Summary of Contents for Robus RCC-3060-WH
- Page 1 TRIPOD / MONOPOD CARBON FIBER WITH BALLHEAD RCC 3060 WH...
- Page 2 Precautions • Do not exceed the tripod’s maximum load capacity. • Ensure that all appropriate locks are engaged when necessary. • This ballhead should be used only in temperatures ranging between -22°F and 140°F. Do not operate in salt water. Dry the ballhead if it becomes wet. •...
-
Page 3: Specifications
Specifications Maximum Load 30 lb. (13. 6 kg) Quick-Release Plate Type Arca-type Maximum Height 60 in. (152. 4 cm) Camera Mounting Screw 1/4-20 Minimum Height 7. 5 in. (19 cm) Controls Quick-release knob Ballhead lock Folded Length 24. 5 in. (62. 2 cm) Pan lock Leg Sections Leg angle lock (×3) - Page 4 Extending the Tripod Legs Turn each twist-lock clockwise, and extend each leg to the desired length. Turn the twist-locks counterclockwise to tighten. Adjusting the Leg Angles 80° The legs can be set at one of three angles. Lift the leg angle lock, adjust the leg, and press down on the lock.
- Page 5 Swapping the Feet The tripod comes with the rubber feet installed. To swap the feet, unscrew the rubber feet, and replace them with the included spikes. Using One Leg as a Monopod The leg with the leg warmer can be used as a monopod. Unscrew the leg, attach the appropriate foot, and adjust to the desired height.
- Page 6 Ballhead Overview Quick-release plate Attach the plate to the base of a camera or accessory with the 1/4-20 mounting screw, and tighten the screw with the D-ring or a screwdriver. 1/4-20 mounting screw Quick-release knob Set the plate into the clamp, and tighten the knob until secure.
- Page 7 Adding Extra Accessories Customize your setup by using the 1/4-20 threaded socket to attach accessories like a flexible or articulating arm. Adding a Counterweight To prevent wobbling or tipping when the tripod is set up on an uneven surface or in windy conditions, hang a counterweight or sandbag on the weight hook.
-
Page 8: Ten-Year Limited Warranty
To obtain warranty coverage, contact the Robus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Robus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’ s own risk and expense.
