Summary of Contents for TieJus PG1
- Page 1 Make your life smarter and safer QUICK START GUIDE PG1 / PW1 SECURITY CAMERA WIRELESS | Wi-Fi | WEATHERPROOF...
-
Page 2: Warranty Service
How to Activate the Free 1-year Warranty Extension? Send us order number and SN number via email. Please email us within 30 days of receiving the camera. Email: Tech@tiejus.com More About Us Web: www.tiejus.com Facebook: https://www.facebook.com/tiejusoffice... - Page 3 Brand Story TieJus is a young and fresh security brand that has attracted millions of technology enthusiasts in just 6 months of establishment. TieJus is committed to creating a smarter and easier modern lifestyle for consumers. Let more consumers enjoy convenient modern life without worrying about information security.
-
Page 4: Table Of Contents
CATALOGS PAGE 1.1 What's in the Box - PG1 ---------------------------------------P1 1.2 What's in the Box - PW1 --------------------------------------P2 2.1 Product Diagram - PG1 --------------------------------------P3 2.2 Product Diagram - PW1 -------------------------------------P4 3. App Download and Installation --------------------------------P6 4. Accounts Registration ---------------------------------------P7 5. - Page 5 CATALOGS PAGE 8.3 Installation Angle -----------------------------------------P20 8.4 Installation Precautions ------------------------------------P20 9. Device Menu -----------------------------------------------P21 10. Zoom of the Camera----------------------------------------P22 11. PIR Motion Detection -----------------------------------------P23 11.1 Motion Detection Alarm Setting ------------------------------P23 11.2 Alarm Notification ----------------------------------------P24 11.3 Record/Playback/Delete -----------------------------------P24 12. Storage Instructions -----------------------------------------P25 13.
-
Page 6: What's In The Box
1.1 What's in the Box - PG1 Manual * 1 PG1 Camera * 1 Mount Bracket * 1 Screws Set * 1 Charging Cable * 1 Solar Panel * 1 NOTE: - TF Card and power adapter are not included. - Page 7 1.2 What's in the Box - PW1 Manual * 1 PW1 Camera * 1 Mount Bracket * 1 Screws Set * 1 Charging Cable * 1 Solar Panel * 1 NOTE: - TF Card and power adapter are not included. - TF Card references in the text are owned by SanDisk Corporation and are not intended for commercial use.
-
Page 8: Product Diagram - Pg1
2.1 Product Diagram - PG1 Name Sensor Type GC2063, 1/3 CMOS Wireless 2.4GHz/5GHz Wi-Fi View angle 355°Pan & 100°Tilt Product Weight 930g Particulars Wi-Fi Antenna Bracket Microphone White Light and IR Lamp Camera Lens Indicator Photosensitive PIR Sensor Element... -
Page 9: Product Diagram - Pw1
2.2 Product Diagram - PW1 Name Sensor Type GC2063, 1/3 CMOS Wireless 2.4GHz/5GHz Wi-Fi View angle 355°Pan & 100°Tilt Product Weight 877g Particulars Wi-Fi Antenna Bracket Microphone Camera Lens White Light and IR Lamp Indicator Photosensitive PIR Sensor Element... - Page 10 Particulars Reset Button TF Card Solar Panel Type-C Switch On/Off Power Port DC5V±5% Power On/Off Toggle power switch to turn on/off the camera Indicator Status Blinking blue light: awaiting Wi-Fi connection (slowly blinking) connecting the Wi-Fi/network anomaly (quickly blinking) Solid blue light on: the camera runs correctly Solid green light on: Device no ID/AP mode ( No ID: The camera does not have ID number/upgrade power failure key files lost.
