Page 2 F Series Heavy Commercial Vehicles Owner’s and driver’s Man ual...
Page 4 We would like to take this opportunity to express our gratitude to you for your purchase of the Isuzu products, and we believe that you will continue to choose them with your happiness and satisfaction.
Page 5: Optional Device
Optional device It applies only to the vehicles equipped with 6HH1 engine. Only for vehicles loaded with 6HK1TC (turbocharged) engines It is only used for FVR model It is only used for FVM model It is only used for FVZ model Euro For use in Type 91/542 EECA vehicles The copyright is reserved.
Page 6: Table Of Contents
Table of Contents Content ....................................Pages Important information ................................8 VIN number and engine number ..............................8 Overloading ....................................9 Operation of new vehicle ................................10 Uses and precautions of new vehicle ............................12 Services and Maintenance ................................12 Switches and instruments ....................
Page 7 - 3 - Driving ......................................67 Preparations before starting the engine ............................67 Engine start: ....................................67 Stopping of the engine ................................. 69 Operation of turbocharged engine ............................... 69 Before driving off ..................................70 Parking ......................................71 Driving precautions ......................
Page 8 - 4 - Parts for grease filling ................................138 Lubrication guide..................................140 Special equipment operation ..............................152 Use and maintenance of the towing vehicle ..........................152 Electronic Tuning AM Radio with Clock ..........................152 Cassette player with electronically tuned radio and clock ......................156 Loading method ......................
Page 9 - 5 -...
Page 11: Important Information
Important information It is important to be familiar with and master the performance of the Isuzu trucks, which are described in the following countries. Before driving QingLing vehicle, must fully understand and follow the following provisions. VIN number and engine number...
Page 12: Overloading
FVR type Vehicle nameplate The vehicle identification signage is mounted Overloading The vehicle nameplate is mounted on the on the left side of the dashboard. Any overloading not only shortens the lower part of the instrument panel on the side service life of the vehicle, but also causes a of the co-driver's seat. serious failure and even an accident.
Page 13: Operation Of New Vehicle
Specifications”. These instructions clearly describe the rated total weight of the vehicle and the loads on front and rear axles. FVM/FVZ model Operation of new vehicle 2. Must avoid engine idling operation at Whether the use of a new vehicle is good or high-speed, sudden start and braking and not, has a great influence on the service life other similar driving operations.
Page 14 1. It is required that the speed of your driving within 3,000 km of the shed should be controlled within the range shown in the table below. Maximum permitted speed in kilometers (km/h) in the initial 3000 km Model Transmission 1st gear 2nd gear 3rd gear...
Page 15: Uses And Precautions Of New Vehicle
6th gear variable GVR (6HKl-TC) speed 6th gear variable GVZ (6HKl-TC) 29」 speed " Uses and precautions of new vehicle 3. Run the engine at idle until the engine is warmed up. All parts and systems of the vehicle must be inspected. Please refer to the instructions in "Switches and Instrument", - 5 -...
Page 16: Services And Maintenance
he Vehicle" and "Driving" for inspection. Services and Maintenance For safe repair, maintenance and reliability of the vehicle. Check and adjust the relevant parts of the vehicle. This can be done according to the chapter “Services and Maintenance”. Warning: The engine control module is installed on the lower left side of the co-driver seat.
Page 17: Switches And Instruments
Switches and instruments switch ⑲Accelerator pedal ① Ventilation equipment ② Combination switch ③ light bulb check switch ④ Indicator lamp/alarm light ⑤ Steering wheel ⑥ inspection of instrument panel Windshield wiper and ⑦ scrubber switch Exhaust brake switch Danger warning lamp flash Heating control...
Page 18: Steering Wheel Control
○ ⑳Power socket FVZ Middle differential lock switch ○ Shift lever ○ Spring brake valve handle and the horn is pressed to whistle. Do not turn the steering wheel when the vehicle is stopped. When the steering wheel is locked, the vehicle cannot be moved;...
Page 19: Starter Switch
can also be adjusted up and down. Before Turn the lock handle (L) for steering Starter switch adjusting the steering wheel, the driver's seat wheel adjustment upwards to release the As shown, there are five positions on the should be placed in the most comfortable steering column.
Page 20: Light Control Switch
“ON”: keep the key in this position when the Combination switch should be returned to its original position. The combination vehicle is in use. switch is used to control headlights, turn “H” (warm - up): turn the key to this position signals, headlight dimmers, and marker range to warm up the engine.
Page 21 Passing light switch Headlight dimming switch OPT Fog lamp switch When the headlight control switch is in “OFF” Move the switch handle up and down to shift When the lamp control switch has been pulled or 1st gear position, if the combination switch the headlight from high beam to low beam or to the first or second position, turn the switch handle is continuously toggled, the high beam...
Page 22: Exhaust Brake Switch
Exhaust brake switch The exhaust brake system closes the exhaust pipe when the engine brake is applied, thereby improving the braking effect. When the switch handle is pulled, both the clutch and accelerator pedals are released and the indicator lamp is on, which indicate that the exhaust brake is operating.
Page 23 Intermittent wiper control switch The windshield wiper switch has 4 positions control the speed of the wiper. When the windshield wiper switch is in the second “INT” position, the switch can be ①Close ②Intermittent turned to adjust the intermittent swing ③Low speed ④High speed interval of the wiper.
Page 24: Instrument Cluster
Danger warning flash switch Press the switch button and the washing The tank should be filled with genuine Isuzu When the switch handle is lifted upwards, all liquid can evenly sprayed on the windshield washing liquid. the turn signals will flash regardless of the This switch is used to operate the power position of the turn signal switch.
Page 25 Power output control switch (if equipped) To use the power output unit (P. T. O.), pull out this switch. This switch is used to operate the power output shaft device. When the switch is pulled out, PTO shaft will be operated and PTO shaft indicator will be turned on.
Page 26 to “ON” position before operating. Pull the control lever to raise the tilt stand. lever locks automatically when it is fully raised. When the lever is pulled back, it should be pushed back while pressing the tip button. detailed instructions operation and use of tipping bucket, refer to Tipper control lever (if...
Page 27: Instruments And Indicators
Instruments and indicators Instrument cluster Voltmeter ① Temperature gauge ② Air pressure gauge ③ ④ OPT Tachometer ⑤ Speedometer ⑥ Fuel gauge ⑦ OPT Oil temperature gauge Bulb inspection control button ⑧ - 17 -...
Page 28: Indicator Lamps
Indicator lamps ① Turn signal indicator lamp ② Oil pressure indicator lamp ③ Exhaust brake indicator lamp ④ Generator indicator lamp ⑤ Air pressure indicator lamp ⑥ PTO indicator lamp (if equipped) ⑧ Parking brake indicator lamp ⑨ FVZ Middle differential lock indicator lamp - 18 -...
