Armored Door Cords
Installation Manual
SD-969-A18Q – Plastic End Caps
SD-969-A18Q – Silver
SD-969-A18/K – Black
16" (41cm) Stainless steel armored cord
Inside door-cord diameter:
Outside door-cord diameter:
SD-969-S18Q – Aluminum End Caps
SD-969-S18Q – Silver
SD-969-S18/K – Black
Die-cast aluminum end caps
17" (43cm) Stainless steel armored cord
Inside door-cord diameter:
Outside door-cord diameter:
SD-969-T15Q/S shown
/
" (8mm)
5
16
/
" (11mm)
7
16
/
" (8mm)
5
16
/
" (13mm)
1
2
Designed to carry wiring to conduct power to
electric locks or access systems mounted in
doors/gates
Conceal unsightly wiring and protect from
vandals
Mounting screws included
Surface-mount
Model
End caps
SD-969-A18Q
Plastic
SD-969-A18/K
Plastic
SD-969-S18Q
Aluminum
SD-969-S18/K
Aluminum
SD-969-T15Q/B
Aluminum
SD-969-T15Q/S
Aluminum
SD-969-M15Q/B Aluminum
SD-969-M15Q/S Aluminum
Pre-Wired
Color
Terminals
No
Silver
No
Black
No
Silver
No
Black
Yes
Bronze
Yes
Silver
No
Bronze
No
Silver
