- Page 1 Terra Desk Assembly Instructions...
- Page 2 Congratulations on your new EFFYDESK! This guide will walk you through the step-by-step process of assembling your standing desk. With clear instructions and helpful tips, you’ll have your desk set up and ready to use in no time! • Estimated Assembly Time: 30 minutes to 1 hour •...
- Page 3 1. Power Cable (1) 6. Lifting Column (2) 2. Control Box (1) 7. Keypad (1) 3. Extension Cord (1) 8. Foot (2) 4. Side Bracket (2) 9. Cable Tray (1) 5. Crossbar (1) Tools Required: A. 3mm Allen Key (Included) B.
-
Page 4: Pre-Assembly Notes
Accessories List from Terra Table Top Package: K. Control Box (1) N. Wireless Charging Inset Keypad (1) L. Power Cable (1) O. Wireless Charging Circular Pad (1) M. Extension cord (1) P. Keypad cord (1) Pre-Assembly Notes • Please note in the assembly instructions that specific instructions apply for certain tabletop sizes. - Page 5 Step-by-Step Assembly Instructions Setting up your Frame: Separate the Crossbar Ends and you will find the Crossbar Rail inside. Insert one of the Crossbar Ends into one of the Lifting Columns and secure with screws. Repeat the same step for the other Lifting Column.
- Page 6 Slide the two Crossbar Ends back into the Crossbar Rail. Please make sure they fit into the slots as shown below. Slider for control box Attach both Feet to the bottom of the Lifting Columns. Allen Key Secure hangers onto the Crossbar Based on whether your tabletop size is A (Small/Medium) or B (Large), follow the corresponding images below to correctly place and attach the screws to the hanger on the crossbar.
- Page 7 Connecting your Wireless Charger: Insert the rounded end of the split cable into the Wireless Charging Pad. Note: The Terra Desk keypad controller is already em- bedded in the tabletop, so you don’t need to attach it manually. For small sized Terra table tops.
- Page 8 8. A. Plug the third end of the split power cable into the control box. Then, insert the remaining end into the HS Keypad port, located next to ports M1 and M2. Attaching the Table Top to the Frame: Install the tabletop Pre-drilled Non pre-drilled...
- Page 9 11. A. Allen Key 11. B. Tighten the middle crossbar For large tabletops, use the screws to tighten the middle crossbar. For small/medium tabletops, disregard this step. Allen Key...
- Page 10 Connecting the Cords Together: Firmly secure the Crossbar with Screws and connect all the cables to the Control Box Note: The Control Box is equipped with a gyro sensor so the table and the Control Box must be leveled in order to work properly or else it will not move up or down.
- Page 11 Attach the Cable Tray to the Hangers with screws. Allen Key Attach the Keypad with Screws to the tabletop. Screwdriver...
- Page 12 Flip the table onto its feet. Final Checks & Powering Up Final Check Before plugging in the table, make sure that: The Control Box is flat and secure, not hanging. The desk won’t work properly if the built-in gyro sensor detects it’s not levelled. The Lifting Columns are level and set at their lowest position.
- Page 13 Initial Calibration and Reset Required for First-Use Calibrate the desk by following the steps below: Please press the Down button and hold for 10-15 seconds until the table stutters and beeps. Release the button. Your desk is ready to use! Operation Guide Adjust the table to the desired height, then press M.
-
Page 14: Troubleshooting And Faqs
Press by holding 10-15 seconds If “HOT” appears on the display Please unplug and replug and let it cool off for a couple of minutes before proceeding. Troubleshooting & FAQs Using the Wireless Charging Feature Place your phone or tablet directly on top of the wireless charging area indicated by the two L shaped markings on the left-hand side of the desk. - Page 15 Replacing your Wireless Charger Unplug the power cable from the outlet. Locate the wireless charging plate underneath the tabletop and remove its screws. Do the same on the new wireless charging plate to prepare it for installation. New Wireless Charger Replacement...
- Page 16 Remove screws from Remove plate backing new wireless charger Old Wireless Charger New Wireless Charger Replacement...
- Page 17 Take out the old charging plate and place the new one in its position. Secure it using the same 4 screws from the original plate.
-
Page 18: Customer Support Information
Repeated exposure to puddles can distort the surface of the Terra top. Customer Support Information If you have any further questions, feel free to reach out to our EFFY Experts at team@effydesk.com — we’re happy to help! - Page 19 110-2440 Canoe Avenue 604-715-7577 Coquitlam, BC team@effydesk.com Canada effydesk.com...