-
Page 11: App Download And Installation
3. App Download and Installation O-KAM Pro is available for iOS and Android Search the name "O-KAM Pro" in the App Store (iOS) or Google Play (Android), or scan the QR code to download the App. NOTE: Please turn on both of the following permissions. ①... -
Page 12: Accounts Registration
4. Accounts Registration ① Please register an APP account and log in. ② If you have already registered, please log in directly. NOTE: ① Please tick "User Agreement" And "Privacy Policy"; ② If the verification code is sent out over time due to network problems, please try again later;... -
Page 13: How To Reset The Camera
5. How to Reset the Camera ① Go to the device homepage, select the camera you want to reset, and click "Delete Device" in the "Device Settings" to remove the camera from the app. ② Press the camera's reset button for 5-10 seconds until you hear the "reset successed, restarting the device"... -
Page 14: Add Camera To App
6. Add Camera to App 6.1 Preparations for Connection ① Insert a TF Card: Insert a TF Card into the camera to save video clips, or you can start the 3-day free cloud service. Without a TF Card or cloud service, no video will be saved. -
Page 15: Adding Methods
6.2 Adding Methods Method 1: Bluetooth Setup(Recommend) ① On the homepage, tap "Add" or the "+" icon in the upper right corner, then tap "Add Device". ② If Bluetooth on your phone is not turned on, a pop-up will appear. Please allow it to turn on Bluetooth. - Page 16 ④ Select the 2.4GHz/5GHz Wi-Fi network you want the camera to connect to and enter the password. When Bluetooth is on, the app will automatically show available 2.4GHz or 5GHz Wi-Fi networks. If you can't find your Wi-Fi network, please contact your router provider to check the Wi-Fi settings.
-
Page 17: Method 2: Qr Device Code Setup
Method 2: QR Device Code Setup Tap "Add Device" Scan QR Code Turn on the Camera Select Camera Input Wi-Fi Password Connect the Camera... - Page 18 09:50:29 08-21-2024 Name the Camera View Installation Tips Check the Wi-Fi Signal 09 : 53 : 54 08-21-2024 Setup Configuration Using the Camera...
-
Page 19: Method 3: Manual Add
Method 3: Manual Add ① Open the mobile APP, please click "+" in the upper right corner. ② Select "Wireless Camera" and follow the guide of your phone to complete the device binding. NOTE: ① The routers only with 2.4GHz capability, you can only select the 2.4GHz signal during configuration.If your router is dual-band, you can pick the 2.4GHz or 5GHz signal during configuration. -
Page 20: Camera Installation
7. Camera Installation 7.1 Installation Preparation ① Surface Selection: Choose a clean, smooth, and dry surface for mounting the bracket. Avoid uneven surfaces like wood veneer or plaster walls. ② Bracket Mounting: Use the provided positioning stickers and screws to securely attach the bracket to the wall. -
Page 21: Mounting Position And Angle
7.2 Mounting Position and Angle ① Location: Ensure the camera's view is unobstructed and the app shows that the camera is receiving a strong Wi-Fi signal. ② Mounting: - Select an appropriate position on the wall to mount the camera. - Place it directly on the table. - Page 22 ③ Angle for Motion Detection: - Aim the camera to cover the lower two-thirds of the field of view, which is the most sensitive to motion. - For close monitoring (e.g., front door), mount the camera 7-10 feet (2-3 meters) high.
