Outdoor living today GS124-SLIDER-CEDAR-AK Assembly Manual

12x4 gardensaver with sliding doors
Hide thumbs

Advertisement

Quick Links

Download this manual
Version #2.1
Jan 30, 2025
Stock Code:
GS124-SLIDER-CEDAR-AK/FJ
GS124-SLIDER-METAL-AK/FJ
GS124-SLIDER-PLY-AK/FJ
Thank you for purchasing a
12x4 Garden Saver. Please
take the time to identify all
the parts prior to assembly.
Important Information:
- It is the sole responsibility of the customer to check with your local municipal or county by-laws before
ordering this product to confirm it complies with building codes in your area.
- If the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
- Snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep
snow off roof frequently.
- In areas with high or gusty wind conditions, it is advisable to install the structure securely to the ground.
- Have a regular maintenance plan to ensure screws, doors, windows and parts are tightly affixed.
- All structures purchased from Outdoor Living Today are covered for a period of one year for defects in
manufacturing and workmanship. Costs incurred for customer installations are not included.
- Failure to use supplied parts included in this kit could result in poor product performance and may void
your warranty. Please contact Outdoor Living Today's Customer Toll Free Line if you plan to deviate from our
written instructions.
Customer agrees to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper
installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line
@ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier
replacement parts, free of charge, within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
1-888-658-1658
12x4 GardenSaver
with Sliding Doors
Assembly Manual
www.outdoorlivingtoday.com
Page 1
