MitoQUAD
USER MANUAL
www.mitoredlight.com
© 2025 Mito Red Light, LLC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MitoQUAD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for mitoredlight MitoQUAD

  • Page 1 MitoQUAD USER MANUAL www.mitoredlight.com © 2025 Mito Red Light, LLC. All rights reserved.
  • Page 2: Table Of Contents

    CONTENTS Recommendation of use and precautions ......... 03 Contraindications ....................07 Indications of use ....................08 User guidance ......................09 Package contents ..................... 10 User Instructions ......................11 Important battery information ............... 16 Troubleshooting ......................18 Specifications ......................19 Disclaimer and warranty ..................22 About us ..........................
  • Page 3: Recommendation Of Use And Precautions

    RECOMMENDATION OF USE Please read the complete instruction manual before using the MitoQUAD. It will give you a better understanding of how the product works, and you’ll be able to enjoy the best session results. Warning Do not leave the device unattended when turned on to avoid the risk of fire or burns;...
  • Page 4 If face filling plastic surgery (hyaluronic acid and other infusions) has been accepted within one month, it is not recommended to use this product. If there is sunburn in the past 2 weeks, it is recommended not to use this product. www.mitoredlight.com...
  • Page 5 Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 12 inches to any part of the MitoQUAD device or system, including cables specified by the manufacturer. Degradation of the performance of this equipment could result.
  • Page 6 Do not maintenance while the device is in use. Do not impact the lamp, or subject the device to heavy shocks, to avoid risk of damage to the lamp. Contact your doctor if you have any medical questions regarding use of this device. www.mitoredlight.com...
  • Page 7: Contraindications

    If you have any adverse reaction from using this device, stop using it immediately. Note: If you experience any discomfort, such as skin discoloration, skin damage, skin irritation or any other concerns develop, stop using the device immediately and consult your physician. www.mitoredlight.com...
  • Page 8: Indications Of Use

    PRODUCT DESCRIPTION The MitoQUAD is a body-worn device that has two models: TLB400, TLB400- B, each of which has 405 LEDs. The MitoQUAD has an LED array of 630nm, 660nm, 810nm, 850nm; with three modes to select from - mode1: RED+NIR: 630nm, 660nm, 810nm, 850nm...
  • Page 9: User Guidance

    For this reason, we recommend you allow at least 6 hours between sessions of the same area. We recommend no more than 20 minutes in any one session. We recommend using the device 4 to 10 times per week. We recommend taking at least one day off per week. www.mitoredlight.com...
  • Page 10: Package Contents

    The customer service might ask you for more information. A - MitoQUAD Belt - easily wrap the belt around waist, leg, arms B - Remote control C - Adapter plug...
  • Page 11: User Instructions

    USER INSTRUCTIONS Connecting your MitoQUAD Belt with the AC Adapter 1. Connect the male end of the remote control cable to the DC power port attached to the light therapy belt (1). 2. Connect the wall power adapter to the female end of the remote control cable (2).
  • Page 12 USER INSTRUCTIONS Connecting your MitoQUAD Belt with the external battery: If you have purchased a separate power bank, which will allow you to use your belt on the go, follow these instructions. The battery can be charged using the USB cable (see page 16 for important safety information).
  • Page 13 "+" and "-". The session time and brightness are also used in the same way. There is a symbol pointing to the selected item. With each press, a toggle is made between the three parameters www.mitoredlight.com...
  • Page 14 For brightness: Press the “set” button until the black highlight is over the sun image Adjust the light intensity from L1 to L5. L1 represents lower powered light, while L5 represents the strongest light setting. Display window (+) button Set button Power button (-) button www.mitoredlight.com...
  • Page 15: Maintenance And Cleaning

    Wait for the device to air dry naturally. Visually check whether the device is still dirty. If yes, repeat the above cleaning steps and visual inspection. Note: Do not use cleaning sprays on the device, cleaning sprays could harm light panel and controller. www.mitoredlight.com...
  • Page 16: Important Battery Information

    Monitor Charging: Never leave the battery charging unattended. Check for any signs of swelling, overheating, or smoke. Do NOT overcharge the battery. Unplug the charger when fully charged to avoid overheating and battery damage. www.mitoredlight.com...
  • Page 17 Fire Extinguisher Ready: Keep a Class D fire extinguisher nearby in case of a battery fire. Do NOT use water, sand, or regular fire extinguishers. PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE. IF YOU HAVE ANY QUESTIONS, PLEASE REACH OUT TO INFO@MITOREDLIGHT.COM www.mitoredlight.com...
  • Page 18: Troubleshooting

    Perform normal operations set times and adjust the followed. according to the instructions. brightness. The device has been used The device suddenly shuts Restart the device after it cools for too long, causing it to down. down. overheat and shut down. www.mitoredlight.com...
  • Page 19: Specifications

    SPECIFICATIONS Basic Specification Product/Model name MitoQUAD Input: 100-240Vac, 50/60Hz, 0.7-0.35A; Power source Output rated: 12Vdc, 2.08A; Dimensions(L*W*H) 558.8mmx 127mm Energy Source LEDs Weight (only main About 0.54 kg unit) Wavelengths 630nm, 660nm, 810nm, 850nm Total Irradiance: 132.8w/m2 Session Time 15 minutes...
  • Page 20: Symbols And Meanings

    Atmospheric pressure limitation Type BF is applied to the lamp mat part Batch code Serial number Protects against fixed foreign objects with a diameter of more than 12.5 mm and is waterproof against drips with an inclination of 15° www.mitoredlight.com...
  • Page 21 Lamp classification group in IEC 62471:2006 Indicates that the electromagnetic interference from the device is under the limits approved by the FCC Symbol for CE Mark. Indicates that the device compliants with the RoHS Directive Symbol for certification TÜV Rheinland UL Recognition Service www.mitoredlight.com...
  • Page 22: Disclaimer And Warranty

    WARRANTY The MitoQUAD has a warranty of one (1) year, from delivery of device. The warranty is valid only to the original purchaser if item purchased directly from www.mitoredlight.com or authorized reseller and is non-transferable. The warranty period starts the date the original purchased unit is delivered.
  • Page 23: About Us

    If you have any further questions, please feel free to contact us at: info@mitoredlight.com You can also call our phone number Monday - Friday 9am - 5pm MST...
  • Page 24 User Manual and Instructional Videos This user manual and instructional videos can be found here: https://mitoredlight.com/pages/user-manual Updated March 2025 www.mitoredlight.com /mitoredlight @MitoRedLight /mitoredlightofficial @mitoredlightofficial...
