OWNER'S MANUAL
DISHWASHER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
DB476***
MFL72141250
Rev.00_090324
Copyright © 2024 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DB476 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LG DB476 Series

Summary of Contents for LG DB476 Series

  • Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH DB476*** www.lg.com MFL72141250 Rev.00_090324 Copyright © 2024 LG Electronics. All Rights Reserved...

  • Page 2: Table Of Contents

    Before Using .....................27 Control Panel ....................31 Wash Cycles ......................32 Options and Extra Functions ................33 Programme Table ....................35 Information for Energy Test (EN60436) ............39 Loading the Dishwasher .................40 Adding Cleaning Agents..................45 Refilling......................46 Useful Tips......................47 SMART FUNCTIONS LG ThinQ Application ..................48 Smart Diagnosis ....................50...
  • Page 3 MAINTENANCE Cleaning and Caring ..................52 TROUBLESHOOTING Before Calling for Service................56...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.

  • Page 5: Installation

    • Do not modify the power cord provided with the appliance. Please contact the LG Customer information centre to advise of its incompatibility. • This appliance should only be transported by two or more people holding the appliance securely.
  • Page 6 • Connect the ground wire to the green ground connector in the terminal box. Operation • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
  • Page 7 • In case of flood, disconnect the power plug and contact the LG Electronics Customer Information Centre. • Under certain conditions, hydrogen gas may be produced in a hot- water system that has not been used for two weeks or more.
  • Page 8 SAFETY INSTRUCTIONS • Do not operate the appliance unless all enclosure panels are properly in place. • Use only detergents or wetting agents recommended for use in a appliance and keep them out of the reach of children. • Do not wash and dry articles that have been soaked in explosive substances such as gasoline, solvents, solvent-based detergent.

  • Page 9: Caution

    SAFETY INSTRUCTIONS Maintenance • Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the socket outlet. • Securely plug the power plug in the socket outlet after completely removing any moisture and dust.
  • Page 10 SAFETY INSTRUCTIONS Operation • Turn off the water tap and unplug the appliance if the appliance is to be left for an extended period of time, such as during vacations. • Do not place objects on the top of the appliance. •...

  • Page 11: Caring For The Environment

    • You can take your appliance either to the shop where you purchased the product, or contact your local government waste office for details of your nearest authorised WEEE collection point. For the most up to date information for your country, please see www.lg.com/global/recycling.

  • Page 12: Installation Parts And Specifications

    INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Interior View Top Wash Impeller Control Panel Upper Spray Arm Levelling Feet Lower Spray Arm Status Indicator Light Salt Dispenser Cap Power Cord Filtration System...

  • Page 13: Specifications

    1 600 - 1 800 W Information on LED Lighting If the LED lighting is not working Please contact the LG Electronics customer This product contains the light source of energy information centre. Do not attempt removal of the efficiency class G.

  • Page 14: Preparing Cabinet Opening

    INSTALLATION Preparing Cabinet Opening • Install the appliance on a flat and stable area. Do not place any objects in-between the floor and base or leg off the appliance. Choosing the Proper Location NOTE • This installation must be conducted by qualified service personnel to ensure it has been installed correctly.
  • Page 15 INSTALLATION • (Case A) Mounting the sliding panel (which NOTE means front panel slides up as the door is opened.) • You can adjust the width dimensions of the wood - Height: 720 - 780 mm panel to match the cabinet width. - Weight : 2.5 - 11 kg Attaching the Strip to the Appliance Side Cabinet...

  • Page 16: Levelling The Appliance

    INSTALLATION by steam or condensation when the door is • Condensation may occur on the underside or opened. along the front edge of the counter top when the room temperature is low. • Install the moisture barrier tape to the underside of counter top to protect the counter top from condensation when the appliance opened.

  • Page 17: Checking The Level

    INSTALLATION In order to assemble as mounting the fixed panel, • If the appliance rocks when pushing the top the sliding links must be disassembled. Remove plate of the appliance diagonally, adjust the feet the sliding links by loosening the 2 screws on each again.

  • Page 18: Securing Door Panel To Dishwasher

    INSTALLATION • Turn the centre screw clockwise to raise the rear Check the opening of door and repeat if of the tub and counterclockwise to lower it. necessary until the door opens and closes properly. Securing Door Panel to Dishwasher NOTE Adjusting Appliance Height •...

