- Page 1 USERS GUIDE D17 PC2...
-
Page 3: Table Of Contents
Content 1. About user guide................. 2 Appearance Size and materials ..........2 Summary ..............3 3. Function 4. Normal Display area..............5 5. Cautions..................5 6. Installation..................5 Standard Operation ..............6 7.1 Power on/off................. 6 7.2 Speed/Distance/Time Display........... 6 7.3 Headlight turn on/off............7 6km/h Walk system ............ -
Page 4: About User Guide
2. Appearance Size and materials D17 PC2, the shell materials can work temperature scope: -20 ℃ —+60 ℃ , the shell material can ensure normal use and good mechanical performance of the products. - Page 5 D17 PC2 the button and display are integrated. In the follow-up instructions, button replace with words ”switch”. “ + ” button replace with word “plug”, button replace with word “minus”. headlight button replace with words “headlight”, button replace with words “walk”...
-
Page 6: Function Summary
3. Function Summary D17 PC2 function overview ： Setting Bluetooth Walk system Headlight Riding Mode PAS level Single trip time Single trip distance Remaining distance Max speed Average speed Battery Indicator Speed - 4 -... -
Page 7: Normal Display Area
4. Normal Display area D17 PC2 display interface 5. Cautions Please handle it carefully. No connecting and disconnecting the display to the controller when it in working condition. Please return it to the factory immediately when failure. 6. Installation Please install the display into the handlebar and connect it to the controller. -
Page 8: Standard Operation
7. Standard Operation 7.1 Power on/off Press the “ ” button (more than 2S), the controller will supply power to the display and start working. In the power on state, press " " button (more than 2S), the controller stops powering on the display. In the turn-off state, the display no longer uses the battery's power supply, and the meter's leakage current is less than 1uA. -
Page 9: Headlight Turn On/Off
max speed, single trip distance 7.3 Turn on/off the headlight Auto mode: The display automatically controls the headlights on/off by sensing external light. Manual mode: long press (more than 2.5s) "+" button to turn on headlight function, and long press "+" button again to turn off headlight function. -
Page 10: 6Km/H Walk System
7.4 6km/h Walk system Long press (more than 2.5S) the " " button, the walk indicator flashes, and then press the "-" button all the time to enter the walk mode. Release the "-" button to disable the push and exit the push walk mode. -
Page 11: Battery Indicator
Percentage of battery capacity: Battery Segment no.: Battery/Percentage(Bafang/Ananda) 15% —— 29% 30% —— 44% 45% —— 59% 60% —— 84% >=85%... -
Page 12: Automatic Adjustment Of Display Light Brightness
Max battery display Low battery display Under voltage (Flashing) 7.7 Automatic adjustment of display light brightness When the ambient brightness of the display changes, the display will automatically adjust the backlight brightness through the built-in light sensor. When the external environment is dimmed, the backlight brightness will be dimmed automatically. - Page 13 Error code interface Error Code Definition Controller phase line overcurrent fault Controller bus overcurrent fault Controller HALL fault Brake fault; throttle fault Controller temperature fault Motor temperature fault Overload fault Controller communication fault Controller overvoltage, undervoltage Other fault Display communication fault 31-50 Controller New EN fault MCU fault, reference voltage fault,...
- Page 14 calculated periodic fault TE chip communication fault 3.3V power fault Button fault Button fault Torque voltage fault Brake fault, speed sensor fault, detector HALL fault Temperature sensor fault Reference sample overtime Current feedback circuit fault Drive voltage fault Abnormal current fault Motor phase fault, motor power on stop overtime fault Torque voltage detects circuit fault...
-
Page 15: Usb Charing
7.9 USB Charging Plug in device that need USB charging when display power off. After that, turn on the display and charge the device. The charging sign "USb" on the display interface flashes 4 times, after 4 times stop flashing to avoid interfering with normal data display. -
Page 16: Display Parameter Setting
8. Parameter Setting Press "+" and "-" (more than 2.5S) together to enter the parameter setting interface. After entering the parameter setting interface, short press "+"(less than 1S) to switch the parameter item. Press "-" key again (more than 2.5S) to enter the parameter setting item, and then press "-"... -
Page 17: Single Trip Distance Clearance Setting
Long press "-" (more than 2.5S) to enter the setting page. The middle number is the backlight level. At this time, the minimum backlight level is 1 and the maximum backlight level is 5 (level from 0-5). Backlight always on. Short press "+"... -
Page 18: Version Viewing Setting
8.3 Version viewing setting “NU” stands for version number Long press "-" (more than 2.5S) to enter the setting, the display's software/hardware version number automatically switched. Short press "+" (less than 1S) to switch between the display version number and the controller version number. -
Page 19: Usb Communication Setting
8.4 USB communication setting "USb" stands for USB communication setting. Long press "-" (more than 2.5S) to enter the setting. The default value is "N" flashing, which means that the USB communication closed. “Y” flashing means communication is on. Short press "+"(less than 1S) to switch the USB communication status. -
Page 20: Wire Layout
9. Wire Layout Connect with Controller Wire connection definition Wire color function Red （ VCC ） Power for display Blue(K) Key for controller Black(GND) Green(CANH) CAN H Yellow(CANL) CAN L White(+/- ） PAS level 10. Display Printing Code If customer have requirements, display printing code will obey the requirements. -
Page 21: Faq
three lines. The first line is the product code and the production date of the display, the second line is the production task list of the display, and the third line is the software name of the display. Ex: 720523202-1906 039780-0008 D17-HV04-SV7301E-5-L3 11. -
Page 22: Software Version
installation and debugging by users or third parties. 3. After out of factory, the casing is scratched or damaged. 4. The meter lead wire is scratched or broken 5. Failure or damage caused by force majeure (such as fire, earthquake, etc.) or natural disasters (such as lightning strikes, etc.) 6.
