Version #1.1
Jan 30, 2025
Stock Code:
SS124-SLIDER-CEDAR-AK/FJ
SS124-SLIDER-METAL-AK/FJ
SS124-SLIDER-PLY-AK/FJ
Thank you for purchasing a
12x4 Space Saver. Please
take the time to identify all
the parts prior to assembly.
Important Information:
- It is the sole responsibility of the customer to check with your local municipal or county by-laws before
ordering this product to confirm it complies with building codes in your area.
- If the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
- Snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep
snow off roof frequently.
- In areas with high or gusty wind conditions, it is advisable to install the structure securely to the ground.
- Have a regular maintenance plan to ensure screws, doors, windows and parts are tightly affixed.
- All structures purchased from Outdoor Living Today are covered for a period of one year for defects in
manufacturing and workmanship. Costs incurred for customer installations are not included.
- Failure to use supplied parts included in this kit could result in poor product performance and may void
your warranty. Please contact Outdoor Living Today's Customer Toll Free Line if you plan to deviate from our
written instructions.
Customer agrees to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper
installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line
@ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier
replacement parts, free of charge, within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
12x4 SPACE SAVER
WITH SLIDING DOORS
ASSEMBLY MANUAL
www.outdoorlivingtoday.com
Page 1
sales@outdoorlivingtoday.com
Advertisement
Table of Contents
Related Manuals for Outdoor living today SS124-SLIDER-CEDAR-AK/FJ
Summary of Contents for Outdoor living today SS124-SLIDER-CEDAR-AK/FJ
- Page 1 - Have a regular maintenance plan to ensure screws, doors, windows and parts are tightly affixed. - All structures purchased from Outdoor Living Today are covered for a period of one year for defects in manufacturing and workmanship. Costs incurred for customer installations are not included.
- Page 2 You can find the footprint for your shed on Page 3 of your Assembly Manual. If doing the assembly yourself, have all the necessary tools ready to go and in working condition. A list of required tools can be found after the parts list. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 2...
- Page 3 - 21 patio pavers (8” x 8” or larger). - Center patio paver stones underneath floor runners and underneath seams in floor joists. Patio paver stones are widely available from most landscape stores. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 3...
- Page 4 2 - ¾” x ¾” x 51” - Facia Nailing Strips Note: Trim and Skirting pieces are graded with the best face being rough sawn. Rough sawn cedar is much easier to paint and stain. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
-
Page 5: Hardware Kit
Metal Roof Screw Metal Roof Hanger x 5 1/4” Nut Driver Silicone Caulking Hardware Kit - PLYWOOD ROOF (Provided) 2 1/2” 1” x 24 Silver 90° Metal x 68 1 1/4” Brackets 3/4” x 12 Silver Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 5... -
Page 6: Tools Required
Please proceed to correct roof section depending on your selected roof type after rafter installation. The Parts List shows differences in some part sizes between our different types of siding. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 6... - Page 7 - Consult your local paint store for the best paint or stain for cedar. - Do not paint / stain the cedar shingles, this will void the warranty. - Optional: stain the inside of your shed. (Note: this will remove the fresh cedar smell.) Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
-
Page 8: Floor Section
Lay out both complete floor joist frames as illustrated. The footprint for 2 1/2” Screws the floor when attached together will be 141 1/2” wide x 45 1/2” deep. Attach x 6 total frames together with 6 - 2 1/2” Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 8... - Page 9 Keep plywood seams tight. Parts Position Plywood Floor on top of completed floor frames. Plywood Plywood Floor will sit slightly inset from outside of floor frame. (5/8” x 45 3/8” x 70 5/8”) x 2 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 9...
- Page 10 Wall Panels - 5pcs. Angled Wall Extenders - 2pcs. Door Headers - 3pcs. Interior Door Header - 1pc. Front Wall Panels - 2pcs. Front Wall Bottom Plates - 2pcs. Bottom Wall Plates - 5pcs. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 10...
- Page 11 The side wall panels will sit even with the floor frame and the rear wall panels will be sandwiched between the side wall panels. The floor plywood may be slightly recessed. Note: Siding will overhang the floor frame by approximately 3/4”. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 12 With the corner wall attachment complete, position a second rear wall panel in place so bottom 2x3 wall framing is sitting flush with outside floor joists. Wall siding should overhang floor by approximately 3/4”. When positioned correctly, attach both side wall panel studs together as per Step B4. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 13 Place Front Walls so wall framing is flush with floor frame and siding Hardware overhangs. Attach with 3 - 2 1/2” Screws per panel as per Steps B3 - 2 1/2” Screws x 12 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 13...
