Night Shark IP Subsea Camera
U S E R
IMENCO AS
Org No: 923 005 749 MVA
M A N U A L
Visiting Address:
Stoltenberggata 1, 5527 Haugesund, Norway
Mail Address:
PO. Box 2143, 5504 Haugesund, Norway
Night Shark IP - User Manual
Office: +47 52 86 41 00
Fax:
+47 52 86 41 01
1
R1.2
imenco@imenco.com
www.imenco.com
Advertisement
Table of Contents
Related Manuals for imenco Night Shark IP
Summary of Contents for imenco Night Shark IP
- Page 1 R1.2 Night Shark IP - User Manual Night Shark IP Subsea Camera U S E R M A N U A L IMENCO AS Visiting Address: Stoltenberggata 1, 5527 Haugesund, Norway Office: +47 52 86 41 00 imenco@imenco.com Org No: 923 005 749 MVA Mail Address: PO.
-
Page 2: Table Of Contents
Contact ..........................3 Warranty..........................4 General Description ....................4 Regarding these Instructions for Use ............... 4 The Night Shark IP camera ..................5 Main Features ......................5 Typical use case ..................... 6 Remote display and control station ..............7 Technical Specification ....................7 Functional Description .................... -
Page 3: Contact
E-mail: imenco@imenco.com www.imenco.com Safety information IMPORTANT! The Imenco Night Shark IP camera is a technically advanced product. Please make sure to read and understand all sections of this manual before installing or operating this product. Installation of this product should only be performed by qualified personnel. -
Page 4: Warranty
Warranty Be sure to read and comply with Imenco’s Terms & Conditions that the Night Shark IP Camera was sold under. General Description... -
Page 5: The Night Shark Ip Camera
Night Shark IP - User Manual The Night Shark IP camera The focus settings of this camera are calibrated for underwater use and have a limited focus area in air. Camera block diagram: Actual camera: DC power Ethernet Subsea View... -
Page 6: Typical Use Case
(e.g. Imenco SmartView) installed for decoding and using the received video. The Ethernet communication of the two Night Shark IP in Figure 2 are combined in a Switch and routed through various other Networking hardware before connected to the client computer. Beware that the network infrastructure and... -
Page 7: Remote Display And Control Station
Ethernet. A computer with sufficient graphics performance and network interface can be used to operate and view / record video from the Night Shark IP camera. Camera setup can be performed by the built-in web interface. This Imenco camera can be supplied together with the Imenco SmartView software for viewing, frame snapshots and video recording, please refer to the SmartView User manual for these functions. -
Page 8: Functional Description
Series Power / Ethernet Circular 13 pins type. Imenco offers customer specified (Cat5e approved) connectors and cabling with the Night Shark IP camera. Contact Imenco to work out a solution for other than standard connectors. The IEEE standards 100BASE-TX and 1000BASE-T defining 100Mb/s and 1000Mb/s data rates over twisted pair copper cables recognize up to 100 m length between nodes. -
Page 9: Installation Instructions
Installation Instructions Make sure that Imenco’s Terms & Conditions are followed when using this product. Unpacking and testing When having received the camera, do a visual inspection for damage of the packet or any of the parts. -
Page 10: Mechanical Installation
Standard Subsea connector type pin-out: Figure 5, Night Shark IP camera - standard connector and RJ45 plug with T568B colours Imenco Future Technologies Visiting Address:... -
Page 11: Adding The Camera To A Computer Network
Optional u se Green Table 4, Night Shark IP camera standard subsea connector pinout (Ethernet connected as T568B) 5.6 Adding the camera to a computer network The camera must be connected to a computer that functions as the remote control and video viewing / recording station. -
Page 12: Operational Instructions
Running the camera on your office network is not advised because of the large and constant data output. The intended use of the Night Shark IP camera is to assign each camera a fixed network address within a closed network. - Page 13 Night Shark IP - User Manual Factory Reset To reset the camera to Imenco Default Settings, log in to the camera Web Interface and go to Save/Load Settings. Click “Load Settings from File” and select the file in the USB- drive provided by Imenco called “WAT-933_Setting.set”.
-
Page 14: Displaying The Video Stream
Media players To view the video stream from the Night Shark IP Camera in a 3. Party media player like VLC, paste in the following URL: rtsp://192.168.1.2:554/h264 Please be aware that most standard media players are not optimized for low latency streaming and can add a considerable amount of delay. -
Page 15: Camera Module Settings
Night Shark IP - User Manual Camera module settings The camera module settings can be altered via the built in Web Interface of the module. To login, go to the current camera IP address in a browser. The available menu options for network, image and video settings are: Digital Noise reduction can be adjusted in the “Output Set”... -
Page 16: Maintenance
Failure to comply may result in personal injury, damage to equipment and loss of warranty. If the Night Shark IP camera seems to be not working properly, please try to speed up the service that Imenco can provide by describing the problem in specific terms from the person who have first handed observed the fault.
