Table of Contents

06900A MULTI-PURPOSE GRINDER
w/ TRIGGER CABLE ASSEMBLY
06950A MULTI-PURPOSE GRINDER
w/ TRIGGER BAIL ASSEMBLY
The Matweld Multi-Purpose
Grinder allows operators to re-
main in an ergonomic upright
position while performing field
weld grinding. The adjustable rear
handle positions easily for the
operators preferred height and
comfort or lowered and swiveled
around for compact storage.
FLOW
10 gpm
(38 lpm)
ACCESSORIES:
00499 - 8 X 1 X 5/8 HUB GRINDING STONE
MATWELD, INC.
Matweld reserves the right to change parts, features, or specifications without notice.
patent no. 6,663,476
A
PRESSURE
RPM
2000 psi
4000
(140 bar)
PHONE:(270) 444-0085
P.O. Box 2816 • Paducah, KY 42002
Website: www.matweld.com
Email: customerservice@matweld.com
B
DIMENSIONS
WEIGHT
L - 40"
36 lbs
W - 22"
(16.36 kg)
H - 34"
FAX:(270) 443-6180
632 South 3rd Street
270-444-0085
Fax: 270-443-6180
C
08/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 06900A and is the answer not in the manual?

Questions and answers

Related Manuals for Matweld 06900A

Summary of Contents for Matweld 06900A

  • Page 1 (140 bar) W - 22” (16.36 kg) H - 34” ACCESSORIES: 00499 - 8 X 1 X 5/8 HUB GRINDING STONE MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 2 MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...

  • Page 3: General Safety Precautions

    TOOL. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN PERSONAL INJURY OR EQUIPMENT DAMAGE. MATWELD HAS NO CONTROL OVER TOOL USE OR OPERATION ONCE IT LEAVES THE MATWELD PLANT. MATWELD HAS NO CONTROL OVER OPERATOR OR MAINTAINER SELECTION. THE CUS- TOMER MUST ASSUME RESPONSIBILITY FOR THE TOOL’S SUITABILITY FOR A PARTICULAR FUNC-...
  • Page 4 SIONS. FAILURE TO DO SO MAY RESULT IN EQUIPMENT DAMAGE AND / OR PERSONAL INJURY OR DEATH. • CLEAN UP ANY OIL OR FLUID SPILLS IMMEDIATELY. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 5 HAVE SUPERVISOR ADD ADDITIONAL PRECAUTIONS RELATING TO THE SPECIFIC WORK AREA AND LOCAL SAFETY REGULATIONS BELOW: MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...

  • Page 6: Safety Precautions

    SURE HOSES ARE COMPLETELY CLEAR OF SPARKS AND HOT DEBRIS. HAVE ANOTHER PERSON STAND CLOSE TO HYDRAULIC POWER SOURCE CONTROLS TO OBSERVE OPERA- TION AND FOR EMERGENCY SHUTDOWN IF NECESSARY. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 7 THE STONE IS ALWAYS IN THE HORIZONTAL POSITION. THE HOOK IS ALSO USED IN THIS POSITION. THIS POSITION IS USED FOR THER- MITE WELD, PROFILE BLEND-INS AND REMOVAL. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 8 OTHER FLUIDS THAT MEET OR EXCEED THIS SPECIFICATION CAN BE USED. *SEE COLD WEATHER OPERATION HYDRAULIC OIL NOTE. 5. HAVE TOOL INSPECTED, AT LEAST ANNUALLY, BY MATWELD OR A MATWELD QUALIFIED SER- VICE REPRESENTATIVE TO DETERMINE IF TOOL IS IN NEED OF SAFETY CHANGES OR WORN PART REPLACEMENT.
  • Page 9 BLOW. THIS IS WHY IT IS VERY IMPORTANT TO DIRECT THE FLOW INTO THE TOOL CORRECTLY. REVERSING THE HOSES TO TEST MAY RESULT IN BLOWN SEALS, DAMAGE TO THE TOOL, AND PERSONAL INJURY. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 10 06900A MULTI-PURPOSE GRINDER 2/25/03 REV. 1 8/12/03 MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 11 1/4-20 X 5/8 BHCS A2499 1/4-20 WING NUT A5608 1/4-20 X 7/8 SET SCREW 06910 WRENCH 02919 CABLE STOP 02940 ADJUSTMENT NUT MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 12 06950A MULTI-PURPOSE GRINDER w/ BOLT-ON TRIGGER BAIL 11/24/04 "T" "P" MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 13 3/8 SAE FLAT WASHER A6200 1/4” I.D. DETENT PIN A2499 1/4-20 WING NUT A5608 1/4-20 x 7/8 SOCKET HEAD SET SCREW 06910 WRENCH MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 14 06950A MULTI-PURPOSE GRINDER w/ WELDED TRIGGER BAIL 06/27/05 "P" "T" "P" "T" MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 15 1/4-20 x 3/4 HEX HEAD BOLT A2048 5/16-18 NYLOCK NUT A3809 1/4 SAE LOCK WASHER SOME MODELS MAY HAVE (2) METRIC BOLTS ON MOTOR ASSEMBLY MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...

  • Page 16: Decal Legend

    06900A MULTI-PURPOSE GRINDER w/ TRIGGER CABLE ASSEMBLY 06950A MULTI-PURPOSE GRINDER w/ TRIGGER BAIL ASSEMBLY DECAL LEGEND MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 17 LARGED, DIMINISHED OR AFFECTED BY, AND NO OBLIGATION OR LIABILITY SHALL ARISE OR GO OUT OF THE RENDERING OF TECHNICAL ADVICE OR SERVICE BY MATWELD OR ITS AGENTS. THE FOREGOING MAY NOT BE CHANGED EXCEPT BY WRITTEN AGREEMENT SIGNED BY AN AUTHO- RIZED OFFICER OF MATWELD, THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE.
  • Page 18 09600A MULTI-PURPOSE GRINDER w/TRIGGER CABLE ASSEMBLY 06950A MULTI-PURPOSE GRINDER w/TRIGGER BAIL ASSEMBLY GENERAL NOTES: MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...
  • Page 19 09600A MULTI-PURPOSE GRINDER w/TRIGGER CABLE ASSEMBLY 06950A MULTI-PURPOSE GRINDER w/TRIGGER BAIL ASSEMBLY GENERAL NOTES: MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 08/09...

  • Page 20: Customer Information

    Name _____________________________________________________ Company___________________________________________________ Serial # of your Matweld tool___________________________________ (Upon receiving your Matweld tool, make sure to list serial number above so that a good record is kept for order information.) MATWELD HYDRAULIC TOOL LIST All Matweld Hydraulic Tools operate at 5 or 10 GPM @ 2000 PSI POWER UNITS: 00100K –...