- Page 14 The Long Door Header has an aluminum strip attached to the back for added support. Attach by screwing down into wall framing with 2 - 3” Screws per side. Fasten aluminum strip to short headers with 2 - 1 1/4” Screws per side. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 15 B11. Hardware (Steps B11 - B12) With Angled Wall Extender and Side Wall aligned correctly, 2 1/2” Screws x 8 total secure together from the inside with 4 - 2 1/2” Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 15...
- Page 16 (2H - 45 1/2” wide) x 3 x 12 total the rear wall. Pilot Hole first. B14. With 2x3 wall framing aligned, attach extender walls to rear wall top plate with 4 - 2 1/2” Screws per wall. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 16...
- Page 17 Prior to securing, make sure wall panels are aligned correctly Hardware on the floor. Wall siding should overhang floor while 2x3 wall plates should sit 2 1/2” Screws x 32 total flush with floor. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 17...
- Page 18 2 1/2” Screws Interior Door Header. Fasten Door Jambs to Front (1 1/2” x 3 1/2” x 71 1/2”) x 2 x 6 total Walls with 3 - 2 1/2” Screws per piece. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 18...
- Page 19 Exploded view of all parts necessary to complete the Rafter and Roof Section. Identify all parts prior to starting. Rear Soffits - L/R Rear Soffit - Center Rafters - 9pcs - 2pcs - 1pc Front Soffits - L/R - 2pcs Front Soffit - Center - 1pcs Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 19...
- Page 20 Attach double rafters as illustrated above with (1/2” x 3 1/2” x 48”) x 2 3 - 2 1/2” Screws per rafter/rafter connection. Rear Soffit - Center (1/2” x 3 1/2” x 45 1/2”) x 1 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 20...
- Page 21 Position completed Rafter Section on top of walls. Outside Rafters will sit on Extension Wall framing and be positioned equally from side to side. When Rafter Section is positioned correctly, both Front and Rear Soffits will sit approximately 1/8” away from wall siding. This can vary slightly. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 21...
- Page 22 1 - 3” Screw per rafter end. Screw into rafters from inside of Header on an angle at x 14 total front of shed, and from inside of Extender Wall Framing at rear of shed. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 23 Attach with 4 - 1 1/4” Screws evenly spaced. The Facia Nailing Hardware Strip provides for a greater nailing surface later when you attach side facia. 1 1/4” Screws x 8 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 23...
- Page 24 (45 1/2” x 56”) x 1 Roof Panel centered on rafter. Align plywood of center roof panel so it is tight against the plywood of the side roof panel. Spacing should be even front and back. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 24...
- Page 25 Push or bang filler carefully with a hammer until evenly spaced and (16” - 18” Long) x 8 butt is even with other 1st row of shingles. Do first filler shingle on both seams. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 26 Slide 3rd and 4th Filler Shingles up and underneath appropriate shin- 2 1/2” Screws gle rows and follow Steps D7 - D9 to align and attach. On last filler, screws will x 8 total get covered by Roof Ridge Board (4 1/2” wide). Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 26...
- Page 27 (1/2” x 4 1/2” x 49 1/4”) x 3 x 15 total Boards should meet on seam of roof panels. When aligned correctly, attach with 5 - 1 1/2” Finishing Nails per piece. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 27...
- Page 28 (3/4” x 1 1/2” x 21 5/8) x 4 Hardware (Steps D1 - D4) 1 1/4” Screws x 27 total Position and attach Center Roof Batten (45 1/2” long) and Outside 50” long batten as per Step D1. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 28...
- Page 29 Position and attach 3rd row of Battens and Batten Spacers following Steps D1 - D3. Space battens such that they are flush with the previous row of Batten Spacers as shown above. Top View of Roof Battens Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 30 Panels down until Steps D10 & D12. Place other two Metal Roof Panels with Hangers the same way. Parts Hardware Metal Roof Panels Metal Roof Hangers (39” x 58 1/2”) x 5 x 5 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 30...
