Peavey Decade Too Operating Manual

Peavey Decade Too Operating Manual

Guitar amplifier and extension cab
Hide thumbs

Advertisement

Table of Contents

Decade
Too
®
Guitar Amplifier
and Extension Cab
Operating
Manual
www.peavey.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Decade Too and is the answer not in the manual?

Questions and answers

Related Manuals for Peavey Decade Too

Summary of Contents for Peavey Decade Too

  • Page 1 Decade ® Guitar Amplifier and Extension Cab Operating Manual www.peavey.com...
  • Page 2 FCC/ICES Compliancy Statement  This device complies with Part 15 of the FCC rules and Industry Canada license‐exempt RSS Standard(s).  Operation is  subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must  accept any interference received, that may cause undesired operation.  Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de  licence.  L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de  brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le  brouillage est susceptible d’en compromettre le fonctionnement.  Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the  user’s authority to use the equipment.  Note – This equipment has been tested and found to comply with the limits for a Class B digital device,  pursuant to Part 15 of the FCC Rules.  These limits are designed to provide reasonable protection against  harmful interference in a residential installation.  This equipment generates, uses, and can radiate radio  frequency energy and, if not installed and used in accordance with the instructions, may cause harmful  interference to radio communications.  However, there is no guarantee that interference will not occur in a  particular installation.  If this equipment does cause harmful interference to radio or television reception,  which can be determined by turning the equipment off and on, the user is encouraged to try and correct the  interference by one or more of the following measures.  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.   Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Page 3 To make the Decade Too™ even more versatile, a preamp out jack has been included on the rear panel to allow driving external power amps, tape decks, etc.. Doctor Joshua also chose to add a buffered effects loop, transformer balanced XLR direct interface, external speaker jacks, and an all new speaker phase switch to take this little guy to the next level.
  • Page 4 - All-new 8", 8 Ohm Celestion driver voiced like the old Rola speaker, circa 1980. - Heavy-gauge steel rack and screw handles allow for precise vertical rotation of the cabinet. - DECADE TOO amplifier nests squarely into the top of the rack for superior floor coupling without affecting the "floating" cabinet.

  • Page 5: Front Panel

    Multi-purpose 2-button footswitch WITHOUT LEDs) as might be required in the studio or home recording situation and is another indication of the unique design of the JOSHUA HOMME DECADE TOO™. NOTE: Using a footswitch with LEDs will not allow for remote switching of the SATURATION™ effect.

  • Page 6: Power Switch And Led

    EQ has virtually no effect, our equalization circuitry provides a drastic change in tonality. To achieve an even greater range, the low frequency EQ has been designed to slightly overlap the action of the middle control to facilitate these two controls “interfacing” to produce the subtle tonal variation so often needed in modern music.

  • Page 7: Rear Panel

    This new ¼” TRS jack allows for remote switching of both the SATURATION™ and effects loop de- feat functions. Use Peavey #03620970, Multi-purpose 2-button footswitch WITHOUT LEDs. NOTE: Using a footswitch with LEDs will not allow for remote switching of the SATURATION™ effect.

  • Page 8: Speaker Outputs

    Doctor Joshua. 18) SPEAKER OUTPUTS These paralleled ¼” speaker outputs are used to drive the internal speaker of the Decade Too™ in addition to another 8 Ohm cabinet, if desired. Minimum total impedance is 4 Ohms.

  • Page 9: Specifications

    Specifications POWER AMPLIFIER SECTION: FREQUENCY RESPONSE +0, -3 dB, 60 Hz to 10 KHz@ 1W into 4 ohms RATED POWER & LOAD: 10W AMS into 4 ohms POWER@ CLIPPING: 4 ohms, 1 KHz, 120 VAC line Typically: 12W RMS@5% THD 14W RMS@10% THD POWER@ CLIPPING: 4 ohms.
  • Page 10 Warranty registration and information for U.S. customers available online at www.peavey.com/warranty or use the QR tag below Features and speci cations subject to change without notice. Peavey Electronics Corporation 5022 Hartley Peavey Drive Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005...