Page 29 ⑩ Headlight high beam indicator lamp ⑪ Stop, rear light bulb indicator lamp ⑫ Repair engine warning lamp Note: Refer to the following text when the indicator lamp is on. Km/h Km/h Km/h Speedometer Tachograph Short distance odometer and reset button The speedometer is used to indicate the speed The odometer records the cumulative travel...
Page 30: Fuel Gauge
display is in the middle part of the lower side of the speedometer. The white area at the far right side can display 0.1 km (or 0.1 miles). Push the reset button inward to reset the short distance odometer to zero. When the pointer enters the red range, the vehicle should be stopped and the engine shall be kept idling until the coolant...
Page 31 tank. “F” and “E” indicate “Full” and indicate the air pressure in the main air tank. dashboard and the warning buzzer also “Empty”. When driving, the pressure gauge reading sounds. should be 7-8 kg/cm Before the starter is turned off, the buzzer should not sound when the air pressure is OPT Double pointer barometer up to 5.3 kg/ cm...
Page 32 vehicle is driven continuously when the OPT Oil temperature gauge tachometer pointer is within the red zone, it The oil temperature gauge is used to indicate many cause serious engine damage. the oil temperature in the engine oil pan. If the Maximum allowable engine speed: pointer rises above the red line, it means that 6HH1: 3,000 turns/min...
Page 33 Air pressure warning lamp (Depressing the pedal brake repeatedly may turned on, it indicates that the pressure in the cause a temporary decrease in air air tank is insufficient, and the brake cannot be The indicator lamp will be turned on when the pressure.) applied fully.
Page 34: High Beam Indicator Lamp
SERVICE ENGINE SOON Turn signal indicator lamp Exhaust flashes together with the turn indicate that the exhaust brake is operating. signal light. High beam indicator lamp Oil pressure indicator lamp brake indicator lamp When using the headlight high beam, the This indicator turns on when the start switch indicator When the switch of turn signal light or When lamp is on.
Page 35 the engine. If the oil level is normal, the turned to the “ON” position, but the start engine turns off. location of the fault is limited to the If the light turns on during driving, it indicates that the engine's electronic control system lubrication system.
Page 36 Stop, rear light bulb indicator lamp When the bulb of the stop lamp or the tail lamp is blown, the indicator lamp will be turned on. When replacing the lamp, use a bulb with a specified number of volts and watts. FVZ Middle differential lock indicator lamp When the middle differential lock switch is...
Page 37 Seatbelt warning lamp (if equipped) Move the operation mechanism The warning lamp is used to remind the driver Transmission lever The shift position Bulb check switch and passengers to fasten their seatbelts. diagram is located on the top surface of the Before driving, use this switch to check that Whenever the start switch is turned to the shift lever knob.
Page 38 MRB model MLD model 6 - speed transmission 6 - speed transmission Spring brake valve handle When the spring brake valve handle is pulled up to the locked position, the spring brake will turn to the braking state and its indicator lamp will be on.
Page 39: Accelerator Pedal
The spring brake valve handle cannot be operated during driving. Tilting mechanism control handle (if temperature, hold down the button on the top of the handle and push the handle down. ※ For details on the operation of the dumping mechanism, refer to the operating instructions equipped) provided by its manufacturer.
Page 40: Other Instructions
en the vehicle is driven on a downhill, must apply the engine brake as possible. Clutch pedal Other instructions Window adjustment handle Ventilation device The clutch must be fully depressed for When raising or lowering the side window disengagement; otherwise the gears may be Turn the grille to adjust the air flow glass of the cab, swing the window adjusting damaged.
Page 41 Close be moved downward. As soon as you release the To stop the window at the desired position, gently OPT Driver side power window switch switch, the window stops moving. pull the front end of the automatic switch and Operation of driver side window switch If the front end of the automatic switch is pushed release it immediately.
Page 42 Close Close Release Locking If the front end of the automatic switch is pulled up completely. In this case, gently pull up the front end switch again and check if the opening and closing halfway, the window on the driver's side can be of the window is normal.
Page 43 As soon as you release the switch, the window switch again to release the locked state of the move downward. As soon as you release the switch, the window stops moving. stops moving. window. Close: OPT Power window lock switch OPT Passenger side automatic Pulling up the front end of the switch allows window switch...
Page 44: Cigarette Lighter
OPT Sun visor OPT Disc-shaped container on lower OPT Overhead shelf side of assistant seat When the sun shines on the face, the sun visor can be lowered. The storage tray is located below the seat. 3. A Curtains Cigarette lighter In use, press it down and heat it in about 15s.
Page 45 4. Sometimes the cigar lighter cannot rebound after it is deformed. Please use the new Isuzu cigarette lighter accessories for replacement. External power outlet Its maximum...
Page 46 Forced ventilation device Outlet Indoor lights Antenna selection toggle The indoor switch can be used in any Pull out the antenna for better reception. position of the start switch. ②“DOOR”: this light comes on as soon as the driver's door is opened. ③“ON”: this light is always on regardless of the position of the door.
Page 47 t select toggle is used to control the wind direction. ① FACE: Air blows to the face ② DEF: Air blows to windshield glass Indoor and outdoor air switching button The indoor and outdoor air conversion button is used to convert between the two ways of air circulation which are outdoor air or indoor air circulation.
Page 48 The air outlet select toggle is used to control the wind direction. ① FACE: Air blows to the face ② BI-LEVEL: Air blows to face and feet ③ FOOT: Air blows to the feet ④ FOOT/DEF: Air blows to the feet and windshield glass ⑤...
Page 49 Air intake switch Temperature adjustment button Fan knob The air intake switch controls the outside air Temperature toggle control temperature (by The fan toggle controls the four speeds of the and the device that directly circulates air controlling hot water flow rate) air flow rate. through the air intake duct. Turn off: Introduce the outside air Lights up: Circulate indoor air - 39 -...
Page 50 Heating in winter Fan defog Forced ventilation When the engine coolant temperature rises, Use temperature toggle and fan toggle to When the dial button is turned in the position adjust the toggle as shown on the left. Use control the flow of air temperature to defrost shown in the figure, the outside air can be the temperature toggle and fan toggle to and defog entered for circulation through the exhaust control the room temperature.
Page 51 Front cover release handle OPT Indoor air control (used in OPT Summer air conditioning (used The release handle of front cover is located on the vehicles with air-conditioner) in vehicles with air-conditioner) Press instrument panel at driver's side. the “A/C” (air conditioner) button, and place room temperature can be adjusted to the desired temperature.
Page 53: Cab Tilting
Pull the front cover release handle Close: Cab tilting and release the front cover lock. 1. Replace the strut rods into its storage clip. When servicing or checking parts in the 2. Lower Raise the front cover and insert the the front cover and press down the engine compartment, tilt the cab forward as lower two parts front cover support bar to maintain the front of the front cover as shown described below.
