sky viper M500 Flying Manual

M500
NANO DRONE
POWERING UP AND PAIRING (WITH ALTITUDE ON)
OFF ON
Turn on drone.
FLYING BASICS (IN AUTO ASSIST MODE)
1
Press Auto Launch to launch a few feet off the ground.
3
Press the directional Thumbstick to fly in any direction.
FLIGHT CONTROLS
THROTTLE/ROTATION STICK
• While in manual flight mode push the throttle
stick forward to make drone lift.
• The further you push the throttle stick, the
faster you lift.
(
Up and down controls only apply to manual
Press up
flight mode.
to lift
Power On/off Switch/sensitivity Switch
Stunt Button
Press down
to descend
THROTTLE/
ROTATION STICK
Press left
to rotate
counter-
clockwise
Press right
to rotate
clockwise
Rotation Trim
ALTITUDE BUTTONS
• Press the up or down arrow to adjust
the drone's altitude. The drone will lift
or lower approximately 12" each time
the up or down arrow is pressed.
(Distance may vary.)
• Hold the up or down buttons for
continuous lift or descent.
FLIGHT SENSITIVITY SWITCH
The Drone's responsiveness may be adjusted on the Controller to match your flying skills.
There are two options: 1 LOW sensitivity
It is best to start in the low sensitivity position until you have mastered flying. Flight sensitivity
can be adjusted before or during flight.
DEFAULT FLIGHT MODE
Each sensitivity setting has a default flight mode, either
auto-flight assist or manual mode.
Place drone on flat surface.
2
Press the Altitude button to fly approximately 12" higher or lower.
4
Press the Auto Land button to land.
DIRECTION STICK
• Push the direction stick forward to fly forward or
away from you (Green blade in front). Push
backwards to fly backward. The further you push,
the faster the drone will fly in that direction.
(
• Push the direction stick left to fly left. Push right
to fly right. The further you push, the faster
the drone will fly sideways.
AUTO LAUNCH/LAND BUTTON
• Press the auto launch
button to launch a few feet
from the ground.
(Exact height may vary.)
• Press the auto land button
to land the drone by itself.
2 HIGH sensitivity
2 2
LOW HIGH
1 1
OFF OFF
Turn on remote.
Press up to
fly forward
Forward/Backward Trim
Power indicator LED
Press down
to fly
backward
DIRECTION STICK
Press left
to fly left
Press right
to fly right
Left/Right Trim
2
(MANUAL)
1
(AUTO)
OFF
FLYING GUIDE
Wait for flashing green lights to turn solid.
MANUAL FLIGHT MODE
• Switch to sensitivity mode 2 to go into manual flight.
TOGGLE INTO MANUAL FLIGHT
• Hold stunt button and press auto land/auto launch
button and a tone will sound from the remote. Make
sure your throttle stick is in the down position.
• Push the throttle stick up to begin manual flight.
TOGGLE INTO MANUAL FLIGHT WHILE IN AUTO-HOVER
• Hold stunt button and press auto land/auto launch
button.
• Move the throttle stick up until the drone starts to
rise. (If throttle is not matched in 5 seconds then
manual flight will be cancelled.)
TOGGLE INTO AUTO HOVER WHILE IN MANUAL FLIGHT
• Press either the up or down altitude locking button to
toggle back into auto hover. (Your drone will hover at the
current throttle speed.)
FLYING TIPS
• When launching the drone, face the same
direction as the drone. Green blades and green
LEDs should be in front.
• If your drone drifts in any direction when you are
hovering, you will need to make Trim
adjustments to correct the driving. Trim
adjustments are sometimes needed when the
drone is first flown after purchase. See TRIM
ADJUSTMENTS section for details.
• Practice launching, hovering and landing before
attempting to learn other moves.
• Flying 2 to 3 feet above the ground will reduce
ground turbulence and make flying easier.
• When first attempting to fly in different
directions, start by tapping the direction stick
until you have a feel for it. Always move controls
slowly until you become comfortable operating
the drone.
• Once you've mastered flying in directions,
practice rotational controls. Spinning and
keeping drone facing the same direction as you
makes flying easier and more intuitive.
• Stay 2 to 3 feet away from walls and ceilings
as drone will be drawn towards them if you fly
too close.
• If propeller blades come in contact with
another object or you crash, throttle down or
auto land immediately to prevent possible or
further damage.
• If anything prevents drone's blades from
spinning or they become jammed, throttle
down or auto land immediately. Do not attempt
to fly until obstruction has been removed and
damage fixed.
• Should something prevent drone's blades from
spinning, drone may auto shutdown. LiPo
battery will need to be unplugged then
reconnected to restore flying power.
• If the drone flies too far away, beyond the
control range of the remote, the drone will
auto-land to prevent the drone from flying away
out of control.
Online Video
Instructions & Flying
Tips available now at
SKYVIPER.COM
AGES 12+
