41357G/61357G SYNCHRONIZED DIGITAL CLOCK
Installation Instructions
MULTIPLE CLOCK CONNECTION
Use RJ45 Splitter Cable (part #41270) to add more clocks. Up to 200 clocks may be added to
1
the system, however clocks should be located within 300 feet of the 7000 unit to receive the
synchronization time data.
Connect RJ45 cable to 41357G/61357G Digital Clock and to 7000 Master Clock. Apply 105-240V AC
2
50/60Hz individually to each digital clock through black and white wires using clock wire harness
(must be installed by licensed electrician).
Mount and install wall clocks according to instructions included with clock.
3
Wire Harness
(included)
Black
Gray
Red
I2048 Rev. K
Page 3 of 8
888.479.7264 • pyramidtimesystems.com
Blue
White
Green
To change or set feature,
1
press SELECT until desired
feature is displayed.
Use or
2
feature.
DATA
1
SELECT
SET-UP INSTRUCTIONS
After displayed feature is
3
changed, press SELECT to
24 VDC
change other feature &
+ -
return to main display.
to change
POWER
