TECHNICAL DATA
Frequency Response Graph
SPECIFICATIONS
Element ........................... High quality condenser
capsule
Polar Pattern ....................Cardioid
Frequency
Response ........................30Hz - 18 KHz
Sensitivity ........................ Sensitivity: -32±2dB
(0dB=1V/Pa at 1kHz)
S/N Ratio .........................83dB
Max SPL ........................... 130dB
(at 1kHz≤1% T.H.D
Distortion ........................≤0.5% (at 1kHz)
Load Impedance ............≥1000Ω
Equivalent
Noise Level .....................11 dBA
Sampling Rate ................16Bit/48KHz
KETTLESTRING LANE | YORK | YO30 4XF | UNITED KINGDOM
METALLVÄGEN 45A | 195 72 ROSERSBERG | STOCKHOLM | SVERIGE
LAHNSTRAßE 27 | 45478 MÜLHEIM AN DER RUHR | DEUTSCHLAND
If you have any more questions about this product, please do not hesitate to contact the
Gear4music Customer Service Team on: +44 (0) 330 365 4444 or info@gear4music.com
COMPACT
USB MICROPHONE
SZC-200-USB
USER MANUAL
