- Page 1 M2AI-2280-720 Dual Kneron KL720 NPU M.2 2280 B-M key Module User’s Manual 1 Last Updated: February 10, 2025...
- Page 2 Copyright Notice This document is copyrighted, 2025. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
- Page 3 Acknowledgements All other products’ name or trademarks are properties of their respective owners. Microsoft Windows® and Windows® 10 are registered trademarks of Microsoft ⚫ Corp. Ubuntu is a registered trademark of Canonical ⚫ Kneron and the Kneron logo are trademarks of Kneron Inc. ⚫...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity M2AI-2280-720 M.2 Module ⚫ M3 screw ⚫ If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
- Page 5 About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page on AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON 主板/子板/背板 QO4-381 Rev.A2 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 本表格依据 SJ/T 11364 的规定编制。 ○：表示该有毒有害物质在该部件所有均质材料中的含量均在GB/T 26572标准规定...
- Page 10 China RoHS Requirement (EN) Name and content of hazardous substances in product AAEON Main Board/Daughter Board/Backplane QO4-381 Rev.A2 Hazardous Substances 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 Part Name (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB Assemblies × ○ ○ ○ ○...
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications ..................1 M2AI-2280-720 Kneron NPU Module Specifications ........2 Chapter 2 – Hardware Information ..................3 Dimensions ......................4 Block Diagram ......................7 Board Design ......................8 List of Jumpers ......................9 2.4.1 Wake function Connector (Option) (JP1) .......... -
Page 12: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 13: M2Ai-2280-720 Kneron Npu Module Specifications
M2AI-2280-720 Kneron NPU Module Specifications System Kneron KL720 Type ARM CM & DSP Support Framework Pytorch, ONNX, TensorFlow 1.6, Tensorflow lite, Keras, Caffe Support Model Resnet, GoogleNet, YOLO, Tiny YOLO, MobileNet-SSD, DenseNet, RNN, LSTM Memory Type 128MB LPDDR3 NPU Performance 1.4 TOP/s x2 Overall Power Consumption Others... -
Page 14: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information... -
Page 15: Dimensions
Dimensions Component Side Chapter 2 – Hardware Information... - Page 16 Solder Side Chapter 2 – Hardware Information...
- Page 17 Cooler Assembly Chapter 2 – Hardware Information...
-
Page 18: Block Diagram
Block Diagram Chapter 2 – Hardware Information... -
Page 19: Board Design
Board Design Chapter 2 – Hardware Information... -
Page 20: List Of Jumpers
List of Jumpers Please refer to the table below for all of the board’s jumpers that you can configure for your application. Label Function Wake function Connector(Option) Reset function Connector(Option) 2.4.1 Wake function Connector (Option) (JP1) Normal Mode Wake function 2.4.2 Reset function Connector (Option) (JP2) Normal Mode... -
Page 21: List Of Connectors
List of Connectors This section details the connectors featured on the AI Core X module. This is a reference to help with setup and configuration for your application. Label Connector Type M.2 2280 B+M key KL720-1 UART0 connector(Option) KL720-1 UART1 connector(Option) KL720-2 UART0 connector(Option) KL720-2 UART1 connector(Option) FAN connector... - Page 22 Signal Type Description Ground Ground Ground Ground PERn0 PCIe Lane 0 Rx PERp0 PCIe Lane 0 Rx Ground Chapter 2 – Hardware Information...
- Page 23 Signal Type Description PETn0 PCIe Lane 0 Tx PETp0 PCIe Lane 0 Tx PERST# PCIe reset Ground CLKREQ# Reference clock request signal REFCLKN PCIe Reference Clock signals (100MHz) PEWAKE# PCIe WAKE# Open Drain with pull up on platform. Active Low. REFCLKP PCIe Reference Clock signals (100MHz) Ground...
-
Page 24: Kl720-1 Uart0 Connector (Option) (Cn2)
2.5.2 KL720-1 UART0 connector (Option) (CN2) Pin Name Signal Type Signal level X_UART0_TX_1 3.3V X_UART0_RX_1 3.3V 2.5.3 KL720-1 UART1 connector (Option) (CN3) Pin Name Signal Type Signal level X_UART1_TX_1 3.3V X_UART1_RX_1 3.3V Chapter 2 – Hardware Information... -
Page 25: Kl720-2 Uart0 Connector (Option) (Cn4)
2.5.4 KL720-2 UART0 connector (Option) (CN4) Pin Name Signal Type Signal level X_UART0_TX_2 3.3V X_UART0_RX_2 3.3V 2.5.5 KL720-2 UART1 connector (Option) (CN5) Pin Name Signal Type Signal level X_UART1_TX_2 3.3V X_UART1_RX_2 3.3V Chapter 2 – Hardware Information... -
Page 26: Fan Connector (Cn6)
2.5.6 FAN connector (CN6) Pin Name Signal Type Signal level +3.3V 3.3V Chapter 2 – Hardware Information...
