05400
ANGLE GRINDER
The Matweld Angle Grinder is a multi-
purpose grinding and cutting tool which
accepts a variety of accessory attach-
ments. It can be used for removing rust
and scale, grinding rail welds, frog
points, or anywhere a detailed grind is
required. The head assembly is a
adjustable to rotate 360 degree for
operator comfort.
MATWELD, INC.
Matweld reserves the right to change parts, features, or specifications without notice.
B
C
FLOW
PRESSURE
10 gpm
2000 psi
(38 lpm)
(140 bar)
PHONE:(270) 444-0085
A
RPM
DIMENSIONS
3800
A - 21"
B - 8"
C -12"
1
632 South 3rd Street
P.O. Box 2816 • Paducah, KY 42002
Fax: 270-443-6180
Website: www.matweld.com
Email: customerservice@matweld.com
WEIGHT
15 lbs.
(6.8 kg)
FAX:(270) 443-6180
REV.8/04
270-444-0085

Advertisement

loading
Need help?

Need help?

Do you have a question about the 05400 and is the answer not in the manual?

Questions and answers

Related Manuals for Matweld 05400

Summary of Contents for Matweld 05400

  • Page 1 10 gpm 2000 psi 3800 A - 21" 15 lbs. (38 lpm) (140 bar) B - 8" (6.8 kg) C -12" MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. REV.8/04...
  • Page 2 MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...

  • Page 3: General Safety Precautions

    TION, SAFETY OR MAINTENANCE OF THIS TOOL. FAILURE TO FOLLOW THESE INSTRUC- TIONS CAN RESULT IN PERSONAL INJURY OR EQUIPMENT DAMAGE. MATWELD HAS NO CONTROL OVER TOOL USE OR OPERATION ONCE IT LEAVES THE MATWELD PLANT. MATWELD HAS NO CONTROL OVER OPERATOR OR MAINTAINER SELEC- TION.
  • Page 4 ABRASIONS. FAILURE TO DO SO MAY RESULT IN EQUIPMENT DAMAGE AND / OR PER- SONAL INJURY OR DEATH. • CLEAN UP ANY OIL OR FLUID SPILLS IMMEDIATELY. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 5 HAVE SUPERVISOR ADD ADDITIONAL PRECAUTIONS RELATING TO THE SPECIFIC WORK AREA AND LOCAL SAFETY REGULATIONS BELOW: MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...

  • Page 6: Safety Precautions

    MAKE SURE HOSES ARE COMPLETELY CLEAR OF SPARKS AND HOT DEBRIS. HAVE ANOTHER PERSON STAND CLOSE TO HYDRAULIC POWER SOURCE CONTROLS TO OB- SERVE OPERATION AND FOR EMERGENCY SHUTDOWN IF NECESSARY. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 7 4. GRASP THE TOOL FIRMLY BEFORE DISENGAGING THE TRIGGER SAFETY LOCK. THERE WILL BE A SLIGHT TORQUE REACTION WHEN THE TRIGGER IS ENGAGED AND THE STONE IS ACTIVATED. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 8 OTHER FLUIDS THAT MEET OR EXCEED THIS SPECIFICATION CAN BE USED. *SEE COLD WEATHER OPERATION HYDRAULIC OIL NOTE. 5. HAVE TOOL INSPECTED, AT LEAST ANNUALLY, BY MATWELD OR A MATWELD QUALIFIED SERVICE REPRESENTATIVE TO DETERMINE IF TOOL IS IN NEED OF SAFETY CHANGES OR WORN PART REPLACEMENT.
  • Page 9 OFF HALF A TURN. 3.) TURN THE GRINDING HEAD BY HAND TO THE DESIRED POSITION AND RETIGHTEN BOLTS AND JAM NUTS. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 10 05400 RIGHT ANGLE GRINDER GENERAL NOTES: MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 11 RECT THE FLOW INTO THE TOOL CORRECTLY. REVERSING THE HOSES TO TEST MAY RESULT IN BLOWN SEALS, DAMAGE TO THE TOOL, AND PERSONAL INJURY. MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 12 05400 RIGHT ANGLE GRINDER MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 13 WING NUT A5608 1/4-20 X 1” SET SCREW 05419 PINION SHAFT OUT PUT GLAND 05435 SAFETY LEVER A6062 1/8” SPRING PIN MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 14 05400 RIGHT ANGLE GRINDER DECAL LEGEND MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180 Matweld reserves the right to change parts, features, or specifications without notice. 06/00 REV.8/04...
  • Page 15 ON ANY THEORY OF LIABILITY INCLUDING, WITHOUT LIMITATIONS, BREACH OF CONTRACT, TORT, (INCLUDING NEGLIGENCE OR STREET LIABILITY) AND NOT WITHSTANDING ANY FAIL- URE OF ANY REMEDY HEREIN OF ITS ESSENTIAL PURPOSE, EVEN IF MATWELD WAS AWARE OF THIS POSSIBILITY OF SUCH DAMAGE. MATWELD’S LIMITED WARRANTY AS SET FORTH...

  • Page 16: Customer Information

    Name _____________________________________________________ Company___________________________________________________ Serial # of your Matweld tool___________________________________ ( Upon receiving your Matweld tool, make sure to list serial number above so that a good record is kept for order information.) MATWELD HYDRAULIC TOOL LIST All Matweld Hydraulic Tools operate at...
