- Page 1 75 mm Aluminum HALF BALL LEVELING ADAPTER HBLA 75M...
- Page 2 Thank you for choosing Robus The Robus 75 mm Half Ball Leveling Adapter is compatible with Robus Vantage Series 3 and 5 tripods. This adapter lets you mount any 3/8-16 flat-base photo or video head into the Vantage tripod’s 75 mm video bowl and adds a camera levelling function for perfectly level camera angles.
- Page 3 Specifications Height 4. 5 in. (11. 4 cm) Ball Diameter 2. 9 5 in. (75 mm) Handle Length 3. 2 in. (8. 1 cm) Mount 3/8-16 screw Material CNC machined aluminum Bubble Level Set Screws Yes, 3 Weight 9. 3 oz. (264 g)
- Page 4 Overview 3/8-16 mounting screw 75 mm ball Handle Set screws Bubble level...
- Page 5 Attaching the Half Ball Adapter Unscrew the handle from the half ball, and place the half ball into the tripod’s video bowl. Screw handle into the half ball from under the video bowl until it’s secure.
- Page 6 Mounting and Adjusting Camera Angles Mount a head onto the 3/8-16 screw, and then mount your camera onto the head. To adjust the camera angle, loosen the handle and use the bubble level to ensure your camera is level. Once the camera is level, tighten the handle until secure.
- Page 7 Important! Always support your camera with one hand when loosening the handle.
- Page 8 To obtain warranty coverage, contact the Robus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Robus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’ s own risk and expense.
