- Page 1 EN User Manual | Hob HKB64453NB aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................13 5. -
Page 3: General Safety
• Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated. - Page 4 • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • If the glass ceramic surface / glass surface is cracked, switch off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply.
-
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS • Before carrying out any operation make This appliance is suitable for the following sure that the appliance is disconnected markets: NL from the power supply. • Make sure that the parameters on the 2.1 Installation rating plate are compatible with the electrical ratings of the mains power supply. -
Page 6: Gas Connection
2.3 Gas connection • Make sure that the ventilation openings are not blocked. • Do not let the appliance stay unattended CAUTION! during operation. When using a gas cylinder, always keep • Set the cooking zone to “off” after each it on a flat horizontal surface (with the use. -
Page 7: Installation
have to move them on the cooking • Switch off the appliance and let it cool surface. down before cleaning. • To prevent spills, use only stable • Do not use water spray and steam to cookware with the correct shape and clean the appliance. -
Page 8: Injectors Replacement
3.2 Gas Connection Liquid gas Use the rubber pipe holder for liquid gas. Always engage the gasket. Then continue WARNING! with the gas connection. The following instructions about The flexible pipe is prepared for apply when: installation, connection and maintenance must be carried out by qualified •... -
Page 9: Adjustment Of Minimum Level
If the supply gas pressure is changeable or 4. Turn the shaft on the minimum position. different from the necessary pressure, you 5. With a thin screwdriver, adjust the bypass must fit an applicable pressure adjuster on screw position (A). the gas supply pipe. -
Page 10: Connection Cable
3.7 Assembly • This appliance is supplied with a mains cable and a plug. ON-TOP INSTALLATION • Always use a correctly installed shockproof socket. • Make sure that there is an access to the mains plug after the installation. • Do not pull the mains cable to disconnect the appliance. - Page 11 A. supplied seal B. supplied brackets INTEGRATED INSTALLATION ENGLISH...
-
Page 12: Possibilities For Insertion
3.8 Installing hob under the hood If you install the hob under a hood, please see the installation instructions of the hood for the minimum distance min. between the appliances. 30 mm 3.9 Possibilities for insertion min. 2 mm The panel installed below the hob must be easy to remove and let an easy access in case a technical assistance intervention is necessary. -
Page 13: Product Description
4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Semi-rapid burner Ultra Rapid burner Auxiliary burner Control panel Control knobs Window for Hob²Hood infrared signal 4.2 Control panel layout Use the sensor fields to operate the Minute Minder and Hob²Hood. The displays, indicators and sounds tell which functions operate. -
Page 14: Control Knob
Stand-by mode: Press the for at least 1 second to activate the display. 4.3 Control knob Symbol Description Symbol Description minimum gas supply no gas supply / off position 1 - 9 power levels ignition position / maximum gas supply 4.4 Residual heat LEDs full light LEDs light slowly reduced... -
Page 15: Daily Use
5. DAILY USE 2. Keep the control knob pushed for equal WARNING! or less than 10 seconds. This lets the thermocouple warm up. If not, the gas Refer to Safety chapters. supply is interrupted. 3. Adjust the flame after it is regular. 5.1 Burner overview If after some tries the burner does not light, check if the crown and its cap are in... -
Page 16: Turning The Burner Off
In the last minute the time decreases in The hob is supplied with StepPower. This seconds, and the last 10 seconds the function allows you to set the power more timer emits a sound signal. precisely from 9-1. 3. Touch WARNING! To stop the sound. -
Page 17: Hints And Tips
3. Touch to select desired automatic mode. For most of the hoods, the remote After the Automatic Mode is selected, wait till system is originally deactivated. Activate it disappears from the display so that this it before you use the function. For more setting is saved in Flash Memory and recalled information refer to the hood user at startup. -
Page 18: Suggested Recipes
Burner Diameter of Keep the window for Hob²Hood infrared cookware (mm) signal communicator clean. Ultra Rapid 200 - 260 Semi-rapid (rear left) 160 - 220 Other remotely controlled appliances Semi-rapid (rear right) 160 - 240 may block the signal. Do not use any Auxiliary 120 - 220 such appliances near to the hob while... - Page 19 Food categories Recipes Burner type Heat up phase Cooking phase power level power level 1) Mushrooms rice Large Couscous Large Pasta - Rice - other Cereals Spaghetti Large Ravioli Large Vegetable soup Medium Mushrooms and pota‐ Soup - Legumes Medium toes soup Fish soup Large...
-
Page 20: Care And Cleaning
The settings suggested in the cooking table should only serve as guidelines and be adjusted depending on the rawness of food, its weight and quantity as well as on the type of gas used and the material of the cookware used to prepare the dish. 7. -
Page 21: Troubleshooting
WARNING! Let the flame spreaders cool down before you clean them. Light stains: Wash the flame spreader with warm water and soap and dry it with a soft cloth. Medium stains: Use the dishwasher. Place the flame spreader on the bottom rack in a flat position, with the top side up. - Page 22 8.1 What to do if... Problem Possible cause Remedy There is no spark when you try to The hob is not connected to an elec‐ Check if the hob is correctly connec‐ activate the spark generator. trical supply or it is connected incor‐ ted to the electrical supply.
-
Page 23: Labels Supplied With The Accessories Bag
8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send this C. -
Page 24: Energy Efficiency
9.6 Gas burners for NATURAL GAS G20 20 mbar BURNER NORMAL POWER MINIMUM POWER kW INJECTOR MARK Ultra Rapid Semi-rapid 1,85 0,45 103x Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product Information according to EU Ecodesign regulation Model identification HKB64453NB ENGLISH... -
Page 25: Energy Saving
Help protect the environment and human health by recycling waste of electrical and Electrolux Appliances AB - Contact Address: electronic appliances. Do not dispose of Al. Powstancow Slaskich 26, 30-570 Krakow, appliances marked with the symbol... - Page 28 867367978-E-162024...
