- Page 1 USERS GUIDE PC5/ D10 PU5...
-
Page 2: Table Of Contents
NEW ANDANDA DRIVE TECHNIQUES(SHANGHIA) CO.,LTD 目 录 Preface...............1 Dimension&Materials............Functions .............3 Screen ................4 Warnings................4 Installation................Operations................7.1 ON/OFF................5 7.2 Speed/ODO/Time……………….…………………...5 7.3 Lighting ON/OFF.............6 7.4 6km/h Assistance.............7 7.5 Assistance level..............7 7.6 Battery capacity ............8 7.7Background light ……………………………8 7.8 Error Code……………………………………………8 EXW Setting................9 8.1 Setting................10 8.2 Background light adjustment......10 8.3 Speed... - Page 3 8.4 Unit..................1 8.5 Battery information............13 8.6 Software Version............13 8.7 ISO setting..............15 8.8 Save/quite...............16 Wiring digram..............16 10. Display printing code............16 11. FAQ&Answers............16 12. Guarantee&Warranty..........17 13. Edition updated..............17...
- Page 5 1. Perface Dear Customer, we ask you please kindly study this manual for D10 PC5/ D10 PU5 to use your electric bike better. We will try to present you necessary information including installation, setting and normal use in most clear words, and hope it helps to clear your possible confusion or problems.
-
Page 6: Dimension&Materials
2. Dimension&Materials D10 PC5/ D10 PU5 display includes screen and control buttons, Screen is a combined set including metal holder and glass plate. Cover of the display is applicable for ambient temperatures ranges between- 20℃ 60℃ while keeps excellent mechanical property. - Page 7 Screen of D10 PC5 Control Button of D10 PC5 D10 PC5/ D10 PU5 Control buttons kit is connected to the bottom of the display. Here we will describe the symbol as switch。+ as PLUS，— as Minus, lighting， as walk assistance。...
-
Page 8: Functions
ODO； Speed ◆At static status, it will not go back to ODO interface after shifting among AVV,MAX, TRIP, TIMEO。 （2）D10 PC5/ D10 PU5 background light automatically adjusts according to ambient brightness. （3）D10 PC5/ D10 PU5 meets with the EN15194：2017 standard。... -
Page 9: Installation
Error code Speed unit Range/time SPEED UI of Range unit MAX SPEED Asst.level Display 5. Warnning Please be careful to use the display safely, Do disconnect it when power is on; Avoid knock or crash. Have it repaired if not working properly. 6. -
Page 10: Speed/Odo/Time
◆Hold on display ON/OFF button for 2.5s if battery is on, display is turned off. Short press for turning on if display is off. If battery is on, hold on battery ON/OFF button to turn off battery, system is closed; However, if press the ON/OFF button 3s later, display is restarted. -
Page 11: Lighting
Real time speed, ODO AVG speed, Trip Max speed, Trip time 7.3 Lighting ◆AUTO-Mode：Display automatically switch on/off light by sensor according to environment; under such circumstance, short press LIGHTING button is not valid for light ON or Off. Default set for display lighting is Automode. - Page 12 ◆Manual Mode：Short press Light button at manual 仅在 mode to activate lighting; Short press again to cancel lighting function. Shift between Auto/Manual Mode: Press and Hold on lighting button for more than 2s for shift（Default set when display turned on is auto-mode, for which letter ”A”...
-
Page 13: 6Km/H Assistance
Manual Mode Interface 7.4 6km/h assistance Press and Hold on assistance button to active 6km/h assistance function, ebike runs at a stable speed of 6km/h; Release the button will cancel the function. - 9 -... -
Page 14: Assistance Level
6km/h assistance interface 7.5 Assistance level adjustment Short press PLUS or Minus button for shift of assistance level which changes output of motor. Default set for assistance has 5 levels, of which 1 level is for the lowest output, 5 is for the highest output. -
Page 15: Error Code
15%——29% First Segment 30%——44% Second Segment 45%——59% Third segment 60%——84% Fourth Segment >=85% Fifth Segment Low capacity Full capacity Under-voltage 7.7 Background light adjustment ◆Background light varies automatically according to environmental lightness by integrated sensor at Auto- Mode. Eg: Background light decreases if environment darks down;... - Page 16 Error code interface Definition： （1） CANBUS common error code definition： Code Definition Phase current failure Controller busbar overloaded Controller hall failure Brake/Throttle failure Controller Temp. Failure Motor Temp. Failure Overloaded Failure Controller communication failure Controller over or under voltage Other failure Display communication failure - 12 -...
- Page 17 CANBUS New Norm error code： Code Definition MCB failure: Base voltage failure, Calculation cycle failure TE communication failure 3.3V power failure Buttons failure Button failure Torque unit voltage failure Brake failure, speed sensor failure, Inspection Hall failure Temperature sensor failure Base sampling overdue Current feedback circuit failure Drive voltage failure...
- Page 18 （2） UART common code definition： code definition solution Abnormal check if 3 phase short bridged. current Throttle check if throttle recovered to original status failre check if well ,cabled , check if phase wire well Phase loss connected to controller. Hall failure check hall sensor well cabled.
- Page 19 8. Display EXW settings 8.1 Setting interface： Hold on Plus and Minus buttons at main interface when speed is O to enter setting mode interface. Short press Plus button to shift among background light, speed limit, unit, background light. Right corner position “1”...
- Page 20 Short press ON/OFF button at the fourth digit will save the new password. Password input interface 8.2 Background light Short press Plus button at setting interface for shift to background Light setting. BL Means background lightness，Right corner position”1” means common setting. There are 3 levels for lightness， level for the darkest setting，2 level for standard setting，3 level for the brightest。Default setting is 1。Short press ON/OFF...
-
Page 21: Speed Limit
BL setting Interface 8.3 Speed Limit Short press Plus button at setting interface for shift to speed limit setting. Speed limit setting decides the Max.Speed, upon which controller will cut off motor output to ensure rider’s safety, Speed limit rages from 12km/h to 25km/h. - Page 22 Short press plus button at setting interface for shift to unit setting interface. Unit setting is valid to set display speed and mileage unit, right corner position”1” means common setting, defaulted unit is KM. Short press ON/FF button to choose unit setting interface. Short press Plus or Minus to shift between KM/H and MPH;...
- Page 23 Battery Information Code 1 Battery information Code 14 8.6 Version Number Short press Plus button at hidden setting interface for shift to version setting interface.。 Right corner positioned “2” means hidden setting. Software version interface 8.7 ISO setting Short press Plus for shift to ISO setting interface after hidden setting mode is activated.
- Page 24 switch on lighting. The threshold is adjusted by short pressing plur or minus button. Short press ON/OFF again to save and quit. ISO setting interface 8.8 Save & Quit： After setting finished, Press and hold on ON/OFF for more than 2s for shift to main interface. Dispaly automatically jump to main interface from Setting interface if no operation detected within 60s.