  • Page 19: Adjusting Door Spring Tension

    INSTALLATION Draw a line between the marks and trim off the Use the door adjustment screws (Φ 4 x 34 mm) top of the template at the line. provided to adjust the door spring tension at Cut out the squares marked on the midline of the bottom of the dishwasher.
  • Page 20 INSTALLATION Preparing Door Panel Use a 2 mm diameter drill bit to drill 10 mm deep pilot holes at the 12 points marked on the template. Mark a centre line lengthwise down the back of the door panel. Align the top and centre line on the installation (Case B) Mounting the fixed panel template with the top and centre line of the Use a 2 mm diameter drill bit to drill 10 mm...
  • Page 21 INSTALLATION Mounting Door Panel door panel using the provided bracket screws (Φ 4 x 14 mm). Mount the door panel on the dishwasher door by inserting the brackets on the panel into the bracket openings in the door. Leave a 180 mm gap to tighten the screws in step 2.

  • Page 22: Securing Dishwasher To Cabinet Opening

    INSTALLATION Remove the 2 screws from the control panel. Reinstall the plastic caps. Attach the door panel to the dishwasher door using the provided wood screws (Φ 4 x 40 mm). NOTE • External water leakage could result if the installation of the screws to the surrounding timber cabinet is not done correctly.

  • Page 23: Preparing Water And Electrical Connections

    INSTALLATION Method 2 CAUTION When the drain hose is connected to a separate • Make sure that plastic debris is not remaining standpipe , it is essential that an airtight inside of spigot after it has been drilled out. connection be made.

  • Page 24: Final Installation Check

    INSTALLATION CAUTION WARNING • Only use the threaded nut of the water supply • For personal safety, remove house fuse or open hose to tighten it to the tap. circuit breaker or switch off power plug before installation. • Do not twist or kink the water supply hose when connecting it to the tap.
  • Page 25 INSTALLATION Installation Check Error Codes Error Possible Cause and Solution Code Drain hose kinked or pinched. • Feed the drainage and supply hoses through the hole under the sink. Then gradually slide the dishwasher into the cabinet while pulling on the hoses under the sink to take up any slack.

  • Page 26: Operation Operation Overview

    OPERATION OPERATION Operation Overview Load the dishes in the rack. • Make certain that no dishes or utensils are in Using the Appliance the path of the spray arms. • Do not place one dish on top of another. Open the door and press the Power button. •...

  • Page 27: Before Using

    OPERATION Set the softening system level of the appliance NOTE according to the water hardness level. • Never use liquid dishwashing detergent in the appliance. Method 2 • It is not recommended to rinse the dishes You can check water hardness by using the test manually before operating the dishwasher strip included in the product.

  • Page 28: Water Hardness Table

    OPERATION Water Hardness Table Water Hardness Softeni Ratio mmol/l mg/l ng level °d °e °f Range (Ca+Mg) (Ca) <4 <5 <7 <0,7 <29 Soft 4 - 7 5 - 9 7 - 13 0,7 - 1,3 29 - 50 1:24 7 - 14 9 - 17,5 13 - 25...

  • Page 29: Adding Rinse Aid

    OPERATION as any spilled salt inside the appliance may cause Remove the lower rack and remove the cap of rust or damage to the appliance if the left the salt dispenser located on the left side of the unwashed. filters. Before using the appliance for the first time, it is necessary to pour 1 kg of dishwasher salt and 1 litre of water at the same time if...

  • Page 30: Setting The Rinse Aid Level

    OPERATION while filling, or air bubbles may result in poor Press Delay Start to change the rinse aid drying results. dispenser setting. Each press of the button changes the setting one step from L0(off) to L4. Once the desired rinse aid dispenser setting is selected, press START to save.

  • Page 31: Control Panel

    OPERATION Control Panel Control Panel Features For Steam Models Power • Press Power button to turn power on and off. • After the cycle is complete, the power automatically turns off for purposes of safety and economy. • If there is a power surge, power outage, or disruption of any kind, power is automatically turned off for safety.

  • Page 32: Wash Cycles

    OPERATION • To activate or deactivate the button sounds, press and hold Dual Zone and Energy Saver simultaneously for 3 seconds. The error alert sound cannot be turned off. Cancel • The drain pump activates and the cycle cancels. Once the appliance finishes draining, the power turns off.