Page 54 Do not leave anything pourable in the cab. Close the doors on both sides securely. * Before lifting the cab upwards, make sure that the headlights are turned off. 3. Then, hold the safety torsion rod ③ by one 1. Prepare the cab before tipping. hand, and grab the cab handle ④...
Page 55 Good Poor 4. Support the cab tilted halfway to confirm 5. To lower the cab to the original position. that the cab tilt bracket is locked. Hold the cab tilt bracket locking lever, release the lock, pull 6. Push the tilt lever upward and press into the the bracket rearward, to drop the cab;...
Page 56: Fuel Tank Filler Cap
OPT Spare wheel hanger OPT Starter auxiliary switch Fuel tank filler cap To remove the spare wheel, insert the handle The starter auxiliary switch can start the into the hole on the frame side and turn it in a engine when the cab is tilted. Rotate the cover counterclockwise to remove counterclockwise direction.
Page 57 Front side Rear side: ① Headlight ② Turn signal lights and vehicle width lights ③ Fog lights ① Turn signal lights ② Taillights, brake lights and reflectors ④ Dome light/sign identification light ③ Reversing lights ④ License plate lights - 5 -...
Page 58: Before Driving Your Vehicle
Before driving your vehicle Proper management and driving can not only prolong the life of the vehicle, but also save fuel and grease. Be careful to drive safely. If any abnormality of the vehicle is found during the inspection, please contact the QingLing Auto Dealer. Simply insert a key into the driver door lock and turn it to unlock or lock all the door locks.
Page 59 Lock the door (outside) Inside door handle Lock the door (inside) The door can be locked from the outside Open the handle inside the Close the door and press the door lock button, to close the door. door and the without using the key. door opens. OPT Automatic door lock (inside) That is, set the door lock knob inside the...
Page 60: Driver's Seat
OPT Driver's seat (suspended seat) Driver's seat Passenger seat Handle A: Pull up on this handle to adjust the seat position forward Handle A: Pull up on this handle to adjust Handle A: Pull this handle and backward. Handle B: Pull this handle to adjust the tilting angle of to adjust the the seat position forward and backward.
Page 61 OPT Driver's seat (air suspension OPT Middle seat seat) Pull this handle to fold the backrest. Air-suspension seats can maintain the required air- cushion height by air pressure under different driver weights. Handle A: Pull this handle to lock the seat height in the middle position.
Page 62 the buckle. When the lock is locked in place, a “Click” sound will be sent. Locking tab Buckle Console storage box Press the button on the cover to open the OPT Seat Belt (Safety Belt) Make sure the seat belt is firmly tied to the glove box on the console.
Page 63 Button Buckle Hold the seat OPT Front seat shoulder-waist Press the button on the buckle to release the belt buckle tab (L) seat belt. duplex safety belt and pull the duplex seat belt so that it As an option in your vehicle, you may be crosses over your equipped with a compound safety belt which body.At this time, the...
Page 64 until it is buckled with a click sound. other than on the abdomen in case of a It is important to make the seatbelt in close contact with the body and lower it position, collision. If a seatbelt is not fastened, a serious accident may cause injuries and because the force generated from the seatbelt can be distributed on the stronger pelvis, even death.
Page 65: Interior Rearview Mirror
to allow the seatbelt to be drawn into the retraction · If the seat belt is found to have been cut, device. At the time, the buckle tab can be placed on weakened, cracked, or subjected to a collision the accessible door pillar. load, replace it.
Page 66: Driver Checklist (Daily Check)
Good Outside rearview mirror Adjust the rear view mirrors, so that the scenes on both sides of the rear Driver checklist (daily c heck) Outside road and the conditions on both sides of the rear To ensure safe and reliable driving, the 1. Check tire pressure and damage. trunk can be seen.
Page 67 2. Check whether the wheel nuts are loosened. 3. Check the oil level in wheel bearing. 4. Check whether the chassis springs are 8 hub bolts: …… The nuts on the right (If equipped) damaged. wheels should have positive thread The nuts on the left wheels should be reversely threaded - 15 -...
Page 69 5. Check the lights for normal operation. 6. Check all parts of engine oil, coolant, 7. Drain the water from the air tank. fuel, and power steering fluid for leakage. - 1 -...
Page 70 Height Good Inside the engine compartment 8. Check the electrolyte level in each battery 9. Check the water level in the water cell. separator. 1. Check the engine oil level. - 2 -...
Page 71 2. Check the tension of fan belt. 3. Check the level of engine coolant and 4. Check the power steering liquid level. cover the water tank. - 3 -...
Page 72 Inspection of inside of front cover Inside the cab 2. Check the liquid level of the clutch fluid Check the level of the cleaning fluid in the in the reservoir. 1. Check the steering wheel for free stroke windshield washer reservoir. and stability.
Page 73 Check the parking brake lever for stroke. 3. Check if the horn, windshield wiper and 4. Check the instruments and indicators. turn signal light can be used normally. - 5 -...
Page 74: After Starting The Engine
After starting the engine 5. Check the fuel level in the fuel tank. 6. Check the condition of the door lock mechanism. 1. Check whether the indicator lamp goes out and stays off when the engine is turning. - 6 -...
Page 75 2. Check free play and stepping condition of 3. Check the free play, stroke, and function 4. Check the inflation air tank. brake pedal. of clutch. - 7 -...
Page 76 5. Check the abnormal engine noise and abnormal exhaust color and odor. - 8 -...
Page 77: Driving
Driving Proper maintenance and driving not only extends the life of the vehicle, but also helps to improve the economics of oil and fuel. Preparations before starting the 2. Place the transmission in neutral. engine Please refer to the neutral position shown on page 25 of this book.
Page 78: Engine Start
Engine start: When the outside temperature is below 0°C, or when on high land with height of 1,500m 1. Turn the start switch key to the “H” position and hold it in this position until the control resistor becomes red hot. When the engine is hot: 1.
Page 79 Turn the start switch key to “ON” Turn the idle control knob in “H” direction to When the engine is preheated safely, turn position then depress accelerator switch. If the accelerator pedal is depressed with the start switch key in the “LOCK” or “ACC” position, the engine will be difficult to start.
Page 80: Stopping Of The Engine
make ensure the bearing cage and rotating parts of the turbocharger are fully lubricated Operation of turbocharged engine and that the engine in the cold status cannot be Stop the engine operated at high speed. General precautions After driving on the road, operate the engine Stopping of the engine at idling speed for at least 3min until the If the naturally aspirated engine is replaced...
Page 81: Before Driving Off
Press the middle differential lock Poor Good switch and confirm that the middle differential lock indicator turns on. Be careful about starting the vehicle When the middle differential locking device is Operation of intermediate Before driving off started successfully and the two shafts of the According formal inspection...
Page 82: Parking
Full release the parking brake Place Parking Driving precautions the gear shift lever in 1st gear and carefully 1. Switch the gear lever to the neutral position 1. Avoid the engine over speed. start the vehicle; do not quickly release the and apply the parking brake.
