Robern AIO AR2030D4FP1 Mounting Instructions

CONTENTS
Safety - 2
Lighting Controls - 2
Tools Needed - 3
Parts - 3
Accessories - 4
Dimensions - 6
Recess Mounting - 7
Electrical Connection - 10
Final Assembly - 11
Use and Maintenance - 14
Warranty - 14
GENERAL INFORMATION
This instruction manual contains information on how to recess mount the AiO Reserve cabinet. This series comes in many sizes. Refer
to the specific model numbers for dimensions. These cabinets are modular and can be paired with compatible products.
The cabinet can be recess mounted using the included hardware, or surface mounted using an optional installation kit (not included).
See page 4 and 5 for all accessory and mounting options. Read the specific instructions for how your cabinet will be mounted.
Save these instructions for future use and reference. An improper installation voids the warranty. Installed cabinets cannot be returned.
If you experience any problems with your cabinet, contact your dealer or Robern directly.
Limited Warranty - One Year Term
© 2024 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376 www.robern.com
RECESS MOUNTING INSTRUCTIONS
Important safety instructions - Save these instructions
1
AiO RESERVE CABINET
Scan the QR code
to see the entire
AiO Reserve series
Use the camera app on your mobile
device to look at this and other
QR codes. This will allow you to
quickly access web pages and other
relevant documents.
AiO Reserve Cabinet Recess Mounting Instructions
Part no. CB-209-1456 06/19/2024
