41357G/61357G SYNCHRONIZED DIGITAL CLOCK
Installation Instructions
SPECIFICATIONS
Time Update BCD or 58th/59th sync signal
Method
Power 105-240V AC, 50/60Hz
Operating Temp -4ºF(-20ºC) to 113ºF(45ºC)
Visibility Up to 250 feet
Mounting Wall
Lens Material Non-glare, shatterproof transparent
polycarbonate
Bezel Material Reinforced Acrylonitrile Butadiene Styrene (ABS)
Bezel Color Black
Time Format Modes 12-Hour (AM/PM) or 24-Hour (Military)
LED Color Red
Battery Backup Holds time/setup for up to 7 days
DIGIT HEIGHT/ WEIGHT
FORMAT
4"/4-Digit 00:00 2.10lbs
4"/6-Digit 2.65lbs
Warranty 1-Year manufacturer's limited warranty
Guarantee 30-Day money back guarantee
Includes Clock wire harness, security mounting bracket
& key, wall mounting template
ACCESSORIES
PART# DESCRIPTION
7000 Master Clock
4000 Auto Totaling Time Clock
5000 Auto Totaling Time Clock
PSDLAUBKK TimeTrax™ Elite Swipe Card Time Clock System
TTPROXEK TimeTrax™ Elite Proximity Time Clock System
TTELITEEK TimeTrax™ Elite Biometric Time Clock System
9T1WI RF Wireless Transmitter (desktop)
S9DWXSLAUB RF Wireless Transmitter (wall-mount unit)
42337 Ethernet RF Wireless Transmitter
(wall-mount unit) add-on transmitter
S9DSXOLAUB Ethernet RF Wireless Transmitter
(desktop) add-on transmitter
42689 Wash Down Enclosure for Digital Clock
42247J Digital Security Mount Replacement
42429E-1 Wall Clock Security Mount Replacement Key
41270 Y Splitter
41269 Cable 50' BCD
41314 Cable 100' BCD
CBPLATEKIT Count up/down digital time controller
43193-3 Chrome Wire Guard for a digital clock
I2048 Rev. K
Page 7 of 8
888.479.7264 • pyramidtimesystems.com
DIMENSIONS SHIPPING
(WxHxD) WEIGHT
11.5" x 6.5" x 1.5" 2.6lbs
15.25" x 6.125" x 1.5" 3.6lbs
41357G
11.5in
61357G
15.5in
4.0in
6.25in
5.0in
1.5in
4.0in
6.25in
5.0in
1.5in