Page 83 2. When driving, if abnormal sound or odor is 3. During driving, if it is found that the 4. Avoid unnecessary acceleration and found, stop and check to find out the cause of indicator lamp or the instrument has a sudden braking. the problem.
Page 84 Stop 5. When driving, do not rest your feet on the 6. Stop the vehicle completely before 7. When a large traction is required on a clutch pedal; otherwise, it will create a partial moving from forward gear to reverse gear or uphill, the low-speed gear should be switched release, resulting in premature wear of clutch from reverse gear to forward gear.
Page 85 and good results can be achieved by using exhaust brake. * When the transmission is in the neutral position, it does not work even if the exhaust brake switch is turned on. Exhaust brake 8. When driving down a long slope, the engine brake, foot brake and exhaust brake should be used in combination a the low gear.
Page 86: Driving For Economy
9. When the vehicle is driven through a shallow 10. After the vehicle is driven through a river, must In heavy rain, pay special attention to safety. river or check the various parts of the engine, rear axle and puddle, must pay special attention to Because the transmission for grease and oil conditions.
Page 87: Precautions About Driving In Winter
Precautions about driving in winter Use of antifreeze 4. Inflated tires will reduce fuel economy. Prevent engine from overcooling The freezing temperature will change with Undercooling not only wears out the main the mixing ratio of antifreeze and water. parts of the engine, but also reduces fuel economy.
Page 88 Mixing ratio ( % ) The appropriate mixing ratio of high- quality glycol-based antifreeze Engine lubricating oil Before using antifreeze, clean the engine cooling system determined according to the graph shown on the thoroughly including the When the temperature is decreased, the oil radiator. viscosity will left.
Page 89: Driving On Snowy Or Frozen Roads
Electrolyte Battery Driving on snowy or frozen roads 2. On snow or frozen roads, avoid high When the ambient temperature is decreased, 1. When driving on snowy or frozen roads, speeds, sudden acceleration or sudden the battery capacity will be decreased. In please use the tire chains or snow tires. braking and sharp turns. addition, as the discharge decreases, the specific gravity of the electrolyte decreases.
Page 90: Precautions For Vehicle Use In Tropical Area
Precautions for vehicle use in 3. Use a low gear to achieve engine braking 4. Pay attention to maintain the proper tropical area effect. distance between the vehicles. At high temperature, the engine may be overheated. Please implement the operations with the methods as described below to avoid overheating of the engine.
Page 91: In Case Of An Emergency
Do not use hard water such as well water or river water in the cooling system of the generator. In order to prevent accelerating the accumulation of rust and scales. check the electrolyte level and, if necessary, fill the electrolyte. Insects, dirt, or other obstacles remaining in the air ducts of radiator, can In case of an emergency...
Page 92: Emergency Starting
icle should be kept on the right (or left) away from the traffic lane and should not be parked on the traffic lane. If the battery is fully discharged, replace it with another auxiliary battery with the same voltage as the original one of 24 volts.
Page 93 ④ Chassis ground wire equipped with discharged battery, and ground wire shall leave discharged battery as far as possible. After connecting the jumper cable, Never connect the cable between the QingLing Motor Company's special start the engine of the vehicle with the positive and negative terminals.
Page 94 1. Front-end towing The parking brake should be released with the The steering wheel of the faulty vehicle should method described in “Air Parking Brake” be fixed at a straight forward driving position. All wheels are in contact with the road or the below (see Section 3).
Page 95 OPT Wheels parking brake In case of emergency: If the pressure of the compressed air in the air tank drops, must enable the brake valve to release the wheels and disable the brake. In the above case, release the wheel parking brake as follows.
Page 96 push rod to an appropriate length. Install the claw connector and insert the locking pin. Note: If you inflate the power chamber before disassembling the push rod, the wheel cylinder will be damaged. Release and apply the parking brake in emergency case Rotate the rigging screw that connects the wheel cylinder and the push rod of the power chamber to...
Page 97 Single rear axle Double rear axle Front axle 5. Place the jack on the recommended If the tyre is deflated and the tyre needs to supporting point. be replaced, the jack cannot be put into the front axle by the defined fulcrum. Instead, the square timber must be placed under the front axle in advance according to the following method.
Page 98 In order to ensure the stability of the vehicle in the jack-up, square wood with the largest possible size should be used. Apply the parking brake to the end, and firmly fix the wheel on diagonal side of Insert square wood under the front the specified jack point.
Page 99: Tire Replacement
The vehicle shall not be lifted in any other When replacing a wheel, you must location than prescribed disassemble and install it with the tire jacking fulcrum. nozzle facing down. To lower: With the jack handle is under the status as shown the figure, slowly...
Page 100 8 bolt hub s ISO8 stud wheel disc Fasten wheel nuts in order using wheel 4. When installing the rear tires, adjust the 1. Apply the oil or equivalent in the wheel nut wrenches. As shown on the left. tire inflation valves on the inner and outer holes and between the nuts and washers.
Page 101 grease. Apply grease after tightening the wheel nut completely. Front wheel Rear wheel Fill grease 4. Do not paint the contact surfaces of hubs, wheel nuts, and dual tires.If it is necessary to paint on these surfaces because of special needs, spray them with a spray gun until you can't see the surface primaries.
Page 102: Long Term Storage
5. Start the engine and let it idle for more than 20 minutes. Long-term storage Caution During the initial test run after a long period of storage To start the parked engine for a long time, follow Avoid making the engine run at a fast (6 months or longer), parts and components of engine the steps below.
Page 103: Maintenance Schedule
Services and Maintenance In order to maintain safety and economical efficiency of driving, regular inspections and repairs should be carried out in accordance with the recommendations presented in this chapter. Maintenance schedule In order to ensure the safety and economy of driving, it is necessary to carry out regular inspections and repairs in accordance with the maintenance schedule.
Page 104 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate (No.1) Use odometer reading or period, whichever comes first. Service interval ×1,000 km Initial 1 Every driving Or monthly Engine Engine start and abnormal noise...
Page 105 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Main fuel filter (sleeve type) Oil pre filter element Fuel tank interior (No.2) Use odometer reading or period, whichever comes first. Every Service interval ×1,000 km...
Page 106 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Radiator coolant (*1: PT-type antifreeze) Radiator coolant (Replace once a year: R) (Replace every two years: R) (※2: High-quality glycol-based antifreeze) ※1PT: Permanent type ※2 Good quality ethylene glycol antifreeze...
Page 107 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Performance of clutch system Clutch pedal free stroke and pedal stroke Clutch air booster vent cap Transmission * Transmission gear Loosen of gear control mechanism Transmission shaft...
Page 108 I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Loose bearings and related parts Rear axle Differential gear oil (Isuzu type) FVZ Middle differential gear oil Grease for rear wheel bearing...
Page 109 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Service interval ×1,000 km Initial Every driving Or monthly Spring damage The leaf spring losses the elasticity Loosening and damage of the installation site Axis eccentricity of leaf spring Prevents leaks and damage of shock absorbers...
