- Page 1 QUICK INSTALLATION GUIDE INDOOR/OUTDOOR LONG RANGE MAINS REPEATER WITH EXTERNAL ANTENNA [LAN-WMBUS-R4-M-LR-A2-X] Version: 01...
- Page 2 Appropriate disconnection device, such as a power supply cable with socket, shall be mount a repeater on a recommended to use Lansen pole used as part of the building instruction. It should be close to the device and easily mounting kit (article number LAN-910-0066).
- Page 3 Step 8 (Mounting on a pole/mast) Strip the power supply cables according to the diagram below. Install the Lansen pole mounting kit (article number LAN-910-0066) on the back of the repeater. Pull the straps through the holes and wrap it around the pole or pipe which the repeater is going to be mounted on and tighten the straps, so it is securely mounted.
- Page 4 Step 9 Step 11 Thread the power supply cable (prepared in Step 5) through the cable inlet, either Attach the cover and mount the screw (marked with a red circle on the image from the back of the repeater or on the side (marked by red circles). Connect the below).
