 1x 2. User manual 1x 2. User manual 1x 3. Power cable 3. Power cable 4. Sun shade 1x 4. Sun shade 1x 5. Bracket Accessories 1x 5. Bracket Accessories 1x...
- Page 8 Please complete details below in the event of warranty service being required. Purchaser's Name: _________ _ Purchaser's Address: ________ _______ _ JS7000K Model Number: ________ Serial Number: __ _ Dealer Name: _ _ _ _ _ _ _ _ _ Date of Purchase:...