Page 110 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Service interval ×1,000 km Initial Every driving Or monthly Steering system Power steering oil Power steering oil filter Loosening of the mounting area Excessive free stroke of bearing * Damage, looseness and excessive gap of the steering...
Page 111 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate (No.7) Use odometer reading or period, whichever comes first. Every Service interval ×1,000 km Initial driving Or monthly Brake hose Bleeding, damage and loose fittings of brake pipes and hoses The cam and the wheel brake are worn excessively...
Page 112 Maintenance schedule I: Inspect, clean up and repair or replace as necessary A: Adjust R: Replace T: Tighten to specified torque L: Lubricate Function of control valve Spring chamber function (No.8) Use odometer reading or period, whichever comes first. Service interval ×1,000 km Initial Every...
Page 113: Lubrication Schedule
Lubrication schedule L: Lubricate Use odometer reading or period, whichever comes first. Service interval ×1,000 km Initial Every driving Or monthly Grease filling point Engine water pump bearing Front spring pin Front hook pin Kingpin hole of steering knuckle Steering drag rod (except maintenance-free) Steering clutch release bearing sleeve Rotating axis steering knuckle universal point and sliding sleeve...
Page 114 FVMFVZ Rear spring sliding pad Front wheel brake camshaft and clearance adjustment mechanism Lubrication schedule L: Lubricate Use odometer reading or period, whichever comes first. Service interval ×1,000 km Initial Every driving Or monthly Rear wheel brake camshaft and gap adjustment mechanism Steering wheel universal point and sliding sleeve Refer to pages 134, 135 of this book for the locations of the grease filling points.
Page 115: Maintenance Guide
Height Good Press down the middle of the belt with a force of 10 kg MAINTENANCE GUIDE and check that the deflection of the fan belt is Pull out the oil gauge again to check if the oil level approximately A: 13, B: 10 mm. At the same time, REGULAR INSPECTION is between the two oil level marks.
Page 116: Coolant Level
3. The level of coolant should be checked when the engine cools down. Coolant level Check the coolant level and refill the coolant in the Level of window washer Pull up the switch lever and check that the washing reserve radiator tank as required. When the water level Check that the tank is full of washing liquid.
Page 117 Battery electrolyte level Exhaustion of air box Clutch level Check the electrolyte level in each cell and fill with liquid When the air box exhausts air, let the water out of Check that the fluid is at the specified fluid level. If (distilled water) as required to the specified liquid level.
Page 118 Steering wheel Clutch pedal free play and stroke When the engine is running, turn the steering wheel in the left- Standard value Not only check the free rotation range of the steering right direction until the tire starts moving. Check the amount ①...
Page 119 Free play of brake pedal Tire inflation pressure, damage and tread wear Standard value: 9-14 mm Standard tire inflation pressure Front and rear wheels and Factory Applicable spare tire specifications pressure models (Kpa) 10.00-20- 16PR 630 ±20 FVR, CVR 10.00-20-16PR 700 ±20 FVM, FVZ 10.
Page 120 ance with national standards. Tire replacement 10.00-20-16PR and 11.00-20-18PR maximum tire The tires may subject to uneven wear depending on inflation pressure: 810KPa their mounting positions. 10.00R-20-16PR and 11.00-R20-16PR maximum tire Rear-wheel is worn severely, because both the running inflation pressure: 840KPa and parking brakes have to act alternately on the rear wheels.
Page 121 l. Internal inspection and maintenance When the air filter is cleaned, the red indicator lamp is on. This indicator is located at the rear of the air cleaner housing. Regular maintenance Smoke exhaust status Air filter After the engine is warmed up, check the color of The use of dirty air filters will not only reduce exhaustion.
Page 122 When the exposed filter cartridge is replaced or the inner filter cartridge is damaged, the inner filter cartridge must be replaced. When replacing, it is better to use genuine Isuzu filter, otherwise it will reduce the filtration efficiency, and may damage the engine.
Page 123 5. Clean 1) paper type filter element The filter element should be cleaned by one of the following methods according contamination. When cleaning dust, prevent collision, otherwise it will deform the filter element and even destroy it. Poor Height Good - 55 -...
Page 124 Water Separator (Fuel sedimenter)/Fuel following manner. Filter (Combined) in Fuel System If necessary, it should be replaced with original Isuzu brand fuel filter kit. When the red buoy starts to reach the drain level, the water separator should be drained as described below.
Page 125: Fuel Pump
Loosen the transparent cover and remove the filter element together with the cover. Remove the old filter cartridge, insert a new one and tighten securely the lid. ①Cover ② Filter element After the maintenance, must exhaust the fuel system and check it for oil leakage.
Page 126 Use a wrench to loosen the fuel filter Fuel tank Deflation of oil supply exhauster and allow the fuel pump to pump fuel so that Remove the drain plug and drain the water and sediment If the fuel tank is empty, the air can enter the fuel the fuel flows out of the vent plug until bubbles in the completely.
Page 127: Valve Clearance Adjustment
4. The filter shall be blown dry with compressed air the tank will cause failure of the power steering unit. and the light oil above shall be blown away. 5. Install the filter and secure the cover. Filter mesh Filter Filter Power steering oil filter Valve clearance adjustment...
Page 128 Use the gauge to adjust the valve clearance as follows: 3. First adjust the valve gap shown by the arrow in 4. Rotate the crankshaft one revolution (360 degrees) Air valve gap (when engine is cold) the figure. and continue to adjust the valve clearance indicated Exhaust: 0.4mm by the arrow in the figure.
Page 129 1. Check all air line fittings and gaskets regularly 2. Replace all gaskets and O-rings regularly. for leaks and repair loose or leaky fittings immediately. If the air to be compressed contains dust, wear and damage to the components of the turbocharger and the engine will occur.
Page 130 If the brake system is used, if there is a large gap between the brake adjustment All pneumatic brakes (ISUZU type) are linings and thus the brake cannot be applied safely, check Remove the rubber plug from the adjustment holes and adjust the clearance of brake linings.
Page 131: Clutch Pedal Adjustment
Rear axle rear shaft 28-33 Clutch pedal adjustment brake The free play of the clutch pedal ensures that the clutch When the brake level stroke is within the standard has a sufficient friction. value range, the brake friction lining gap will be If the actual push rod stroke of the brake is close to or adjusted to about 0.3 mm.
Page 132 Follow- up Follow-up cylinder Air booster Free play checking: Adjust the free play: 3. Tighten the nut and install the return spring. Then 1. Remove the return spring on Depress the clutch pedal carefully until a strong the hydraulic set the free play of the clutch pedal to the given value follower cylinder. range listed in the table resistance is felt, and check the free stroke before a below.