  • Page 33: Options And Extra Functions

    OPERATION • This cycle does not have drying. Steam This option adds steam during the cycle to improve wash results. Express This cycle will quickly clean lightly soiled dishes. High Temp. Raises the main wash or heating rinse temperature • Press and hold Turbo for 3 seconds to activate. to improve cleaning.

  • Page 34: Status Indicator Light

    OPERATION Status Indicator Light FUNCTIONS sections for detailed information about this feature. The Status Indicator light at the bottom of the dishwasher shows the status of the appliance: whether it has encountered any problems,whether Auto Open Dry it is operating normally, or whether it is ready to wash dishes.

  • Page 35: Programme Table

    OPERATION Programme Table Programme Guide On DB476*** Models Wash Rinse Program Soil Level Pre-wash Main wash Rinse Heating rinse Auto All levels (65 - 70 ℃) (62 ℃) (70 ℃) Intensive Heavy (75 ℃) (62 ℃) (70 ℃) Delicate Light (55 ℃) (62 ℃) (70 ℃)
  • Page 36 OPERATION NOTE • Running time may vary according to the water temperature, ambient temperature, water pressure and voltage. • Information that the values given for programmes other than the eco programme are indicative only. • When the Auto Open Dry feature is activated, the heating rinse temperature may vary.
  • Page 37 OPERATION Regulation for Europe(On DB476*** Models) Water Energy Consumption Programme Duration (min) Consumption (kWh) Auto 12,9 0,91 - 0,97 Intensive 23,1 1,60 Delicate 16,5 1,07 Refresh 10,0 0,76 0,54 Turbo 18,5 0,84 Express 0,58 Rinse 0,01 Machine Clean 0,78 *1 Auto Open Dry feature is on. NOTE •...

  • Page 38: Available Options

    OPERATION Available Options NOTE • The Energy Saver option is not available with the High Temp. or Extra Dry option. • The Delay Start option can be selected for every washing programme in this table. For Steam Models Programm Energy Dual Zone Half Load Steam...

  • Page 39: Information For Energy Test (En60436)

    OPERATION Information for Energy Cutlery Rack Test (EN60436) Appliance loaded in accordance with standard specifications. NOTE • When the salt dispenser is operated, the data below increases. - Water Consumption: 4 L - Energy Consumption: 30 W - Duration: 4 minutes For Models with Auto Open Dry Function •...

  • Page 40: Upper Rack

    OPERATION Upper Rack Lower Rack Glasses(Milk) Dinner plates(Egg) *1 There are 5 glasses stained with milk. Melamine Dessert Plates(Egg) Dessert Bowls(Oat flake) *2 Milk Glass for EN60704-2-3: 2020 Soup plates(Oat flake) Saucers(Black tea) Oval Platter(Meat) Mugs(Black tea) Small Pot(Spinach + Margarine) Cups(Black tea) Oven Pot(Meat) Glass bowl(Meat)

  • Page 41: Items Not Suitable For Dishwashers

    OPERATION • Items with burnt on food should be soaked prior To make it easier to load larger dishes, the front to loading the dishwasher. row of tines can be folded down. • Deep based items should be placed upside down.

  • Page 42: Loading The Upper Rack

    OPERATION Loading the Upper Rack CAUTION Daily Use Load • The spray arms must not be blocked by items that are too tall or hang through the baskets. The upper rack is suitable for delicate items such Test for free movement by manually rotating the as, small plates, long cutlery, cups, glasses and spray arms.

  • Page 43: Height Adjustable Upper Rack

    OPERATION • The rack on the left pops free at the back. There are three available positions for adjusting The rack on the right pops free at the front. the height of the upper rack to create more space. Lowering the Rack Hold the rack at the centre of each side to support its weight.

  • Page 44: Loading The Cutlery Rack

    OPERATION Possible plate size according to the • When the upper rack is in the lower position, push in the upper rack first, and the lower rack upper rack position later. • Pull out the lower rack first, and the upper rack Plate Size (mm) later.

  • Page 45: Adding Cleaning Agents

    OPERATION Adding Cleaning Agents Height Adjustable Tray The tray on the left side can be adjusted to a high Adding Detergent to the or low position to accommodate utensils or cutlery Dispenser of different sizes. Remove dishes before adjusting the tray. Adjust the tray by sliding the lever. •...

