7 Operation
7.1 RGB status LED
RGB status LED display
domovea has an RGB status LED display
going operations in domovea
RGB status LED display
Off
Flashing green
Permanent green light
Permanent blue light
Permanent white light
Flashing yellow
Flashing yellow (double pulses for 15 s)
Flashing red
(Fig.
(see Tab. 2).
(Fig. 3/2)
Table 2: RGB status LED display
3/2) to signal errors that have occurred or to display on-
Cause
Module has no power supply
Device is booting
Device ready for operation, network OK
Offline mode, bus and cloud connection disconnected
Mode for PC direct connection, DHCP server activated
Ready for operation, with network problems
Device identification when using the Matter bridge (see Hand-
book/Installation manual – https://hgr.io/r/TJAS471)
Malfunction: Boot/software error
Operation
RGB status LED