Page 133 Follow-up cylinder Air booster Follow - up Follow the instructions below to deflate Clutch hydraulic system deflation If air enters into the clutch piping, it will cause drag of 1. Apply the parking brake or spring brake the clutch. Therefore, if the clutch is used with insufficient fluid in the clutch tank, or if the hydraulic system is disassembled during clutch repair, venting must be performed.
Page 134 2. Check the clutch fluid level in the clutch groove and refill Remove the rubber cap from the bleeder Loosen the bleeder screw on the clutch booster, as necessary. screw, clean the bleeder screw, connect the vinyl tube place the clutch fluid with air bubbles into the container, Brake fluid dissolves paint and plastic, vinyl, rubber, etc, to the bleeder screw, and place the other end of the and immediately tighten the bleeder screw.
Page 135 Drain hole cover of air booster In-valve drain hole rubber cover Relay valve: The drain hole cover of air booster should be disassembled and cleaned periodically. The drain hole rubber cover shall be cleaned. Double-linkage control valve: - 67 -...
Page 136 Battery electrolyte specific gravity If the external parts of the battery are dirty, it can be Properly align the headlights to ensure adequate lighting cleaned with slightly warm water. The battery terminals on the road without causing glare to other drivers, At 20°C, if the reading of specific gravity of electrolyte should be coated thinly with petroleum jelly or grease which is the most important work.
Page 137: Replacing Light Bulbs
Replacing light bulbs When replacing the light, make sure that the light switch is set to the “OFF” (switch off) position. The bulb should be replaced with a new one with same capacity. Standard ratings of lamp wattage are listed below. Bulb Light name Power (W)
Page 138 Recognition light Front fog lights - 70 -...
Page 139 Current Circuits Current Circuits reading reading 7.5A Headlight high beam/Left Taillights, fog lamps, 7.5A Headlight high illumination devices beam/right Parking light 7.5A Headlight high beam/Left Starter (relay) 7.5A Headlight high beam/right (Power output) power outlet 7.5A Clock and dome light spared Turn signal 7.5A...
Page 140 If the slow break fusible link has blown, it should be replaced. 2. Remove the air conditioner filter. If need, Isuzu Pure brand slow-blown fuse should be used. Even if it is a temporary 3. Blow off the dust with compressed air, or rinse with water (after measure, it is not allowed to install wires such as copper wires.
Page 141 4. Reinstall the filter. - 73 -...
Page 142 Recommended liquids, lubricants, and diesel fuels In order to achieve the highest performance and longest working life of your QingLing Vehicles, the best lubricants and diesel fuels must be properly selected and used. When adding the lubricants, be sure to select the original QingLing lubricant or the lubricants recommended in the table below based on the maintenance schedule for each model.
Page 143 TRANSMISSION TM (80W - 90, 85W - 140) GL-5 GL- Grease-lubricated bearings TOTAL EPX 90 (90) 5 GL-5 CASTROL CASTROL DYNADRIVE (80W - 90) ISUZU GENUINE ESSCO AFT II, AFT II EXXON/ESSO ESSCO ATF D (DEXRON II-D) MOBIL MOBIL ATF (DEXRON III)
Page 144 BESCO LLC SUPER TYPE E ISUZU GENUINE HAVOIJNE EXTENDED LIFE ANITIFREEZE COOLANT Engine cooling system TEXACO/CALTEX HAVOLINE XLC EXTENDED LIFE COOLANT6280 Liquid portion Model Electric hydraulic tank tilting pump MIL.- H - 5606E aviation oil equivalent Clutch and brake fluid tank...
Page 145: Lubricating Oil
Lubricating oil According to the lubricating oil chart, care should be taken to select the lubricating oil. It is important to select the viscosity of the lubricating oil based on the ambient temperature. See the chart below. Engine oil viscosity map - 77 -...
Page 146 Engine oil vis cosity grade - ambient temperature ( Single grade ) Do not use any synthetic oil * When the ambient temperature is below 25 degrees Celsius ( - 13 degrees Fahrenheit), it is best to use starting aids (oil sump heater, block heater, etc.) to prevent starting failure or other ( Multi grade ) engine failure.
Page 147 Gear oil viscosity map ( Single grade ) Viscosity Level of Gear Oil - Ambient Temperature ( Multi grade ) - 79 -...
Page 148 Lubrication table (FVR models) ○ ○ ○ ○ ○ ○ 〇Check or add E …Engine oil B …Brake fluid E Replace G …Gear oil A …Automatic transmission fluid M …Multipurpose grease …Multipurpose grease or hub bearing grease - 80 -...
Page 149 Clutch fluid tank Wheel hub Wheel hub bearing oil or bearing oil or grease grease Power steering oil tank Engine Manual Manual Transmission Wheel hub Wheel hub bearings bearings Differential gear and wheel hub bearing oil 1000 km of initial driving ,000 km per year Every 2 months driving 8,000 km Every 3 months driving 8,000 km...
Page 150 Lubrication table (FVM/FVZ models) ○ ○ ○ ○ ○ ○ ○ 〇Check or add E …Engine oil B …Brake fluid E Replace G …Gear oil A …Automatic transmission fluid M …Multipurpose grease C Cab tilting pump oil …Multipurpose grease or hub bearing grease - 82 -...
Page 151 Clutch fluid tank Wheel hub bearing oil or grease Wheel hub bearing oil or grease Power steering oil 6 HK1TC engine tank ISUZU transmission Differential and wheel bearing grease Wheel hub bearings Wheel hub bearings ( hub with grease) hub with grease)
Page 152 Parts for grease filling (FVR models) Monthly or every 4,000 km ① Steering wheel universal point and sliding sleeve ② Straight pole (excluding maintenance-free type) ③ Front spring pin ④ Steering wheel kingpin ⑤ Rotating shaft ⑥ Front eye pin ⑦ Automobile transmission shaft universal point ⑧...
Page 153 Parts for grease filling (FVM/FVZ models) Every 4000 kilometers or once a month ① Steering wheel joints and sliding sleeves ② Straight pole (excluding maintenance-free type) ③ Front spring pin ④Steering knuckle king pin ⑤Clutch shifting device ⑥ Eye pin for front spring pin ⑦...
Page 154 Lubrication guide Drain the oil in the engine crankcase, main oil filter, Engine oil replacement Unscrew the drain plug in the lower part of the oil pan and branch oil filter completely, and then tighten the drain plug. to drain the engine crankcase oil. The warmed oil may cause skin burns.
Page 155: Transmission Oil Replacement
( MLD type 6th gear ) ( MRB model 6 gear ) Transmission oil replacement Replacement power steering gear Disassemble the drain plug (D) under the transmission case and drain oil in the transmission case. Discharge of oil: From the oil level inspection plug hole, add the specified gear oil into the transmission to the oil level inspection 1.
Page 156 1. Tighten the connecting bolt engine and operate it at idling speed several minutes, 2. After the tank is filled to air from entering the hydraulic system the specified level mark, recheck the liquid level and add the standard please wait 2-3 min until the level is maintained.
