- Page 1 HDMI® KVM Switch 2 In 1 Out Model: AK502 User Manual...
-
Page 2: Specifications
Windows/macOS/Linux Dimensions L114×W63×H19(mm)/L4.5×W2.5×H0.7(inch) The data are measured by UGREEN lab but may vary based on specific circumstances. The video output resolution depends on the video bandwidth of the signal source device, the video cable, and the maximum resolution supported by the display... -
Page 3: Product Overview
Product Overview HDMI Signal Signal Switch Indicator Button Mini USB Port USB-C USB-A (for desktop controller) Output Port Output Port Power Port PC2 Input PC1 Input USB-A Data & HDMI USB-A Data & HDMI (DC 5V) Video Input Port Video Input Port USB-A Output Port HDMI Output Port... - Page 4 Connection Step 1: Connect to Signal Source Devices: Use both the included HDMI cable and USB-A data cable to connect PC 1 to the "PC1 Input" ports, and then connect PC 2 to the "PC2 Input" ports. HDMI Cable (for video transmission ) USB-A Cable (for data transmission) Note: Each signal source device must be connected with both the HDMI cable and the USB-A data cable to function properly.
- Page 5 Step 3. Connect to USB Devices: Connect the USB devices to the USB-A and USB-C output ports. ··· Mouse/Keyboard/USB Flash Drive/Hard Drive Enclosure/Printer ... Step 4. Connect to Power Supply: Connect the included power adapter to the power port. Power Adapter Tips ·...
- Page 6 FAQs 1. What should I do if the display device does not display any images after connection? · Please ensure the product is connected correctly and the length and specifications of the cable meet the product requirements. · Please select the correct input signal source (some monitors require manual selection), and try adjusting the color space and color depth.
- Page 7 4. What should I do if the HDMI port works normally but the USB port does not work? · Please ensure that both the USB-A cable and the HDMI cable are connected to the same signal source device. · Try replacing the signal source device and the USB device. ·...
-
Page 8: Package Contents
Notes · Do not throw or drop the product or subject it to strong physical shock. · Do not dismantle or fix the product by yourself, please contact UGREEN after-sales service if necessary. · Please do not leave the product in extreme temperature or moist environments. - Page 9 The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