  • Page 46: Refilling

    OPERATION • To avoid damaging the appliance, do not pull up If a prewash is desired, fill the recessed on the dispenser to close the appliance door. prewash compartment area on the lid with detergent. • Use of an unsuitable detergent and rinse aid Amount of detergent may result in a risk of damage, corrosion, poor Programme...

  • Page 47: Unloading The Dishwasher

    OPERATION Checking the Rinse Aid Unloading the Dishwasher When the Rinse Aid Refill icon illuminates lit, it • Before unload the dishes, check if the dishes means the rinse aid is almost empty. If necessary, cooled down to hand-warm condition. refill the rinse aid dispenser.

  • Page 48: Smart Functions

    When the cycle is complete or the appliance has problems, you have the option of receiving push Run the LG ThinQ application and sign in with notifications on a smartphone. The notifications your existing account or create an LG account are triggered even if the LG ThinQ application is to sign in.

  • Page 49: Wireless Lan Module Specifications

    Internet service provider or refer to your Run the LG ThinQ application. wireless router manual. • LG ThinQ is not responsible for any network connection problems or any faults, Select and touch the Dishwasher in the malfunctions, or errors caused by network application.

  • Page 50: Declaration Of Conformity

    LG ThinQ application. equipment type Dishwasher is in compliance with Directive 2014/53/EU. The full text of the EU • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow declaration of conformity is available at the...

  • Page 51: Customer Care And Service

    Customer Care and Service Contact an LG Electronics customer information centre. • To find an LG Electronics authorised service personnel, visit our website at www.lg.com and follow the instructions found there. • Self-repair is not recommended as it could further damage the device and void the guarantee.

  • Page 52: Maintenance

    MAINTENANCE MAINTENANCE To maintain performance and prevent problems, Food residue may be stuck in the narrow gaps check the outside and inside of the appliance, inside the appliance after completion of washing. including filters and spray arms regularly. Wipe off all food residue. WARNING •...

  • Page 53: Cleaning The Filters

    MAINTENANCE white vinegar into shallow bowl and place in upper Clean the filters with a soft brush under rack. Run Auto cycle. Do not use detergent. When running water. Reassemble the filters before the cycle is finished, restart. reinstalling them. CAUTION •...

  • Page 54: Cleaning The Upper Spray Arm

    MAINTENANCE Cleaning the Upper Spray Arm NOTE • When assembling, rotate it firmly until it clicks. Pull the upper rack forward. Make sure that the water jet holes are not blocked by food particles. When cleaning is necessary, remove the upper spray arm by turning the nut on the bottom of the spray arm 1/8 turn counterclockwise and pulling down.

  • Page 55: Seasonal Maintenance And Storage

    MAINTENANCE After cleaning the upper spray arm, press it up Refit the filter and gasket and make sure that it into place. Turn the nut 1/8 turn clockwise to is sitting correctly. make sure that the nut locks back into place. Refit and secure the water supply hose in reverse order.

  • Page 56: Troubleshooting

    The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If this appliance does not function properly or does not function at all, check the following before you call LG Electronics service centre. Symptoms Possible Cause &...
  • Page 57 TROUBLESHOOTING Symptoms Possible Cause & Solution Motor trouble • Call for service if the same problem occurs again. Vario motor trouble • Call for service if the same problem occurs again. Operation Symptoms Possible Cause & Solution Noise Some level of noise is normal during operation. •...
  • Page 58 TROUBLESHOOTING Symptoms Possible Cause & Solution Water remains in sump Water may remain if the power supply was lost before normal end of the after completion of course or was manually disconnected. cycle. • Re-start the course. Sprays arms do not Holes of spray arms are blocked by food particles.
  • Page 59 TROUBLESHOOTING Symptoms Possible Cause & Solution Yellow or brown film Coffee or tea stains on inside surfaces of • Eliminate the stain by using a stain removal product. appliance Yellow water remains When initially using the appliance, Yellow water may generate in the inside the dishwasher.
  • Page 60 TROUBLESHOOTING Symptoms Possible Cause & Solution Odour There is food in the bottom of the unit or in the filter. • Clean the filter and the interior according to the MAINTENANCE section of the owner’s manual. Unwashed dishes are left in the unit for a long time. •...
  • Page 61 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
  • Page 62 Memo...
  • Page 63 Memo...