Page 157: Parts For Grease Filling
When the ventilation is performed, must check the fluid the front wheels on the ground, check the steering 6. Carry out a test run to check whether the steering level and add it if necessary. system to see if there was any oil leakage. wheel is operated smoothly and whether there is any 5.
Page 158 Kingpin hole of steering knuckle (4 points) Steering drag rod (2 points) Steering clutch release bearing sleeve(1 points) (Except for maintenance-free type) Lubricant Type Multi-purpose Lubricant NLGI No. 2 - 90 -...
Page 159 sliding sleeve Drive shaft knuckle universal joints and Central bearing of automobile transmission shaft ( 1 Rear spring pin (2 points) Lubricant Type Multi-purpose Lubricant NLGI point ) Lubricant Type Multi-purpose Lubricant NLGI No. 2 No. 2 Inject a sufficient volume of grease into the drive shaft knuckle until it overflows from the needle bearing seal (4 positions).
Page 160 Front wheel brake camshaft and clearance Rear wheel brake camshaft and clearance Universal disk universal point and sliding adjustment mechanism ( 4 points ) adjustment mechanism ( 4 points ) sleeve (3 points) Use and maintenance of semi-trailer tractor (dedicated portion) Operation Guide: Connect Before the towing vehicle is connecting or disconnecting with the semi-trailer, the entire train needs to stop on a flat surface with strong adhesion.
Page 161 1. Before the towing vehicle and trailer are coupled, confirm that the joint surfaces on the towing vehicle and the trailer are clean and well lubricated. 2. Check if the operating handle ⑦ of the traction seat is pulled out to the preset position (extending about 350mm). Otherwise, the following operations should be performed: Lift the spring clip in front of the handle upwards, push the handle forward to the unlocked state, and pull the handle outward to the maximum position, and lock it on the traction seat panel by the clamping groove on the handle, at this time, the locking hook is in the open state.
Page 162 After using for more than 5000km, the trailer should be removed for every week for inspection. Clean the joint surface between the tractor and the trailer, and use pressure-resistant grease to lubricate the tractor's joint panel, lock mechanism, center “throat” of the tractor seat, and trailer tractor pins. The high-pressure grease containing MoS or graphite additive is recommend, such as: BPL2M, BPHTEP1, BPLS2, Esso M-class, Shell, Retinax AM.
Page 163 Structure diagram of JOST saddle traction seat (JSK36DV only) Special statement: If the traction seat fails, please contact the traction seat manufacturer or the special repair station of QingLing Brake for repairs. Do not disassemble without authorization! Please use the genuine parts from the tractor manufacturer. The company will not be responsibility for any quality accident caused by non-original parts. - 95 -...
Page 164: Special Equipment Operation
Special equipment operation Electronic Tuning AM Radio with Clock ① ON/OFF button switch ② Tone control knob ③ Reset button ④ station selection/tuning button (∧∨) ⑤ Preselected station buttons ⑥ Display buttons ⑦ Electronic digital clock - 96 -...
Page 165 ① ON/OFF button switch ② Tone control knob ③ Reset button Press this switch to turn on the radio. Turn the knob clockwise to increase the treble, and Press this reset button to reset the displayed value of Press it again to turn off the radio.
Page 166: Scan Button
press the above button a very short time (within Scan button ④ Selection station/harmonic button (∧∨) 0.5s) to enter the manual tuning mode. Each time When the “SCN” button is pressed, the sweep from To use these buttons, first press “DISP” button and select the the button is pressed, the frequency displayed the current frequency value to the higher frequency frequency display mode on the display.
Page 167 ⑥Display buttons ⑦ Electronic digital clock Each time the “DISP” (display) button is pressed, If the clock needs to be adjusted, first press and hold the “DISP” button for more than 1.5 seconds. At the time, the time value will flash. displaying clock is switched to the displaying ·...
Page 168: Cassette Player With Electronically Tuned Radio And Clock
Cassette player with electronically tuned radio and clock (if equipped) ① ON/OFF button switch ② Left and right balance control ③ Audio control buttons ④ Preselected station buttons ⑤ Selection button of AM/FM band ⑥ Scanning button ⑦ Electronic digital clock ⑧...
Page 169: Volume Control Knob
① ON/OFF button switch Left and right balance control ② Tone control knob Press this switch to turn on the radio. Pull out the left and right balance control knob and Turn the knob clockwise to increase the treble, and Press it again to turn off the radio.
Page 170 button is pressed, the frequency display increases or decreases by 1 kHz (amplitude modulation) or 0.1 MHz ③ Station selection/tuning button (∧∨) (frequency modulation). Press the “∧” button, and the frequency increases. Press ④ Preselected station buttons ⑤ Selection button of AM/FM band the “∨”...
Page 171 Hold down the frequency modulation/amplitude Press and hold the alarm button for more than 1.5 ⑥ Scanning button seconds to select the alarm mode. During the alarm modulation (AM/FM) button and press the “∧” When the “SCN” button is pressed, the sweep from the mode setting, the display will always show the alarm button at the same time to increase the value of current frequency value to the higher frequency starts...
Page 172 ⑨ Fast forward/reverse button (FF/REW) ⑩ box out button When the FF/REW button is pressed, the button is When the take-out button is pressed, the cassette is locked and the tape advances quickly or rewinds. More ejected. specifically, if you press the button on the same side of the tape drive direction displayed on the display screen, the fast forward will be performed.
Page 173 Cargo loading method ②Heavy truck ③Dump trucks QingLing trucks classified by usage ① General truck ( as steel and cereals.) Applicable to transportation of bulk materials such (Applicable to transport soil, sand, etc.) (Applicable to general groceries, foods, etc. that are transported in boxes.) - 105 -...
Page 174: Loading Limit
Within Poor Good ④ Box truck 2. Loading limit (Applicable to transport sensitive materials such as rain, ① The cargo width should not exceed the outside dust, etc.) of the compartment Poor Good Within 0.5 m ( not more than 1/20 of full length) Common - 106 -...
Page 175 3. Loading instance ②Do not let the goods stick out of the truck bed as much Rough operation will shorten the life of the carriage as possible. ① Gently open and close the car. - 107 -...
Page 176 Protective plate used when Good Poor Good transporting steel Thud ②Carefully loading and unloading Throwing cargo will hurt the cargo and the carriage. ③ The cargo should be tied tight with ropes - 108 -...
Page 177 Poor Poor Good If it is not fixed, the materials will be scattered during ④ The cargo should be loaded low and evenly Unbalanced loading can not only make driving the journey unstable, but also damage the cargo and the vehicle. - 109 -...
Page 178 Good Poor Poor The relatively tall cargo should be fixed in the center of the compartment. - 110 -...
Page 179 Good Good Metal plate or pallet Poor Creaking ⑤ Long goods should be placed on a shelf Only the front frame and the rear door are used to ⑥ The concentrated weight should be distributed Caution: support the trunk. with weight distribution measures •...