- Page 31 Adjust the position of remaining Metal Roof Panels on Battens as per Step D7. Overlap Metal Roof Panels to achieve the desired overall width. Overall width past the end of Battens can vary from 1” - 3”, depending on your personal preference. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 32 Battens. Five more 1 1/2” Metal Screws and five 1 1/2” Metal Screws will be required to further secure Metal Roof Panels and to complete Metal Ridge Caps in later steps. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 33 Step D10. Do not overtighten! x 5 total Note: If Top Siding Pc. for Angle Wall installed in Step B9 it can be done now. Attach with 3 - 1 1/2” Finishing Nails per piece. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 33...
- Page 34 Start with an Outside Large Plywood Roof Panel. Position so plywood overhangs outside Rafter by 2”. In the front, plywood will be recessed 1/8” back from rafter end. With panel positioned correctly, attach to Rafters with 9 - 1 1/4” Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 35 Steps D2 - D3. Place Small Center Roof Panel (45 1/2” wide) on rafters as per Step D3 and attach. Position 2nd Large Outside Roof Panel on roof and attach as per Step D2. Position 2nd Small Outside Roof Panel on roof and attach as per Step D3. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 35...
- Page 36 1 1/4” Screws x 6 total Note: If Top Siding Pc. for Angle Wall installed in Step B9 it can be done now. Attach with 3 - 1 1/2” Finishing Nails per piece. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 36...
- Page 37 Side Front Interior Door Flange Corner Trim Door Stops Lower Door Track Front Corner Trim Front Bottom Skirting Note: All Trim, Facia, and Bottom Skirting pieces will be positioned rough face out when installed. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 37...
- Page 38 Attach Front Bottom Skirting with 4 - 1 Front Bottom Skirting 1 1/2” Finishing Nails 1/2” Finishing Nails per piece as per Steps (1/2” x 4” x 45 1/4”) x 3 x 12 total E1 - E2. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 38...
- Page 39 Trim with 5 - 1 1/2” Finishing Nails per piece (7/8” x 2 1/2” x 42”) x 4 x 20 total as per Step E5. Note: Part size will vary depending on type of siding chosen for shed. See Parts List. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 39...
- Page 40 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 40...
- Page 41 Roller Assemblies to adjust the height until they hang parallel. Left Side Door Right Side Door Wider door trim towards center. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 41...
- Page 42 (1 1/2” x 2 1/4” x 3 1/2”) x 3 Door Tracks to shed with 6 - 3” Screws per piece. Secure Door Stops with 2 - 3” Screws per piece. Hardware 3” Screws x 18 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 42...
- Page 43 (3/4” x 3 1/2” x 44 1/4”) x 3 x 12 total closure so doors can not slide out of the track. Secure each piece of Track Cover with 4 - 2 1/2” Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 43...
- Page 44 (when viewed from the front of the shed). Ensure flange is flush (3/4” x 3 1/2” x 71”) x 1 with the inside of the door frame and attach with 5 - 1 1/4” Screws. Hardware 1 1/4” Screws x 5 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 44...
- Page 45 Rear Corner Trims. Align and (1/2” x 5 1/2” x 88 3/4”) x 2 x 32 total attach as per Step E12. Side Rear Corner Trims (1/2” x 2 1/2” x 88 3/4”) x 2 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 45...
- Page 46 2 - 1 1/2” Finishing Nails per rafter end. Attach Side Facia to (1/2” x 5 1/2” x 45 1/2”) x 2 the Facia Nailing Strip with 5 - 1 1/2” Finishing Nails. Hardware (Steps E15 - E18) 1 1/2” Finishing Nails x 46 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 46...
- Page 47 Center and Left/Right Facia, these will be covered by Facia Detail Plates in Step E19. Rear Facia will cap the side Facia. Attach Rear Facia to rafter ends with 2 - 1 1/2” Finishing Nails per rafter end. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 48 This requires a large amount of caulking but is 1 1/4” Screws important to fill. Later, Window Trims will be installed to hide caulking. Complete x 16 total second Window Insert the same. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 48...
- Page 49 3/4” Black Screws. Hardware Door Handles x 2 total Pre-drill 1/4” deep with 1/8” drill Black Hasp x 1 total bit for all door 3/4” Screws x 16 total hardware. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 49...
- Page 50 Please call, write or email us at: Canadian Address United States Address 9393 287th Street P.O. Box 96 Maple Ridge, British Columbia Sumas, Washington Canada V2W 1L1 USA 98295 Toll Line: 1.888.658.1658 Fax: 1.604.462.5333 sales@outdoorlivingtoday.com Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 50...