-
Page 23: Best Practices For Motion Detection
7.3 Best Practices for Motion Detection - Motion Path: Position the camera so that motion moves side-to-side across its view rather than directly toward or away from it. - Detection Range: Optimal motion detection occurs within 5 to 20 feet (1.5 to 6 meters) from the camera, though it can detect motion up to 33 feet (10 meters). -
Page 24: Solar Panel Installation
8. Solar Panel Installation 8.1 Installation Steps ① Use Power Drill and two screws to fix the camera bracket on the wall. Align the screw cap of the bracket with the screw hole on the back of the solar panel and rotate it clockwise to fix it. -
Page 25: Installation Location
8.2 Installation Location - Find a location that receives sunlight for most of the day to ensure maximum exposure. - The solar panel needs a few hours of direct sunlight to convert solar energy into electricity. The conversion efficiency is affected by weather conditions, seasonal changes, geographic locations, etc. -
Page 26: Device Menu
9. Device Menu 09 : 53 : 54 08-21-2024 3.0KB/s 09 : 53 : 54 08-21-2024 3.0KB/s 09 : 53 : 54 08-21-2024 3.0KB/s 09 : 53 : 54 08-21-2024 More Functions Two-Way Talk Add Device and Scan Code Camera Name Full Screen View Real Time Live... -
Page 27: Zoom Of The Camera
10. Zoom of the Camera 09 : 53 : 54 08-21-2024 3.0KB/s 09 : 53 : 54 08-21-2024 3.0KB/s PG1: Dual lens zoom PW1: Live Screen Zoom... -
Page 28: Pir Motion Detection
11. PIR Motion Detection 11.1 Motion Detection Alarm Setting 09 : 53 : 54 08-21-2024 3.0KB/s 09 : 53 : 54 08-21-2024 Select Camera Select "Motion Detection" Set it up NOTE: - In order to obtain the alarm message push function, please enable the push permission of the APP in the mobile phone system. -
Page 29: Alarm Notification
11.2 Alarm Notification ① Recording Type: This camera does not support continuous 24/7 recording. It activates only when motion is detected. ② System Reactions: - Alarm Notifications: Receive sound alerts via the app. - Storage: Pictures and videos are automatically saved to the TF Card or cloud storage. -
Page 30: Storage Instructions
12. Storage Instructions ① Manual Storage - Go to the live video feed and manually record by clicking the "Record" button to start or stop. - Recordings will be stored in your app's album. - Exiting the live view will automatically stop the recording. ②... -
Page 31: Power Saving Settings
13. Power Saving Settings 13.1 Motion Detection Frequency This feature helps prevent multiple alarms for the same event. You can customize the motion detection frequency by setting different intervals. For instance, if the frequency is set to 30 seconds, and the camera is triggered at 8:00 AM, you'll receive an alarm notification but won't get another one within the next 30 seconds, even if motion persists. -
Page 32: Detection Schedule
13.3 Detection Schedule You can set a weekly or daily alarm schedule as needed. For example, if the camera's working hours are set from 0:00 to 1:00, the camera will only be triggered and record alarm video during this period. 13.4 Battery Management ①... -
Page 33: Custom Non-Detection Area
13.5 Custom Non-Detection Area You can masking off unnecessary detection areas, such as distant roads and frequently blown tree branches, to reduce false alarms. 09 : 53 : 54 08-21-2024 3.0KB/s 14. Multi-Camera Management Watch 4 Cameras Live at the Same Time 09 : 53 : 54 08-21-2024 Garden Backyard... -
Page 34: Multi-User Sharing
15. Multi-User Sharing Sharing Steps: ① B downloads the O-KAM Pro App on their phone and creates a new account. ② B clicks "Add" in the App on their phone. ③ B scans A's QR code. ④ A accepts the share and refreshes the device page. 09 : 53 : 54 08-21-2024 QR code sharing Scanning the QR code... -
Page 35: How To Find The Uid/Sn Number
If you have any other questions, please send us the UID/SN number of your camera and describe the problem you have encountered. We will resolve it as soon as possible. Email: Tech@tiejus.com 09 : 53 : 54 08-21-2024 Click Settings... -
Page 36: Faq
17. FAQ Q1: How do I invite family and friends to use my camera together? A1: Open the APP and select your camera in the home page. Click "Share" in the camera settings to enter the sharing page, and a QR code will be generated. Your friends can open the app and gain some access by scanning the OR code in their phone. - Page 37 Q6: What should I do if the equipment fails? A6: Long press the power button to restart the camera. If the device no response, you can open the USB silicones cover at the bottom of the camera, long press the reset button to reset and then long press the power button to restart the camera.
- Page 38 ③ The recommended TF Card capacity is between 16-256G. ④ Recommend to use a high-speed TF Card of Class 10 and above. ⑤ Try to insert and remove the TF Card several times. ⑥ It is recommended to try another TF Card. ⑦...
- Page 39 Please Email us for Better Solution instead of returning any unqualified product to Amazon Tech@tiejus.com THANK YOU Made in China FCC ID : 2A7TD-BW4...
