RIBBON MICROPHONE
SZ-R2
USER MANUAL
Thank you for purchasing the Subzero SZ-R2. To get the most out of your
product, please read this manual carefully.
BOX CONTENTS
• 1x R2 Ribbon Microphone
• 1x Manual
FEATURES
• Figure-8 polar pattern
• Robust build quality
• Versatile frequency range
SPECIFICATIONS
Polar Pattern ................................................ Figure 8
Frequency Response .................................... 30Hz-15kHz
Sensitivity .................................................... -54dB±2dB
Impedance .................................................. <=600Ω
Recommended Load Impedance ................ >3000Ω
Maximum SPL ............................................. 148dB
Signal to Noise Ratio ................................... 70dB
Phantom Power Requirement ..................... +48V
USING THE MICROPHONE
1. Placing your hand over or bringing the microphone too close to the
speaker may result in feedback. To prevent this, start by reducing the volume,
then position the microphone away from the speaker and ensure there's
ample distance between them.
2. The microphone capsule is delicate and highly sensitive, so handle it
with care to prevent any potential damage from dropping, impacting, or
subjecting it to strong shocks.
3. Preserve the sensitivity and sound quality of the microphone by avoiding
exposure to moisture and extreme temperatures, as these factors can
compromise its performance.
FREQUENCY RESPONCE GRAPHS
-40
-50
dB
-60
-70
-80
50
100
200
0
30
330
300
270
240
210
150
180
Unidirectional at 1KHz
500
1000
2000
Hz
60
90
120
5000
10,000
20,000
KETTLESTRING LANE | YORK | YO30 4XF | UNITED KINGDOM
LAHNSTRAßE 27 | 45478 MÜLHEIM AN DER RUHR | DEUTSCHLAND
If you have any more questions about this product, please do not hesitate to
contact the Gear4music Customer Service Team on:
+44 (0) 330 365 4444 or info@gear4music.com
WWW.GEAR4MUSIC.COM