Page 180 The first time During a crash The second time After 1 month The third time After 6 months After the fourth Every 6 months time For safety and automotive life - 112 -...
Page 181: Loading Method
3.569 2.389 1.533 8.896 MLD6Q 6.720 4.244 2.580 1.540 0.763 6.823 ISUZU MRB6P 7.027 4.277 2.493 1.500 0.780 7.038 MLD6 gear type: 6.5 including power-retrieving device: +0.7 Lubricant capacity L MRB6P gear type:7.8 The values in the table are estimates and are for reference only.
Page 182 Cargo loading method Type of Truck Loading method Method for protecting box Center line of cargo table Center line of cargo table When loading sand, gravel, brick and other goods, use side fence Debris, sand, gravel, bulk cargo protection materials and hang Rope ropes.
Page 183 Center line of cargo table Center line of cargo table Protection material of Rope Uniform loading on the side fence full length of the cargo Left/Right platform On the left and right of the lateral necessary center line of the cargo table Center line of cargo table Rope...
Page 184 Model FVR33P FVR34P FVM34Q FVZ34Q CXA34T Gross vehicle mass 15000±100 15000±100 20000±100 21500±100 24500±100 Loading mass 8000 8000 11500 12000 15000 Kurb mass 7000±100 7000±100 8500±100 9500±100 9500±100 Number of passengers Person allowed in the cab Engine Model 6HH1 6HK1 6H K1-TC 6HK1-TC 4-stroke single, water-...
Page 185: Main Data And Specifications
Main data and specifications Model FVR33P FVR34P FVM34Q FVZ34Q CXA34T General dimensions Outline dimensions Full length 9650±50 9650±50 9535±50 9535±50 10300±50 Full width 2465±30 2465±30 2465±30 2465±30 2465±30 Full height 2810±30 2810±30 2810±30 2810±30 2810±30 Wheelbase 5550±50 5550±50 5950±50 5950±50 6400±50 Wheel base Front wheel...
Page 186 Model FVR33P FVR34P FVM34Q FVZ34Q CXA34T Transmission Model MLD-6A MLD-6Q M RB-6P MRB-6P Clutch Type One-piece, dry type, with buffer spring Diameter 350 380 Pedal free play 45-65 Rear axle Type Integral axle housing, full floating drive axle Gear ratio 5.571 6.142 6.142 6.429 6.429...
Page 187 Power steering oil capacity Model FVR33P FVR34P FVM34Q FVZ34Q CXA34T Front wheel positioning angle Toe-in Camber -1-1 0±1 。 30’±30’ 30’±10’ Caster ±50’ ±50’ 。 King pin angle 30’±1 30’±1 。 Service brake Type All pneumatic, dual circuit Pedal free play 9-14 Parking brake Type...
Page 188 (Optional: 10.00-20-16PR) (Optional: 11.00-20-18PR) Rear 10.00-20-16PR 11.00R20-16PR (Optional: (Optional: 10.00-20-16PR) 11.00-20-18PR) Model FVR33P FVR34P FVM34Q FVZ34Q CXA34T Electrical device Type 24V system with negative grounding Battery V/Ah 12V-115A, h (2) Starter V/kw 24/4.5 Generator 24/40 - 120 -...
Page 189 Model FVR33PX FVR34PX FVR34SX FVM34QX FVZ34QX FVZ34VX General dimensions Outline dimensions Full length 9600±50 9600±50 11120±50 9600±50 9600±50 11685±50 Full width 2485±30 2485±30 2495±30 2485±30 2485±30 2495±30 Full height 3670±30 3670±30 3970±30 3670±30 3670±30 3950±30 Wheelbase 5550±50 5550±50 6300±50 5950±50 5950±50 7000±50 Wheel base...
Page 190 Gross vehicle mass 15000±100 15000±100 15500±100 20000±100 21500±100 21580±100 Loading mass 7300 7300 7270 11000 12000 11200 Kurb mass 7700:1:100 7700±100 8230±100 9000±100 9500±100 10380±100 Number of passengers allowed Person in the cab Engine Model 6HKl 6HKl 6HKl-TC 6HHl 4-stroke single, 4-stroke single, 4-stroke single, 4-stroke, water-...
Page 191 Model FVR33PX FVR34PX FVR34SX FVM34QX FVZ34QX FVZ34VX Transmission Model MLD-6A MLD-6Q MLD-6Q MR B-6P MRB-6P Clutch Type One-piece, dry type, with buffer spring Diameter 350 380 Pedal free play 45-65 Rear axle Type Integral axle housing, full floating drive axle Gear ratio 5.17 6.142 6.142 6.142...
Page 192 Steering wheel free play 10-60 Power steering oil 3.4 capacity Model FVR33PX FVR34PX FVR34SX FVM34QX FVZ34QX FVZ34VX Front wheel positioning angle Toe-in -1-1 0±1 -1-1 0±1 Camber 。 30’±30’ 0 30’±10’ 30’±30’ 30’±10’ Caster 。 ±50’ King pin angle 30’±1 。...
Page 193 Rear 10.00-20-16PR (Optional: 10.00-20-16PR) Electrical device Model FVR33PX FVR34PX FVR34SX FVM34QX FVZ34QX FVZ34VX Type 24V system with negative groun ding Battery V/A.h 12V-115A, h (2) Starter V/kw 24/4.5 Generator 24/40 - 125 -...
Page 194 Main data and specifications Dimension inside the vehicle (reference) Full length Full width Full height Minimum ground clearance mm - 126 -...
Page 195 Main data and specifications Minimum turning radius Drive type Number of axes Weight Gross vehicle mass Loading weight Equipment mass - 127 -...
Page 196 Main data and specifications - 128 -...
Page 197 Main data and specifications - 129 -...
Page 198 Main data and specifications - 130 -...
Page 199 Main data and specifications - 131 -...
Page 200 Main data and specifications - 132 -...
Page 201 - 133 -...
Page 202 Tools with vehicle Name Specifications Quantity Tool bag Spanner Extension bar - Wheel Wrench Grease gun Hydraulic jack assembly QYH10D Jaws 150 Monkey wrench 250 Wrench kit 10×12 Wrench kit 14×17 Wrench kit 19×22 Wrench kit 24×27 "-" Combination screwdriver "+"...
Page 203: Additional Descriptions
Wheel wrench - spare wheel Additional descriptions Use and maintenance of dual fuel tanks: The vehicle is equipped with the dual fuel tanks to ensure its proper and safe use and maintenance. Caution: Before daily operation, check to make sure that the surface of the connecting pipe between the two fuel tanks is not damaged or leaking.

This manual is also suitable for:

Fvr Fvm Fvz Fvr33g Fvr34j Frvr34s ... Show all

Isuzu F Series Owner's And Driver's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Isuzu F Series

Summary of Contents for Isuzu F Series

This manual is also suitable for:
